    Open Frame

    Customizable Open-frame Display for Smart Effciency

    There are two 75XF3Ps installed in the drive-thru zone at the burger place, and they vividly display the burger menu and ads even in bright sunlight. There are two 75XF3Ps installed in the drive-thru zone at the burger place, and they vividly display the burger menu and ads even in bright sunlight.
    * All images in this page are for illustrative purposes only.

    Open-frame Outdoor Display

    LG Open Frame display empowers you to personalize not only the casing design but also the function, granting you the freedom to tailor the display to your exact preferences.
    Various frame-shaped displays are installed outdoors. Various frame-shaped displays are installed outdoors.
    * Please reach out to your local sales representatives for detailed casing guide

    High Visibility Under
    Strong Sunlight

    With outstanding high brightness of 3,000 nits (Typ.), the XF3P outdoor display delivers content clearly while captivating passerby. In addition, its outdoor visibility can deliver a variety of information even to those wearing polarized sunglasses.
    A large-sized display is installed on the street, and a woman is looking at a vivid-quality advertisement on the screen. A large-sized display is installed on the street, and a woman is looking at a vivid-quality advertisement on the screen.

    Optimized Design for
    Double-sided Display

    The XF3P, featuring a sleeker design than the conventional model, excels in maximizing space efficiency with its convenient double-sided display.
    A double-sided display is set up on the street. The effective placement of the circuit board allows for a slim design of the double-sided display. A double-sided display is set up on the street. The effective placement of the circuit board allows for a slim design of the double-sided display.
    * The conventional model refers to the XF3C.

    Efficient Energy Management

    The screen brightness is automatically adjusted depending on the ambient light. The brightness is increased in light for better visibility, while it is decreased in darkness for efficient power management. Also, XF3P uses M+ panel that can offer high energy efficiency and cost savings by decreasing power consumption.
    The 75XF3P screen can adjust its brightness automatically according to the ambient light. The 75XF3P screen can adjust its brightness automatically according to the ambient light.
    * M+ IPS reduced approximately 35% BLU Power consumption (IEC62087, 10 min) compared to RGB IPS, tested under same brightness (@fullwhite, 400 nits).
    ** Specific features can differ from circumstances.

    High-performance with
    webOS 6.0

    Quad Core SoC (System-on-Chip) can execute several tasks at the same time without a separate media player. In addition, webOS 6.0 platform enhances not only user convenience with intuitive UI but also web-app integration with updated Node JS / Chromium version.
    It has improved user convenience by utilizing the SoC and webOS. It has improved user convenience by utilizing the SoC and webOS.
    A display is working well in an environment of 0~50°C. A display is working well in an environment of 0~50°C.

    Wide Range of Operating Temperature

    The XF3P can be used under a wide range of operating temperature from 0℃ to 50℃.

    * Conducted by LG internal test, Operating temperature: 0℃~50℃ (without direct sunlight; with direct sunlight in cooling system), 0℃~40℃ (with direct sunlight)
    The 75XF3P has a conformal coating making it resistant to dust and salinity in moisture. The 75XF3P has a conformal coating making it resistant to dust and salinity in moisture.

    Conformal Coating

    Conformal Coating* protects the circuit board and power board against dust, iron powder, humidity, etc.

    * Thin protective films/breathing membranes that filter water vapor and solid debris

    Installation Guide for
    a Customized Casing

    LG offers an installation guide for designing a customized casing to ensure stable performance for outdoor displays. It includes information about the size of ventilation and the location of partitions within the casing.
    Each of the four 75XF3Ps has a customized casing. Each of the four 75XF3Ps has a customized casing.
    Users can monitor and control their displays through a mobile phone and laptop. Users can monitor and control their displays through a mobile phone and laptop.

    Web Monitoring

    The LG Control Manager, the embedded web monitoring program, is user-friendly and enables the user to have full access anywhere at anytime from their mobile phone or PC while having access to both current and past data. It allows the user to monitor the unit, make adjustments, and control the unit remotely in real time.

