    GSCA039-GN component-copyModelName
    Versatile Series

    Key Features

    Choose your Pitch

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (GSCA039-GN)
      AED
      AED
      LG Members Price
    Total
    Add to CompareAdd to CompareRemove Compare

    component-OBScountrySelectDesc

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (GSCA039-GN)
      AED
      AED
      LG Members Price
    Total
    Versatile Series
    Find a Dealer
    GSCA-01-GSCA-Versatile-Series-Outdoor-LED-Signage-ID-D GSCA-01-GSCA-Versatile-Series-Outdoor-LED-Signage-ID-M

    Fast Installation

    Various factors including magnets on the top and bottom, positioning pins, handles and fast locks help installers easily set up and dismantle the LED screens without additional tools.
    Fast Installation Fast Installation
    Easy Maintenance Easy Maintenance

    Easy Maintenance

    The GSCA series applied a simple Lock Fixing method which requires no additional tools, making it easier to replace LED modules or power/data units. It saves cost and time for maintenance.

    Two Cabinet Options

    The GSCA series offers two sizes of cabinets enabling a screen size configuration that fits perfectly with customer's demands.
    Two Cabinet Options Two Cabinet Options

    IP Rated Weatherproof
    & 90° Corner Design

    The cabinet is IP65 certified, allowing stable operation unaffected by weather and harsh outdoor environments. Also, if you add a 90° corner option, the GSCA series can deliver flawless content even when installed on the corners.
    IP Rated Weatherproof & 90° Corner Design IP Rated Weatherproof & 90° Corner Design
    Front or Rear Serviceability Front or Rear Serviceability

    Front or Rear Serviceability

    The product offers either front access or rear access, allowing customers to choose installation options according to their environment and minimizes limitations in installation and maintenance.

    Explore more showroom at Digital Connect

    Close
    PHYSICAL PARAMETER
    • Pixel Configuration
      3 in 1 SMD
      Pixel Pitch (mm)
      3.91
    • Module Resolution (W x H)
      64 × 128
      Module Dimensions (W x H, mm)
      250 × 500
    • Weight per Module (kg)
      1.40
      No. of Modules per Cabinet (W × H)
      2 × 2 / 2 × 1 (Half-sized)
    • Cabinet Resolution (W × H)
      128 × 256 / 128 × 128 (Half-sized)
      Cabinet Dimensions (W x H x D, mm)
      500 × 1,000 × 66.05
      500 × 500 × 66.05 (Half-sized)
    • Cabinet Surface Area (m2)
      0.500 / 0.250 (Half-sized)
      Weight per Cabinet (kg/cabinet)
      12.5 / 7.9 (Half-sized)
    • Weight per Square Meter (kg/m2)
      24.9 / 31.7 (Half-sized)
      Physical Pixel Density (pixels/m2)
      65,536
    • Flatness of Cabinet
      ± 0.3 mm
      Cabinet Material
      Die-casting Magnesium
    • Service Access
      Front or Rear (One Option Only)
    OPTICAL PARAMETER
    • Min. Brightness (After Calibration)
      5,000
      Color Temperature
      3,500 ~ 9,000
    • Visual Viewing Angle (Horizontal/Vertical)
      160 / 155
      Brightness Uniformity
      97%
    • Color Uniformity
      ± 0.003 Cx,Cy
      Contrast Ratio
      6,000
    • Processing Depth (bit)
      14
    ELECTRICAL PARAMETER
    • Power Consumption (W/cabinet, Max.)
      300 / 150 (Half-sized)
      Power Consumption (W/cabinet, Avg.)
      100 / 50 (Half-sized)
    • Power Consumption (W/m2, Max.)
      600
      Heat Dissipation (BTU/h/Cabinet, Max.)
      1024 / 512 (Half-sized)
    • Heat Dissipation (BTU/h/Cabinet, Avg.)
      341 / 171 (Half-sized)
      Heat Dissipation (BTU/h/m2, Max.)
      2047
    • Power Supply (V)
      100 to 240
      Frame Rate (Hz)
      50 / 60
    • Refresh Rate (Hz)
      3,840
    OPERATION CONDITIONS
    • Lifetime (Hours to Half Brightness)
      100,000
      Operating Temperature (°C)
      -20℃ to +45℃
    • Operating Humidity
      10-99%RH
      IP Rating Front
      IP65
    • IP Rating Rear
      IP65
    CERTIFICATION
    • Certification
      CE,FCC,ETL
    Environment
    • Environment
      RoHS
    CONTROLLER
    • Controller
      LCIN006

    To access more technical documentation and downloads, please visit the LG B2B Partner Portal.

    Find a dealer to help with service for sales, installation, and after sales.
