    Outdoor LED
    Find a Dealer

    Outdoor Signage with Long-Range Visibility

    The LED screen is prominently displayed across two sides of the building's exterior. Even though it is installed wrapping around the corner, the content appears seamless without interruption. Despite the bright sunlight and the high-mounted position, its visibility and clarity remain excellent. The LED screen is prominently displayed across two sides of the building's exterior. Even though it is installed wrapping around the corner, the content appears seamless without interruption. Despite the bright sunlight and the high-mounted position, its visibility and clarity remain excellent.
    * All images in this page are for illustrative purposes only.
    A large GSPA screen is installed on the exterior wall of the building entrance. A large GSPA screen is installed on the exterior wall of the building entrance.

    Long-Range Visibility

    Ideal for long-distance visibility, our GSPA6.6/10.0 models are perfect for large billboards and mid-to-high building facades. Capture attention from a distance with crisp, clear text and vibrant visuals.
    The GSPA series, with its enhanced power consumption, offers higher energy efficiency. The GSPA series, with its enhanced power consumption, offers higher energy efficiency.

    Enhanced Energy Efficiency

    Compared to LG’s traditional model, power consumption has decreased by more than 21%*, based on the same brightness. This means that operating costs are significantly reduced.

    * Power consumption improvement is compared to the LG GSEG100-GS model.
    The use of two cabinet sizes and an L-shaped installation enables the LED screen to be seamlessly mounted on the building's cornered wall. The use of two cabinet sizes and an L-shaped installation enables the LED screen to be seamlessly mounted on the building's cornered wall.

    Flexible Installation

    The GSPA series offers two sizes of cabinets, allowing for a screen size configuration that perfectly meets customer demands. Both side-cut cabinets can also be used as described. The GSPA series integrates seamlessly into the space and delivers smooth content to customers.
    The GSPA series can be installed by selecting either 6,000 or 8,000 or 10,000 nits brightness for the surrounding environment. The GSPA series can be installed by selecting either 6,000 or 8,000 or 10,000 nits brightness for the surrounding environment.

    High Brightness for Outdoor

    Optionally, users can choose among several models, such as P10 / 10,000 nit, P10 / 8,000 nit, P6.6 / 8,000 nit, and P6.6 / 6,000 nit. It can also be optimized for screen time, region, regulations, and power consumption, depending on different environmental conditions. The P10 operates at temperatures up to 60°C and can be reliably installed at altitudes of up to 5,000 meters.

    * Brightness options are set before shipment from the factory, and cannot be changed after installation.

    Compatibility with LG Software Solutions

    When connected with LG's CVGA system controller, the GSPA series is compatible with LG software solutions including SuperSign CMS, LED Assistant, and ConnectedCare, which help customers operate their own business properly.
    The LG employee is remotely monitoring the GSPA series installed in a different place by using a cloud-based LG monitoring solution. System controller with webOS enables the GSPA series to be compatible with LG software solutions. The LG employee is remotely monitoring the GSPA series installed in a different place by using a cloud-based LG monitoring solution. System controller with webOS enables the GSPA series to be compatible with LG software solutions.
    * The availability of the 'LG ConnectedCare' service differs by region, and it needs to be purchased separately. So please contact the LG sales representative in your region for more details.
    * The items that can be monitored by LG ConnectedCare : Main Board (Temp., Signal Status, FPGA Ver, Ethernet Connection Status), Receiving Card (Temp., LED Power)
    * Actual GUI may vary in different webOS versions.
    * LG Software solutions needs to be purchased separately.
    Close
    PHYSICAL PARAMETERS
    • Pixel Configuration
      Single SMD
      Pixel Pitch(mm)
      P6.67
    • Module Resolution (WxH)
      72 x 48
      Module Dimensions(WxH,mm)
      480 x 320
    • Weight per Module (kg)
      1.65
      No. of Modules per Cabinet (WxH)
      2 x 3
    • Cabinet Resolution (WxH)
      144 x 144
      Cabinet Dimensions (W x H x D, mm)
      960 x 960 x 68
    • Cabinet Surface Area (㎡)
      0.9216
      Weight per Cabinet (kg/unit)
      20.5
    • Weight per Square Meter (kg/m2)
      22.5
      Physical Pixel Density (pixels/㎡)
      22,500
    • Flatness of Cabinet (mm)
      ±0.5
      Cabinet Material
      Aluminum
    • Service access
      Front & Rear
    OPTICAL SPECIFICATIONS
    • Brightness (After Calibration, nit)
      Max. 8,000
      Color Temperature (K)
      3,200 ~ 9,300
    • Visual Viewing Angle (Horizontal)
      160
      Visual Viewing Angle (Vertical)
      140
    • Brightness Uniformity
      0.97
      Color Uniformity
      ±0.003 Cx, Cy
    • Contrast Ratio
      15,000 : 1
      Processing Depth (bit)
      14 (HDR10, HDR10 Pro)
    ELECTRICAL SPECIFICATIONS
    • Power Consumption (W/Cabinet, Max.)
      580
      Power Consumption (W/Cabinet, Avg.)
      193
    • Power Consumption (W/㎡, Max.)
      630
      Heat Dissipation (BTU/h/Cabinet, Max.)
      1,583
    • Heat Dissipation (BTU/h/Cabinet, Avg.)
      526
      Heat Dissipation (BTU/h/m2, Max.)
      1,720
    • Power Supply (V)
      100 to 240
      Frame Rate (Hz)
      50 / 60
    • Refresh Rate (Hz)
      3,840
    OPERATION SPECIFICATIONS
    • LED Lifetime (Half brightness)
      100,000
      Operating Temperature(℃)
      -30°C to +50°C
    • Operating Humidity
      10~90%RH
      IP rating Front
      IP66
    • IP rating Rear
      IP66
    Standard
    • Certification
      CE, CB, ETL, FCC, BIS, KC (TBD)
      Certification (Fire Protection)
      BS476 Part7 Class1
      & EN13501-1 Class B
    Environment
    • Environment
      'RoHS, REACH
    CONTROLLER
    • Controller
      CVGA / LCQT

    To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
