The Stadium Series is perfect for any outdoor use or applications. With its powerful display, it can adapt to any environment. Learn about the product features below.
?
Outstading Visibility1
Smooth Playback in Dynamic Motion1
*LBF160DA1D Rear: IP43-certified.
*Except the LBS060DA1D, LBS060DA3D, LBF160DA1D models.
?
| Model Name | LBS100DA1D | LBS100DA3D | LBS120DA1D | LBS120DA3D |
|---|---|---|---|---|
| Pixel Configuration | 3 in 1 SMD | 3 in 1 SMD | 3 in 1 SMD | 3 in 1 SMD |
| Pixel Pitch(mm) | 10.667 | 10.667 | 12.00 | 12.00 |
| Unit Case Resolution (WxH) | 144x144 | 144x144 | 128x128 | 128x128 |
| Unit Case Dimension (WxHxD, mm) | 1536x1536x222 | 1536x1536x222 | 1536x1536x223 | 1536x1536x223 |
| Weight per Unit Case / Square Meter (kg) | 104.0/44.1 | 104.0/44.1 | 104.0/44.1 | 104.0/44.1 |
| Service access | Front or Rear | Front or Rear | Front or Rear | Front or Rear |
| Min. Brightness (After Calibration) | 6,000 | 6,000 | 6,000 | 6,000 |
| Color Temperature | 3500-8500 | 3500-8500 | 3500-8500 | 3500-8500 |
| Visual Viewing Angle (Horizontal/Vertical) | 160/145 | 160/145 | 160/125 | 160/125 |
| Brightness Uniformity / Color Uniformity | ≥97％/±0.05Cx,Cy | ≥97％/±0.05Cx,Cy | ≥97％/±0.05Cx,Cy | ≥97％/±0.05Cx,Cy |
| Contrast Ratio | 3,000 | 3,000 | 3,000 | 3,000 |
| Processing Depth (bit) | 16 | 16 | 16 | 16 |
| Power Consumption (W/Unit, Avg./Max.) | 616/1540 | 580/1450 | 580/1450 | 544/1360 |
| Power Consumption (W/m2, Max.) | 653 | 615 | 615 | 576 |
| Power Supply (V) | 100 to 240 | 100 to 240 | 100 to 240 | 100 to 240 |
| Refresh Rate (Hz) | 4,000 | 4,000 | 4,000 | 4,000 |
| Lifetime (Half brightness)* | 100,000 | 100,000 | 100,000 | 100,000 |
| Operating Temperature(°C) / Humidity | -20° to 50°/< 90%RH | -20° to 50°/< 90%RH | -20° to 50°/< 90%RH | -20° to 50°/< 90%RH |
| IP rating Front / Rear | IP65/IP54 | IP65/IP54 | IP65/IP54 | IP65/IP54 |
?
*The Lifetime(Half brightness) spec is subject to LED package spec.
**Models may vary by region. Check with local salesteam for availability.
?