    * Enabled by wired LAN connection
    Partner content is being utilized to compose the content intended for playback on the signage. Partner content is being utilized to compose the content intended for playback on the signage.

    Professional Content Partners

    Pairing the XF3P with LG SW solutions would enhance its utilization.

    * Sold separately
    Close
    PANEL
    • Screen Size
      75"
      Panel Technology
      IPS, M+
    • Aspect Ratio
      16:9
      Native Resolution
      3,840 x 2,160 (UHD)
    • Refresh Rate
      60Hz
      Brightness
      Min: 2,800cd/m2, Typ: 3,000cd/m2
    • Contrast Ratio
      1,200:1 (Typ)
      Dynamic CR
      500,000:1
    • Color Gamut
      NTSC 72%
      Viewing Angle (H x V)
      178 x 178
    • Color Depth
      10bit ( Dethering), 1.07 billion colors
      Response Time
      8ms (G to G BW) typ.
    • Surface Treatment (Haze)
      AGLR(Haze 3%), QWP
      Life Time (Typ.)
      50,000 Hrs
    • Operation Hours (Hours / Days)
      24Hrs
      Portrait / Landscape
      Yes / Yes
    • QWP (Quarter Wave Plate)
      Yes
    MECHANICAL SPECIFICATION
    • Bezel Color
      Black
      Bezel Width
      11.8 mm Even
    • Weight (Head)
      32.7kg
      Packed Weight
      43kg
    • Monitor Dimensions (W × H × D)
      1,675.2 x 953.6 x 114.6 mm
      Carton Dimensions (W × H × D)
      1,816 x 1,106 x 285 mm
    • Handle
      Yes (2)
    FEATURE
    • Special Features
      Conformal Coating (Power Board), Direct Sunlight
    Key Feature(Hardware)
    • Internal Memory
      8GB
      Sensor
      Temperature Sensor (2), Auto Brightness Sensor, Pixel sensor (TBD), Humidity Sensor
    Key Feature(Software)
    • webOS ver.
      webOS6.0
      Features
      Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail Over, Background Image (Booting Logo Image, No Signal Image), Sync Mode (RS-232C Sync, Local Network Sync, Backlight Sync), PIP, PBP, Video Tag (4), Play via URL, Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting, Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, Power (Smart Energy Saving, PM Mode, Wake on LAN, Network Ready), HDMI-CEC, SI Server Setting, webRTC, Pro:Idiom
    ENVIRONMENT CONDITIONS
    • Operation Temperature
      0℃ to 40℃ (with Solar)
      0℃ to 50℃ (w/o Solar)
      Operation Humidity
      10% to 80%
    POWER
    • Power Supply
      AC 100-240 V ~, 50/60 Hz
      Power Type
      Built-In Power
    POWER CONSUMPTION
    • Typ.
      745W
      Max.
      775W
    • Smart Energy Saving (70%)
      280W
      DPM
      0.5W(DP, HDMI)
    • Power off
      0.5W
      BTU (British Thermal Unit)
      2,644
    CERTIFICATION
    • Safety
      CB / NRTL
      EMC
      FCC Class "A" / CE / KC / VCCI
    • ErP
      Yes
    SOFTWARE COMPATIBILITY
    • Content Management Software
      SuperSign CMS
      Control and Monitoring Software
      SuperSign Control+
    • LG ConnectedCare
      Yes
    CONNECTIVITY
    • Input
      HDMI In ((2), HDMI1/2 : HDCP 2.2), DP In (HDCP1.3), DVI-D In, Audio In, RS232C In (4pin phone jack), RJ45(LAN) In, IR In, USB In (USB2.0 Type A)
      Output
      DP Out, External Speaker Out (4pin phone jack), RS232C Out
    Language
    • OSD
      English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Arab, Türk?e, Polski
    ACCESSORY
    • Basic
      Remote Controller(including battery 2ea), Power Cord, HDMI Cable,Manual (EIG, IG) RS-232C Gender
      Optional
      Double sided Bracket (Landscape&Portrait : WM-B640S)
