Name: LG LED Cinema
Brand: LG

LG LED Cinema

Find a Dealer

LG LED Cinema

LAD033F

()

Key Features

Pixel Pitch: 3.3 mm
Screen Ratio: 4,096 x 2,160 (DCI-compliant)
Brightness: 48 cd/m2 (DCI-compliant / Minimum)
Contrast Ratio: 4,000 : 1 (Minimum)

Real Black, Infinite Darkness

The infinite contrast created by the individual LEDs that make up LG LED Cinema creates deep darkness of the content. By bringing fine details perfectly to the screen, it provides viewers an amazing sense of immersion that has never experienced before.

Lifelike Colors

Most cinema screens feature a DCI-P3 Color Gamut spec, but the actual colors that the audience feels may be different. LG LED Cinema accurately reproduces the colors intended by the content creator and delivers the DCI-P3 Color more vividly.

High Uniformity

Unlike standard projectors using a single light source, LG LED Cinema has LEDs emitting individually and offers an excellent brilliance uniformity. As there is no dimming and image distortion like fading, LG LED Cinema delivers a clearer & uniform image representation on the entire screen.

The Optimal Space Utilization

As LG LED Cinema does not need a projection room which is necessary in standard projector-style theaters, it guarantees maximizing profits by securing additional seats. A space behind the stuffy theater can be reinvented to more customer satisfying interiors.

Compatibility with Dolby

LG LED Cinema has secured compatibility with Dolby Media Server and Dolby Atmos of Dolby, the global leader in the entertainment industry, to offer the most immersive experiences in sound, as well as picture quality.

Longer Lifetime

The LG LED Cinema boasts 100,000 hours of long lifetime and saves time and cost for maintenance. It doesn’t require placement of parts like lamps as conventional projectors used to.

All Spec

OPTICAL PARAMETER

Pitch

3.3 mm
LED Type

SMD
Pixels per LED Module

8,640
Aspect Ratio

64 : 90 (per Cabinet)
Resolution

192 × 270 (per Cabinet)
Pixels

51,840 (per Cabinet)
Pixel Density

90,000 (per SQM)
Visual Viewing Angle (Horizontal/Vertical)

120o, 120o
Color Depth

12 Bit (DCI-compliant)
Chromaticity Uniformity

In case of White : Within ±0.015 x, ±0.015 y
Color Temperature (White)

(x. y) = (0.314, 0.351) / DCI-P3 Theater
Color Temperature (R, G, B)

DCI-P3 theater
R: (x. y) = (0.68, 0.32)
G: (x. y) = (0.265, 0.690)
B: (x. y) = (0.15, 0.06)
Contrast Ratio

4000 : 1 (Minimum)
Brightness(After Calibration)

48 nit (DCI-compliant)
Color Gamut

DCI - P3 (DCI-compliant)
Video Frame Rate

24 Hz, 25 Hz, 30 Hz, 48 Hz, 50 Hz, 60 Hz
Lifetime

100,000 Hours (LED to Half Brightness)
Operation Hours

16 Hours per Day / 7 Days per Week

PHYSICAL/ELECTRICAL PARAMETERS

Modules (per Cabinet)

6 (2 × 3)
Dimension (LDM)

320 mm × 300 mm
Dimension (per Cabinet)

640 mm × 900 mm × 124 mm (Including Handle)
Dimension (4K, Total)

14,080 mm × 7,200 mm (101 sqm)
Dimension (4K, Active Area)

13,653 mm × 7,200 mm (98 sqm)
Weight (per Cabinet)

15 kg
Weight (4K, Total)

2,640 kg
Material of Cabinet Body

Aluminum
Heat Generation (per Cabinet)

221 BTU (Max.) / 73 BTU (Typ.)
Serviceability

Rear only
Power Supply

AC100-240 V ~, 50/60 Hz
Power Type

Built-in Power
Power Consumption (Max, per Cabinet)

90 watt (Main) / 52 watt (Secondary)
Power Consumption (Max, 4K)

9,260 W
Certification

DCI, CB, CE-LVD/EMC, FCC, ETL/UL, RoHS, REACH
Supported Media Server

Dolby? IMS3000
Interface

RJ45
Operation Temperature

0°C to 40°C
Operation Humidity

10% to 80%
Storage Temperature

-20°C to 60°C (-4°F to 140°F)
Storage Humidity

5% to 85%
