    22XF1TJ-B component-copyModelName
    Outdoor Touch Open-frame Display

    Key Features

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (22XF1TJ-B)
      ?
      ?
      LG Members Price
    Total
    Add to CompareAdd to CompareRemove Compare

    component-OBScountrySelectDesc

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (22XF1TJ-B)
      ?
      ?
      LG Members Price
    Total
    Outdoor Touch Open-frame Display

    Versatile Touch Display Fit for Your Business

    A woman is charging a car by touching the touchscreen installed on an electric car charger. A woman is charging a car by touching the touchscreen installed on an electric car charger.
    * All images in this web page are for illustrative purposes only.
    A 22XF1TJ is installed on the wall at the entrance of the building with another 22XF1TJ stand below for reservation purposes. The lady with sunglasses is using the touchscreen to make a reservation. The screen remains visible even when under direct sunlight. A 22XF1TJ is installed on the wall at the entrance of the building with another 22XF1TJ stand below for reservation purposes. The lady with sunglasses is using the touchscreen to make a reservation. The screen remains visible even when under direct sunlight.

    High Visibility Under Bright Environments

    With a brightness of 1,300 nits, 22XF1TJ boasts high visibility in bright environments. In addition, its clear visibility can deliver a variety of information even to those wearing polarized sunglasses.
    The left one shows a 22XF1TJ installed on the wall showing its 21.5" in size. On the right, there are various screen types: A wall-mount type, hanging type, kiosk type. The left one shows a 22XF1TJ installed on the wall showing its 21.5" in size. On the right, there are various screen types: A wall-mount type, hanging type, kiosk type.

    21.5 inches of Versatile Screen Size

    The small and light size of 21.5 inches allows for flexible use in various spaces. In particular, you can install the display in various way allowing for high utilization for small-medium businesses (SMB) to large businesses.
    22XF1TJ is installed as a touch kiosk for drive-in ordering. A woman is touching a kiosk to select a food from the menu. 22XF1TJ is installed as a touch kiosk for drive-in ordering. A woman is touching a kiosk to select a food from the menu.

    Built-in Touch Display

    The 22XF1TJ has a P-cap Touch function, and the display accurately detects touch points even on the corners or edges of the display. The user is able to get the information they need by simply touching the screen.
    The 22XF1TJ screen can adjust its brightness automatically according to the ambient light. The 22XF1TJ screen can adjust its brightness automatically according to the ambient light.

    Smart Brightness Control

    The screen brightness is automatically adjusted depending on the ambient light. The brightness is increased in light for better visibility, while it is decreased in darkness for efficient power management.
    The 22XF1TJ is used as an touch kiosk display in a self-service car wash. The 22XF1TJ is protected against dust, direct sunlight, rain, and snow. The 22XF1TJ is used as an touch kiosk display in a self-service car wash. The 22XF1TJ is protected against dust, direct sunlight, rain, and snow.

    Secured Protection with IP66 Design

    The front part of the display is sealed with IP66 design for reliable operation. It’s designed to be not only waterproof but also waterproof against the damaging effects of the sun, rain, snow, dust and wind, which is an essential feature for outdoor application.
    * IP Code or Ingress Protection Code classifies the degree of protection provided by
    mechanical casings and electrical enclosures against intrusion, dust, accidental contact, and water.
    ** IP66 means the product is protected from total dust ingress and resists highpressure, heavy sprays of water.
    *** 22XF1TJ is certified as IP66 by CTK in November 2021.
    The 22XF1TJ is used as a drive-thru ordering touch kiosk. The display is working well in an environment of 0~50°C. The 22XF1TJ is used as a drive-thru ordering touch kiosk. The display is working well in an environment of 0~50°C.

    Wide Operating Temperature Range

    22XF1TJ can be used under a wide range of operating temperatures from 0°C to 50°C* which results in fewer constraints for outdoor installation.
    * 22XF1TJ is LG-internally tested under humidity of 30% (55°C ) and 99% (40°C).
    When an external impact is applied to the display, the glass screen of non-shatterproof displays breaks and shatters, but the screen of 22XF1TJ only cracks and doesn't shatter. When an external impact is applied to the display, the glass screen of non-shatterproof displays breaks and shatters, but the screen of 22XF1TJ only cracks and doesn't shatter.

    Shatterproof Design with Boosted Safety

    The 22XF1TJ applies a shatterproof film to the back of the front glass, preventing the risk of scattering debris even if the glass is damaged by a forceful impact.
    The 22XF1TJ has a conformal coating making it resistant to salinity in moisture. The 22XF1TJ has a conformal coating making it resistant to salinity in moisture.

    Conformal Coating

    Conformal Coating* improves reliability of the circuit board, power board by protecting it against humidity.
    * Conformal Coating : Thin protective films/breathing membranes that filter water vapor and solid debris

    Antibacterial Coating for
    More Hygienic Touch Usage

    The 22XF1TJ, equipped with a touch screen covered by Antimicrobial Coating glass, prevents microbial growth and allows users to confidently touch the screen. This coating is also effective in preventing contamination which can be caused by bacteria transmitted through touching the screen, reducing stains and screen discoloration.
    A user is touching the 22XF1TJ screen with an antibacterial coating. A user is touching the 22XF1TJ screen with an antibacterial coating.
    * Antimicrobial coating glass is on surface of screen only and the effect may vary depending on kind of bacteria or conditions of use.
    ** The antimicrobial coating glass is treated with the antibiotic substance AEM 5700.
    *** The antibiotic substance AEM 5700 has the antibacterial effectiveness of more than 99% against Escherichia coli and Staphylococcus aureus. (The test (Test method : ISO 22196:2011) is conducted on a glass surface covered with AEM 5700.)
    **** The antibiotic substance AEM 5700 has the antibacterial effectiveness of more than 99% against SARS-CoV-2. (The test (Test method : ISO 18184:2019) is conducted on fabric covered with AEM 5700.)
    ***** The antibiotic substance AEM 5700 is certified by U.S. Environment Protection Agency (EPA) and the Biocidal Products Regulation (BPR, Regulation (EU)).

