    LAP020EL6BP component-copyModelName
    P2.0 700nit LG LED Curve Series for Indoor

    Key Features

    Choose your Pitch

    Add to CompareAdd to CompareRemove Compare

    component-OBScountrySelectDesc

    P2.0 700nit LG LED Curve Series for Indoor
    Find a Dealer
    Close
    PHYSICAL PARAMETER
    • Pixel Pitch
      2.0mm
      LED Type
      SMD 3-in-1
    • Resolution(WxH, per Unit Frame)
      120 x 90
      Dimensions(WxHxD, per LDM)
      240 x 180 x 10.5 mm
    • Dimensions(WxHxD, per Unit Frame)
      480 x 540 x 105mm2)
      Weight(per Unit Frame)1)
      9.3 kg2)
    • Weight(per SQM)2)
      35.9 kg2)
      IP Rating
      N/A
    • Unit Frame Material
      Die Casting Alluminum
      Unit Frame Color
      Black
    • Curvature
      H : Concave/Convex ±1,000R
      V : Concave/Convex ±6,000R
      Access
      Front and Rear
    OPTICAL PARAMETER
    • Brightness(Max)
      700nit
      Contrast Ratio
      6,000:1
    • Viewing Angle(H x V)
      160 x 140
      Bit Depth(Bit Processing per Color)
      16bit
    • Brightness Uniformity
      ≥ 95%
      Color Uniformity
      ±0.015Cx, Cy
    • Color Gamut
      NTSC 100%, BT2020 94%
      Color temperature - Default
      6,500K
    • Color temperature - Adjustable
      3,200 - 9,300K
      Video Frame Rate
      50/60Hz
    ELECTRICAL PARAMETER
    • Input Power Range
      100-240V~, 50/60Hz
      Power consumption - Max/Typ(per Unit Frame)
      250/125W
    • Power consumption - Max/Typ(per SQM)
      965/485W
      Refresh rate
      3,840Hz(Max)
    • Redundancy
      Signal
    CONNECTIVITY3)
    • Video Inputs
      HDMI In(1), DP In(1), OPS In(1), USB(1)
      Control
      RJ45 In(1), RS232C In(1)/Out(1)
    • Special Features
      Temperature Sensor, Power Detection,
      ADA Compliant4), PSU Hot Swappable4)
    OPERATION CONDITIONS
    • Working Temperature/Huminity
      0 °C to 40 °C at 10 % to 80 %
      Storage Temperature/Huminity
      -20° to +60°C at 5 to 85%
    • LED Lifetime
      100,000hrs
    CERTIFICATION
    • Safety
      N/A
      EMC
      FCC Class "A" / CE / KC
    • Environment
      RoHS
    OPTIONAL ACCESSORY
    • Optional Accessory
      N/A
    COMPLIANCE INFORMATION
    • The safety information for accessories is included with the safety information for the product and is not provided separately.
