Pitch
3.3 mm
LED Type
SMD
Pixels per LED Module
8,640
Aspect Ratio
64 : 90 (per Cabinet)
Resolution
192 × 270 (per Cabinet)
Pixels
51,840 (per Cabinet)
Pixel Density
90,000 (per SQM)
Visual Viewing Angle (Horizontal/Vertical)
120o, 120o
Color Depth
12 Bit (DCI-compliant)
Chromaticity Uniformity
In case of White : Within ±0.015 x, ±0.015 y
Color Temperature (White)
(x. y) = (0.314, 0.351) / DCI-P3 Theater
Color Temperature (R, G, B)
DCI-P3 theater
R: (x. y) = (0.68, 0.32)
G: (x. y) = (0.265, 0.690)
B: (x. y) = (0.15, 0.06)
Contrast Ratio
4000 : 1 (Minimum)
Brightness(After Calibration)
48 nit (DCI-compliant)
Color Gamut
DCI - P3 (DCI-compliant)
Video Frame Rate
24 Hz, 25 Hz, 30 Hz, 48 Hz, 50 Hz, 60 Hz
Lifetime
100,000 Hours (LED to Half Brightness)
Operation Hours
16 Hours per Day / 7 Days per Week
Modules (per Cabinet)
6 (2 × 3)
Dimension (LDM)
320 mm × 300 mm
Dimension (per Cabinet)
640 mm × 900 mm × 124 mm (Including Handle)
Dimension (4K, Total)
14,080 mm × 7,200 mm (101 sqm)
Dimension (4K, Active Area)
13,653 mm × 7,200 mm (98 sqm)
Weight (per Cabinet)
15 kg
Weight (4K, Total)
2,640 kg
Material of Cabinet Body
Aluminum
Heat Generation (per Cabinet)
221 BTU (Max.) / 73 BTU (Typ.)
Serviceability
Rear only
Power Supply
AC100-240 V ~, 50/60 Hz
Power Type
Built-in Power
Power Consumption (Max, per Cabinet)
90 watt (Main) / 52 watt (Secondary)
Power Consumption (Max, 4K)
9,260 W
Certification
DCI, CB, CE-LVD/EMC, FCC, ETL/UL, RoHS, REACH
Supported Media Server
Dolby? IMS3000
Interface
RJ45
Operation Temperature
0°C to 40°C
Operation Humidity
10% to 80%
Storage Temperature
-20°C to 60°C (-4°F to 140°F)
Storage Humidity
5% to 85%
