Ultra Stretch Signage, 58:9 Space-Fitting Wide Screen
The 86BH5F is the most suitable display for delivering new forms of advertising and multiplexed information in a 58:9 widescreen format. It can bring unused & leftover space to life by being installed without restriction.
* All images in this page are for illustrative purposes only.
58:9 Extended Wide Format
It is a unique wide screen with 58:9 bar type which provides much more flexibility in playing content* than the conventional display of 16:9 ratio.
* Video content only. (Images not supported)
-Special-Digital-Signage-ID-D.jpg)
-Special-Digital-Signage-ID-M.jpg)
Ultra HD Resolution (3,840 x 600)
Ultra HD resolution delivers an immersive viewing experience with vivid colors and clear images.
Multi Screen Mode with 4PBP
The Picture-by-Picture (PBP) feature allows you to show multi content in one single display by up-to four parts. It is very useful and convenient to deliver various advertisements or pieces of information at the same time without calibration.
Tiled Scene with Immersive View
The 86BH5F can show a tiled scene by up to 15 × 15 configuration. This will be the best choice if you want to use a large screen, or provide visual impact to your customers in a different way.
IP5x Certified Design
The IP5x Dust-Proof Certification ensures that the product is completely protected from dust, eliminating the risk of performance degradation.
User-Friendly UX
The 86BH5F is equipped with a user-friendly UX to simplify approach flows, groups similar functions together, and adopts an intuitive GUI for ease of use. When using the display in portrait mode, OSD* can also be adjusted accordingly.
*OSD : On Screen Display
LAN Daisy Chain Management
By using this daisy-chained network feature, you can execute commands such as controlling, monitoring and even updating firmware.
Real-Time Monitoring with ConnectedCare
Easier and faster maintenance are available with our optional cloud service solution ConnectedCare*. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, ensuring the stable operation of clients' businesses.
* ConnectedCare is the brand name of LG Signage365Care Service. The availability differs by region.
PANEL
-
- Screen Size
- 86"
- Panel Technology
- IPS
-
- Aspect Ratio
- 58:9
- Native Resolution
- 3840 x 600
-
- Refresh Rate
- 60Hz
- Brightness(Typ.,cd/m2)
- 500nit (Typ.)
-
- Contrast Ratio
- 1,100:1
- Dynamic CR
- 500,000:1
-
- Color gamut
- NTSC 72%
- Viewing Angle (H x V)
- 178 x 178
-
- Color Depth
- 10bit, 1.07Billion colors
- Response Time
- 8ms(G to G)
-
- Surface Treatment(Haze)
- 10%
- Operation Hours (Hours/Day)
- 24/7
-
- Portrait / Landscape
- Yes / Yes
CONNECTIVITY
(JACK INTERFACE)-INPUT
(JACK INTERFACE)-INPUT
-
- Digital-HDMI
- Yes(3), HDCP2.2 / 1.4
- Digital-DP
- Yes(1), HDCP2.2 / 1.3
-
- Digital-DVI-D
- Yes (1), HDCP1.4
- Audio In
- Yes(1)
-
- RS232C IN
- Yes(1)
- RJ45(LAN)
- Yes(1)
-
- IR IN
- Yes(1)
- USB
- USB2.0 Type A(2)
CONNECTIVITY
(JACK INTERFACE)-OUTPUT
(JACK INTERFACE)-OUTPUT
-
- DP Out
- Yes (1), Input : HDMI / DVI / DP
- Audio Out
- Yes(1)
-
- RS232C OUT
- Yes(1)
- RJ45(LAN)
- Yes(1)
MECHANICAL SPECIFICATION
-
- Bezel Color
- Black
- Bezel Width
- T/R/L/B : 5.9/4.4/4.4/5.9mm
-
- Weight (Head)
- 20.5 kg
- Monitor Dimensions (W x H x D)
- 2158.3 x 348.5 x 81.7mm
-
- Handle
- Yes
- VESA? Standard Mount Interface
- 600 x 200
KEY FEATURE
-
- HW - Internal Memory
- 8GB
- HW - Wi-Fi - Built-in
- Yes
-
- HW - Sensor - Temperature Sensor
- Yes
- HW - Sensor - Auto Brightness sensor
- Yes
-
- HW - Sensor - Current Sensor
- Yes
- HW - Local Key Operation
- Yes
-
- SW - webOS ver.
- webOS 4.0 (SCAP : not support)
- SW - Embedded CMS - Local Contents Scheduling
- Yes
-
- SW - Embedded CMS - Group Manager
- Yes
- SW - USB Plug & Play
- Yes
-
- SW - Fail over
- Yes
- SW - Background Image - Booting Logo Image
- Yes
-
- SW - Background Image - No Signal Image
- Yes
- SW - Sync Mode - RS-232C Sync
- Yes
-
- SW - Sync Mode - Local Network Sync
- Yes
- SW - Multi-screen - PBP
- Yes(4)
-
- SW - Rotation - Screen Rotation
- Yes
- SW - Rotation - External Input Rotation
- Yes
-
- SW - Tile Mode Setting
- Yes(Max. 15x15)
- SW - Setting Data Cloning
- Yes
-
- SW - SNMP
- Yes
- SW - ISM Method
- Yes
-
- SW - Auto Set ID
- Yes
- SW - Status Mailing
- Yes
-
- SW - Control Manager
- Yes
- SW - 3rd Party Compatibility - Crestron Inside
- Yes
-
- SW - Smart Energy Saving
- Yes
- SW - PM mode
- Yes
-
- SW - Wake on LAN
- Yes
- SW - Beacon
- Yes
-
- SW - HDMI-CEC
- Yes
ENVIRONMENT CONDITIONS
-
- Operation Temperature
- 0°C to 40°C
- Operation Humidity
- 10% to 80%
POWER
-
- Power Supply
- AC 100-240V~, 50/60Hz
- Power Type
- Built-In Power
POWER CONSUMPTION
-
- Typ.
- 220W
- Max.
- 240W
-
- BTU (British Thermal Unit)
- 751 BTU/Hr(Typ.), 819 BTU/Hr(Max)
CERTIFICATION
-
- Safety
- CB / NRTL
- EMC
- FCC Class "A" / CE / KC
OPS COMPATIBILITY
-
- OPS type compatible
- O(Piggyback)
SOFTWARE COMPATIBILITY
-
- SuperSign Control / Control+
- Yes/Yes
- SuperSign WB
- Yes
-
- SuperSign Media Editor
- Yes
- LG ConnectedCare
- Yes
LANGUAGE
-
- OSD
- English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Japanese, Russian, Portugues(Europe), Dutch, Czech, Greek, Arabic
ACCESSORY
-
- Basic
- Remote Controller(including battery 2ea), Power Cord, DP cable, RS-232C Cable,IR/Light sensor receiver, Manual
- Optional
- OPS Kit(KT-OPSF)
