Eye-level Accessible LED

Name: Eye-level Accessible LED
Brand: LG UAE
SKU: GSED025-GD
Rating: 0 (0 reviews)

Key Features

Pixel Pitch: 2.50 mm
Brightness: 4,000 nit
Eye-level Pitch for Outdoor
Design for Durability and Easy Maintenance
Front and Rear Serviceability
IP Rating: IP66

Choose your Pitch

P2.5

Add to Compare

component-OBScountrySelectDesc

Key Features

Pixel Pitch: 2.50 mm
Brightness: 4,000 nit
Eye-level Pitch for Outdoor
Design for Durability and Easy Maintenance
Front and Rear Serviceability
IP Rating: IP66

Choose your Pitch

P2.5

Add to Compare

component-OBScountrySelectDesc

component-copyModel-toastMsg

Eye-level Accessible LED

A display as tall as a person is installed at eye level on the street, and a woman who is walking past is watching a clear-image-quality opera advertisement on the display’s screen.

* All images in this page are for illustrative purposes only.

A large display is installed at eye level on the street.

Eye-level Pitch for Outdoor

Unlike the existing large-scale screen that used to be installed high to secure visibility, the GSED series has a lower pixel pitch of 2.5 mm, which allows installment for eye-level accessibility and to accurately display images even on a smaller screen.

It shows the enlarged image of a corner bracket which is on the rear product.

Design for Durability and Easy Maintenance

The GSED series corner brackets provide a solid installation and reduce the risk of twisting. Its accessibility to the front and rear sides allows for easy maintenance for various installation environments.

Signal Redundancy Support

The GSED series is designed to support redundancy of signal, providing users with comfort. With an additional system controller, customers can get continuous operation while the dual controllers can reduce screen failures with bi-directional signal input.

In the case of no signal redundancy, the error is blacked out starting at the beginning of the display. However, in the case of signal redundancy, only the error part is blacked out.

* To use Signal redundancy properly, video transmission system has to be arranged suitably. Please check it with LG engineer to confirm it.

Compatibility with LG Software Solutions

When connected with LG's CVEA system controller, the GSED series is compatible with LG software solutions including SuperSign CMS, LED Assistant, and ConnectedCare, which help customers operate their own business properly.

The LG employee is remotely monitoring the GSED series installed in a different place by using a cloud-based LG monitoring solution. System controller with webOS enables GSED series to be compatible with LG software solutions.

* The availability of the 'LG ConnectedCare' service differs by region, and it needs to be purchased separately. So please contact the LG sales representative in your region for more details.
* The items that can be monitored by LG ConnectedCare : Main Board (Temp., Signal Status, FPGA Ver, Ethernet Connection Status), Receiving Card (Temp., LED Power)
* Actual GUI may vary in different webOS versions.
* SuperSign CMS service needs to be purchased separately.

PHYSICAL PARAMETER

Pixel Configuration

Single SMD

Pixel Pitch (mm)

2.50
Module Resolution (W x H)

96 × 108

Module Dimensions (W x H, mm)

240 × 270
Weight per Module (kg)

1.05

No. of Modules per Cabinet (W × H)

2 × 2
Cabinet Resolution (W × H)

192 × 216

Cabinet Dimensions (W × H × D, mm)

480 × 540 × 70
Cabinet Surface Area (m2)

0.26

Weight per Square Meter (kg/m2)

32.7
Weight per Cabinet (kg/cabinet)

8.5

Physical Pixel Density (pixels/m2)

160,000
Flatness of Cabinet

±1.0 mm

Cabinet Material

Al
Service Access

Front and Rear

Visual Viewing Angle (Horizontal/Vertical)

160 / 140
Brightness Uniformity

97%

Color Uniformity

±0.05 Cx, Cy
Contrast Ratio

4,000 : 1

Processing Depth (bit)

16 (HDR10, HDR10 Pro)

OPTICAL PARAMETER

Max. Brightness (After Calibration)

4,000 nit

Color Temperature (K)

3,500-8,500

ELECTRICAL PARAMETER

Power Consumption (W/cabinet, Max.)

180

Power Consumption (W/cabinet, Avg.)

72
Power Consumption (W/m2, Max.)

694

Heat Dissipation (BTU/h/Cabinet, Max.)

614
Heat Dissipation (BTU/h/Cabinet, Avg.)

246

Heat Dissipation (BTU/h/m2, Max.)

2,368
Power Supply (V)

100 to 240

Frame Rate (Hz)

50 / 60
Refresh Rate (Hz)

3,840

CONTROLLER

Controller

CVEA

OPERATION CONDITIONS

LED Lifetime (Half Brightness)

100,000

Operating Temperature (°C)

-30 to +50
Operating Humidity

0-90% RH

IP rating Front / Rear

IP66 / IP66

CERTIFICATION

Certification

CE / FCC / ETL

Environment

Environment

RoHS, REACH

90 degree corner cut

90 degree corner cut

Yes
