Fast Installation
Easy Maintenance
Two Cabinet Options
90° Corner Design Available
Front or Rear Serviceability
Compatibility with
LG Software Solutions
* The items that can be monitored by LG ConnectedCare : Main Board (Temp., Signal Status, FPGA Ver, Ethernet Connection Status), Receiving Card (Temp., LED Power)
-
- Pixel Configuration
- 3 in 1 SMD
- Pixel Pitch (mm)
- 3.91
-
- Module Resolution (W x H)
- 64 × 128
- Module Dimensions (W x H, mm)
- 250 × 500
-
- Weight per Module (kg)
- 1.30
- No. of Modules per Cabinet (W × H)
- 2 × 2 / 2 × 1 (Half-sized)
-
- Cabinet Resolution (W × H)
- 128 × 256 / 128 × 128 (Half-sized)
- Cabinet Dimensions (W × H × D)
- 500 × 1,000 × 66 / 500 × 500 × 66 (Half-sized)
-
- Cabinet Surface Area (m2)
- 0.500 / 0.250 (Half-sized)
- Weight per Cabinet (kg/cabinet)
- 12.0 / 8.0 (Half-sized)
-
- Weight per Square Meter (kg/m2)
- 24.0 / 32.0 (Half-sized)
- Physical Pixel Density (pixels/m2)
- 65,536
-
- Flatness of Cabinet
- ± 0.3 mm
- Cabinet Material
- Die Casting Aluminum Alloy
-
- Service Access
- Front or Rear (One Option Only)
-
- Min. Brightness (After Calibration)
- 1,000
- Color Temperature
- 3,500 ~ 9,000
-
- Visual Viewing Angle (Horizontal)
- 160
- Visual Viewing Angle (Vertical)
- 160
-
- Brightness Uniformity
- 97%
- Color Uniformity
- ± 0.003 Cx,Cy
-
- Contrast Ratio
- 7,000
- Processing Depth (bit)
- 14
-
- Power Consumption (W/cabinet, Max.)
- 270 / 135 (Half-sized)
- Power Consumption (W/cabinet, Avg.)
- 90 / 45 (Half-sized)
-
- Power Consumption (W/m2, Max.)
- 540
- Heat Dissipation (BTU/h/Cabinet, Max.)
- 921 / 461 (Half-sized)
-
- Heat Dissipation (BTU/h/Cabinet, Avg.)
- 307 / 154 (Half-sized)
- Heat Dissipation (BTU/h/m2, Max.)
- 1,842
-
- Power Supply (V)
- 100 to 240
- Frame Rate (Hz)
- 50 / 60
-
- Refresh Rate (Hz)
- 3,840
-
- Lifetime (Hours to Half Brightness)
- 100,000
- Operating Temperature (°C)
- -10 °C to +45 °C
-
- Operating Humidity
- 0 - 80 % RH
- IP rating Front / Rear
- IP30 / IP30
-
- Certification
- CE,FCC,ETL
-
- Environment
- RoHS
-
- Controller
- CVCA, LCIN006