    Web Monitoring
    (Control Manager)

    This is a web-based monitoring solution, which provides a ease of control for the user. It enables users to have full access anywhere, anytime from their mobile phone & PC as long as they’re connected to a network while having access to both current and past data. It allows users to monitor the unit, make any adjustments and control it remotely in real-time.
    User can monitor and control their displays through mobile phone and laptop. User can monitor and control their displays through mobile phone and laptop.

    Real-time LG ConnectedCare Service

    Maintenance is easy and fast with the optional LG ConnectedCare* service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, supporting the stable operation of clients' businesses.
    The LG employee is remotely monitoring the 22XF1TJ series installed in a different place by using cloud-based LG monitoring solution. The LG employee is remotely monitoring the 22XF1TJ series installed in a different place by using cloud-based LG monitoring solution.
    * The availability of the 'LG ConnectedCare' service differs by region, and it needs to be purchased separately. So please contact the LG sales representative in your region for more details.
    Close
    PANEL
    • Screen Size
      21.5"
      Panel Technology
      IPS
    • Back Light Type
      Edge
      Aspect Ratio
      16:9
    • Native Resolution
      1920x1080 (FHD)
      Refresh Rate
      60 Hz
    • Brightness
      1300nit (Typ, w/ Glass)
      Contrast Ratio
      1000:1 (Typ)
    • Dynamic CR
      800,000:1
      Color gamut
      NTSC 72%
    • Viewing Angle (H x V)
      178 × 178
      Color Depth
      8bit, 16.7Million colors
    • Response Time
      25ms (G to G)
      Surface Treatment(Haze)
      Anti glare, 3H(Haze 25%)
    • Life time
      70,000 Hrs (Typ)
      Operation Hours (Hours/Day)
      24/7
    • Portrait / Landscape
      Yes / Yes
      QWP(Quarter Wave Plate)
      Yes (Apply on glass)
    CONNECTIVITY(JACK INTERFACE)
    • Input
      HDMI (1, HDCP1.4), RS232C IN, RJ45(LAN), USB2.0 Type A (1)
      Output
      Touch USB, Externel Speaker Out (1, L/R, 10W+10W), RS232C OUT
    MECHANICAL SPECIFICATION
    • Bezel Color
      Black
      Bezel Width
      32.0mm(R/L), 27.0mm(T/B)
    • Weight (Head)
      8.0kg
      Packed Weight
      9.6kg
    • Monitor Dimension (W x H x D)
      554.7 x 325.8 x 60mm
      Carton Dimensions(W x H x D) (Box outer size)
      644 x 406 x 207 mm
    • VESA? Standard Mount Interface
      100x100
      Protection Glass
      Depth 3mm, Tempered / Chemical strengthening (Thermal-strengthening), Shatter-Proof
    KEY FEATURE
    • HW
      Internal Memory 16GB, Temperature Sensor, Auto Brightness sensor, Humidity Sensor, Acceleration(Gyro) Sensor, Power Indicator, FAN
      SW
      webOS ver. (webOS4.1), Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail over, Background Image (Booting Logo Image, No Signal Image), Sync Mode (Local Network Sync), Video Tag (4, Max One HDMI input), Play via URL, Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Setting Data Cloning, SNMP, ISM Method, Status Mailing, Control Manager, Power (Smart Energy Saving, PM mode, Wake on LAN, Network Ready), HDMI-CEC, SI Server Setting, webRTC, Pro:Idiom
    ENVIRONMENT CONDITIONS
    • Operation Temperature
      0°C to 50 °C
      Operation Humidity
      10 % to 80 %
    POWER
    • Power Supply
      AC 100-240V~, 50/60Hz
      Power Type
      Built-In Power
    POWER CONSUMPTION
    • Typ.
      85W (Full White)
      37W (IEC 62087)
      Max.
      115W
    • BTU (British Thermal Unit)
      290(Typ), 393(Max)
      DPM
      0.5W↓
    • Power off
      0.5W↓
    CERTIFICATION
    • Safety
      CB / NRTL
      EMC
      FCC Class "A" / CE / KC / VCCI
    • ErP / Energy Star
      Yes / No
    SOFTWARE COMPATIBILITY
    • SuperSign CMS
      Yes
      SuperSign Control / Control+
      Yes / Yes
    • Signage 365 Care
      Yes
    Language
    • OSD
      English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Arab, Turkish
    ACCESSORY
    • Basic
      Remote Controller(including battery 2ea),
      Power Cord, Manual (EIG, IG), RS-232C Gender
    SPECIAL FEATURE
    • Tilt(Facedown)
      Yes (Max -15o degree, Face Down) PP
      IP Rating
      IP66 (Front Only)
    • Direct Sunlight
      Yes
