    LSAP009-U2 component-copyModelName
    LG MAGNIT

    Key Features

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (LSAP009-U2)
      AED
      AED
      LG Members Price
    Total
    Add to CompareAdd to CompareRemove Compare

    component-OBScountrySelectDesc

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (LSAP009-U2)
      AED
      AED
      LG Members Price
    Total
    LG MAGNIT

    Micro LED Display with
    Megapixel HELIOS LED Processing Platform

    A man is giving a presentation in front of a large LED screen. The screen displays automobile-related content with clear visibility. A man is giving a presentation in front of a large LED screen. The screen displays automobile-related content with clear visibility.
    * All images in this page are for illustrative purposes only.

    Powerful UI/UX with
    Megapixel HELIOS LED Processing Platform

    With the Megapixel HELIOS LED Processing Platform, LSAP now has the capability to utilize powerful UX and UI functionalities. Real-Time Mapping and Multi-User Control, Superior Color Control, Hyper-Speed Seam Correction using a game controller, and Monitoring and Diagnostics through connected diagnostics are all available.
    The MVR controller provides access to the features such as Real-Time Mapping and Multi-Use Control, Superior Color Control, Hyper-speed Seam Correction using a Game Controller, and Monitoring and Diagnostics using Connected Diagnostics. The MVR controller provides access to the features such as Real-Time Mapping and Multi-Use Control, Superior Color Control, Hyper-speed Seam Correction using a Game Controller, and Monitoring and Diagnostics using Connected Diagnostics.
    * Megapixel HELIOS LED Processing Platform needs to be purchased separately

    Enhanced Uniformity with
    LST (LG Surface Treatment) Technology

    LG MAGNIT's innovative Chip Transfer and Surface Treatment Technology enhances white uniformity and reduces color distortion from any angle, delivering true and accurate wide-angle viewing experiences. This technology ensures remarkable color uniformity, resulting in superior image quality.
    While conventional screens distort colors (appearing red) at different angles, MAGNIT displays accurate results from every viewing angle. While conventional screens distort colors (appearing red) at different angles, MAGNIT displays accurate results from every viewing angle.

    Achieving True Black with
    Direct Chip Mounting

    LG MAGNIT's advanced and precise method for direct bonding micro-sized chips onto circuit boards combined with the black coating technology, creates a stunning black expression that stands out compared to SMD-type LED displays. This makes it the ideal choice for displaying content that requires deep black color, ensuring that every image is rich, vibrant, and true to life.
    Traditional SMD-type LEDs have larger chips, and the casing color used for the LED chips gives the screen an overall gray appearance. In contrast, Micro LEDs directly embed micro-sized chips on the substrate, with the non-chip areas being black, resulting in better representation of black color. Traditional SMD-type LEDs have larger chips, and the casing color used for the LED chips gives the screen an overall gray appearance. In contrast, Micro LEDs directly embed micro-sized chips on the substrate, with the non-chip areas being black, resulting in better representation of black color.
    * Based on comparison against LG's conventional LED Signage

    Accurate Colors as Intended

    By carefully selecting an LED chip which is a key factor to determine color purity, its narrowed wavelength allows LG MAGNIT to show uniform colors across the screen. Furthermore, the enhanced Gamut Transfer technology supports it to describe colors close to the original color, which is essential for places where exact color representation is demanding.
    The Ferris wheel shines brightly with vibrant colors. The Ferris wheel shines brightly with vibrant colors.

    Care Less with Sturdy Design

    Through several layers of coated film, LSAP can protect its LED chips from risks caused by water drops, dust, static electricity or physical impacts. It also meets the fire regulations with BS 476 Part 7 Class 1 certification. Considering that it is usually installed in public places where many people come and go, its stability is vitally important to minimize unforeseen accidents.
    LSAP offers protection for LED chips from various factors like water drops, dust, static electricity, or physical impacts. Additionally, it has received BS 476 Part 7 Class 1 fire certification. LSAP offers protection for LED chips from various factors like water drops, dust, static electricity, or physical impacts. Additionally, it has received BS 476 Part 7 Class 1 fire certification.
    * Based on in-house testing in accordance with the certification criteria, or under actual operating conditions.
    Close
    PHYSICAL PARAMETERS
    • Pixel Configuration
      COB
      Pixel Pitch (mm)
      0.938
    • Module Resolution (W x H)
      320 x 120
      Module Dimensions (W x H, mm)
      300 x 112.5
    • Weight per Module (kg)
      0.19
      No. of Modules per Cabinet (W × H)
      2 × 3
    • Cabinet Resolution (W × H)
      640 × 360
      Cabinet Dimensions (W x H x D, mm)
      600x337.5x44.9
    • Cabinet Surface Area (m2)
      0.203
      Weight per Cabinet (kg/unit)
      7.6
    • Weight per Square Meter (kg/m2)
      37.5
      Physical Pixel Density (pixels/m2)
      1,137,778
    • Flatness of Cabinet (mm)
      ±0.5
      Cabinet Material
      Die-casting Aluminum
    • Service access
      Front and Rear
    OPTICAL SPECIFICATIONS
    • Max Brightness (After Calibration, nit)
      Max. 600
      Color Temperature (K)
      6,504K / 2,000~10,000K
    • Visual Viewing Angle (Horizontal)
      160°
      Visual Viewing Angle (Vertical)
      160°
    • Brightness Uniformity
      ≥ 95%
      Color Uniformity
      ±0.02Cx,Cy
    • Contrast Ratio
      Max. 100,000:1
      Processing Depth (bit)
      22bit Internal processing (HDR10)
    ELECTRICAL SPECIFICATIONS
    • Power Consumption (W/Cabinet, Max.)
      68
      Power Consumption (W/Cabinet, Avg.)
      47
    • Power Consumption (W/m2, Max.)
      336
      Heat Dissipation (BTU/h/Cabinet, Max.)
      232
    • Heat Dissipation (BTU/h/Cabinet, Avg.)
      160
      Heat Dissipation (BTU/h/m2, Max.)
      1146
    • Power Supply (V)
      100 to 240
      Frame Rate (Hz)
      23.98/24/25/29.97/30/50/59.94/60
    • Refresh Rate (Hz)
      3,840
    OPERATION SPECIFICATIONS
    • LED Lifetime (Half brightness)
      100,000
      Operating Temperature(℃)
      0° to +40°
    • Operating Humidity
      10-80%RH
      IP rating Front
      IP50
    • IP rating Rear
      IP20
    CERTIFICATION
    • Certification
      IEC 62368-1
      EMC Class A,
      , BS476 Part7 Class2Y
    Environment
    • Environment
      RoHS/REACH
    CONTROLLER
    • Controller
      MVR HEIOS
    SERIES
    • Series
      LSAP

    To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
