- Pixel Configuration
- 3 in 1 SMD
- Pixel Pitch (mm)
- 3.91
-
- Module Resolution (W x H)
- 64 × 128
- Module Dimensions (W x H, mm)
- 250 × 500
-
- Weight per Module (kg)
- 1.40
- No. of Modules per Cabinet (W × H)
- 2 × 2 / 2 × 1 (Half-sized)
-
- Cabinet Resolution (W × H)
- 128 × 256 / 128 × 128 (Half-sized)
- Cabinet Dimensions (W x H x D, mm)
-
500 × 1,000 × 66.05
500 × 500 × 66.05 (Half-sized)
-
- Cabinet Surface Area (m2)
- 0.500 / 0.250 (Half-sized)
- Weight per Cabinet (kg/cabinet)
- 12.5 / 7.9 (Half-sized)
-
- Weight per Square Meter (kg/m2)
- 24.9 / 31.7 (Half-sized)
- Physical Pixel Density (pixels/m2)
- 65,536
-
- Flatness of Cabinet
- ± 0.3 mm
- Cabinet Material
- Die-casting Magnesium
-
- Service Access
- Front or Rear (One Option Only)
-
- Min. Brightness (After Calibration)
- 5,000
- Color Temperature
- 3,500 ~ 9,000
-
- Visual Viewing Angle (Horizontal/Vertical)
- 160 / 155
- Brightness Uniformity
- 97%
-
- Color Uniformity
- ± 0.003 Cx,Cy
- Contrast Ratio
- 6,000
-
- Processing Depth (bit)
- 14
-
- Power Consumption (W/Cabinet, Max.)
- 300 / 150 (Half-sized)
- Power Consumption (W/Cabinet, Avg.)
- 100 / 50 (Half-sized)
-
- Power Consumption (W/m2, Max.)
- 600
- Heat Dissipation (BTU/h/Cabinet, Max.)
- 1024 / 512 (Half-sized)
-
- Heat Dissipation (BTU/h/Cabinet, Avg.)
- 341 / 171 (Half-sized)
- Heat Dissipation (BTU/h/m2, Max.)
- 2047
-
- Power Supply (V)
- 100 to 240
- Frame Rate (Hz)
- 50 / 60
-
- Refresh Rate (Hz)
- 3,840
-
- Lifetime (Hours to Half Brightness)
- 100,000
- Operating Temperature (°C)
- -20℃ to +45℃
-
- Operating Humidity
- 10-99%RH
- IP Rating Front
- IP65
-
- IP Rating Rear
- IP65
-
- Certification
- CE,FCC,ETL
-
- Environment
- RoHS
-
- Controller
- LCIN006
-
- Series
- GSCA