| Model Name | LBS100DA1D | LBS100DA3D | LBS120DA1D | LBS120DA3D |
|---|---|---|---|---|
| Pixel Configuration | 3 in 1 SMD | 3 in 1 SMD | 3 in 1 SMD | 3 in 1 SMD |
| Pixel Pitch(mm) | 10.667 | 10.667 | 12.00 | 12.00 |
| Unit Case Resolution (WxH) | 144x144 | 144x144 | 128x128 | 128x128 |
| Unit Case Dimension (WxHxD, mm) | 1536x1536x222 | 1536x1536x222 | 1536x1536x223 | 1536x1536x223 |
| Weight per Unit Case / Square Meter (kg) | 104.0/44.1 | 104.0/44.1 | 104.0/44.1 | 104.0/44.1 |
| Service access | Front or Rear | Front or Rear | Front or Rear | Front or Rear |
| Min. Brightness (After Calibration) | 6,000 | 6,000 | 6,000 | 6,000 |
| Color Temperature | 3500-8500 | 3500-8500 | 3500-8500 | 3500-8500 |
| Visual Viewing Angle (Horizontal/Vertical) | 160/145 | 160/145 | 160/125 | 160/125 |
| Brightness Uniformity / Color Uniformity | ≥97％/±0.05Cx,Cy | ≥97％/±0.05Cx,Cy | ≥97％/±0.05Cx,Cy | ≥97％/±0.05Cx,Cy |
| Contrast Ratio | 3,000 | 3,000 | 3,000 | 3,000 |
| Processing Depth (bit) | 16 | 16 | 16 | 16 |
| Power Consumption (W/Unit, Avg./Max.) | 616/1540 | 580/1450 | 580/1450 | 544/1360 |
| Power Consumption (W/m2, Max.) | 653 | 615 | 615 | 576 |
| Power Supply (V) | 100 to 240 | 100 to 240 | 100 to 240 | 100 to 240 |
| Refresh Rate (Hz) | 4,000 | 4,000 | 4,000 | 4,000 |
| Lifetime (Half brightness)* | 100,000 | 100,000 | 100,000 | 100,000 |
| Operating Temperature(°C) / Humidity | -20° to 50°/< 90%RH | -20° to 50°/< 90%RH | -20° to 50°/< 90%RH | -20° to 50°/< 90%RH |
| IP rating Front / Rear | IP65/IP54 | IP65/IP54 | IP65/IP54 | IP65/IP54 |
?
*The Lifetime(Half brightness) spec is subject to LED package spec.
**Models may vary by region. Check with local salesteam for availability.
?
| Model Name | LBS160DA1D | LBS160DA3D | LBF160DA1D | LBB160DA1D2 |
|---|---|---|---|---|
| Pixel Configuration | 3 in 1 SMD | 3 in 1 SMD | 3 in 1 SMD | 3 in 1 SMD |
| Pixel Pitch(mm) | 16.00 | 16.00 | 16.00 | 16.00 |
| Unit Case Resolution (WxH) | 96x96 | 96x96 | 48x60 | 96x60 |
| Unit Case Dimension (WxHxD, mm) | 1536x1536x227 | 1536x1536x227 | 768x960x254 | 1536x960x215 |
| Weight per Unit Case / Square Meter (kg) | 104.0/44.1 | 104.0/44.1 | 40.0/54.3 | 71.0/48.1 |
| Service access | Front or Rear | Front or Rear | TOP | Front or Rear |
| Min. Brightness (After Calibration) | 6,000 | 6,000 | 6,000 | 6,000 |
| Color Temperature | 3500-8500 | 3500-8500 | 3500-8500 | 3500-8500 |
| Visual Viewing Angle (Horizontal/Vertical) | 160/105 | 160/105 | 160/105 | 160/105 |
| Brightness Uniformity / Color Uniformity | ≥97％/±0.05Cx,Cy | ≥97％/±0.05Cx,Cy | ≥97％/±0.05Cx,Cy | ≥97％/±0.05Cx,Cy |
| Contrast Ratio | 3,000 | 3,000 | 3,000 | 3,000 |
| Processing Depth (bit) | 16 | 16 | 16 | 16 |
| Power Consumption (W/Unit, Avg./Max.) | 620/1550 | 584/1460 | 184/460 | 372/930 |
| Power Consumption (W/m2, Max.) | 657 | 619 | 624 | 631 |
| Power Supply (V) | 100 to 240 | 100 to 240 | 100 to 240 | 100 to 240 |
| Refresh Rate (Hz) | 4,000 | 4,000 | 4,000 | 4,000 |
| Lifetime (Half brightness)* | 100,000 | 100,000 | 100,000 | 100,000 |
| Operating Temperature(°C) / Humidity | -20° to 50°/< 90%RH | -20° to 50°/< 90%RH | -20° to 50°/< 90%RH | -20° to 50°/< 90%RH |
| IP rating Front / Rear | IP65/IP54 | IP65/IP54 | IP65/IP54 | IP65/IP54 |
?
*The Lifetime(Half brightness) spec is subject to LED package spec.
**Models may vary by region. Check with local salesteam for availability.
