Pitch Name
P1.5
Pixel Configuration
3 in 1 SMD
Pixel Pitch (mm)
1.50
Screen Resolution (WxH)
1,920x1,080
Screen Dimension (W x H x D,mm)
2,880 x 1,620 x 128.5 (w/o Screen Frame)
Screen Weight (kg)
175 (w/o Screen Frame)
No. of Modules per Unit Case (W × H)
4 × 3
Unit Case Resolution (W × H)
640 × 360
Unit Case Dimensions (W × H × D, mm)
960 × 540 × 127.4
Unit Case Surface Area (m2 )
0.518
Weight per Unit Case (kg/unit)
Master: 20.85, Slave: 19.24
Weight per Square Meter (kg/m2 )
37.6
Physical Pixel Density (pixels/m2 )
444,444
Flatness of Unit Case (mm)
±0.2
Unit Case material
Front : Die Casting Aluminum, Rear : PC+ABS
Service Access
Front and Rear
Max. Brightness (cd/m2)
500
Colour Temperature
6,500
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
140
Brightness Uniformity
95%
Colour Uniformity
±0.015Cx,Cy
Contrast Ratio
5,000
Processing Depth (bit)
16(HDR10, HDR10 Pro)
Power Consumption (W/Screen, Max.)
2,900
Power Consumption (W/Screen, Avg.)
980
Power Consumption (W/m2, Max.)
622
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
Sound Output (Max.)
162W
Lifetime (Half Brightness, hrs) 1)
100,000
Operating Temperature(℃)
0°C to +40°C
Operating Humidity
10 ~ 80%RH
Safety
IEC 60950-1 / EN 60950-1 / UL 60950-1
EMC
FCC Class A / CE / KC
Safety / EMC
AS/NZS 60950,CB Scheme / AS/NZS CISPR32,RCM(Class A)
Environment
RoHS
Video Inputs
HDMI In(3), DP In, USB
Control
RJ45 In, RS232C In/out
Special Features
Temperature Sensor, Ambient Light Sensor, Crestron Connected 2)
Basic Accessory
Data Cable, LAN Cable, Power Cord, RS232C Gender (9pin to Phone Jack), Remote Controller, IR Receiver, Manual
To access more technical documentation and resources, please visit the LG B2B partner portal.
