    LSBF025-GD component-copyModelName
    LSBF Indoor LED Series

    Key Features

    Choose your Pitch

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (LSBF025-GD)
      AED
      AED
      LG Members Price
    Total
    Add to CompareAdd to CompareRemove Compare

    component-OBScountrySelectDesc

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (LSBF025-GD)
      AED
      AED
      LG Members Price
    Total
    LSBF Indoor LED Series
    Find a Dealer

    LSBF Indoor LED Series

    There are large LED displays installed across three floors of a large shopping mall, prominently showcasing perfume advertisements. There are large LED displays installed across three floors of a large shopping mall, prominently showcasing perfume advertisements.
    * All images in this page are for illustrative purposes only.
    LSBF has a brightness of 600 nits, so it is clearly visible, even under strong light. LSBF has a brightness of 600 nits, so it is clearly visible, even under strong light.

    Brightness

    With a great brightness of 600 nits, it clearly delivers content and attracts public attention, making it ideal for achieving bright indoor visibility.
    LSBF consists of a total of 8 modules that create a single cabinet. LSBF consists of a total of 8 modules that create a single cabinet.

    Improved Flatness and Easy Maintenance

    LSBF is composed of four LSBE modules that form one cabinet with two modules each, allowing it to create a seamless screen. Also, it allows for easy maintenance.
    The frame of LSBF is composed of aluminum. The frame of LSBF is composed of aluminum.

    Durable Frame Design

    LSBF incorporates an aluminum cabinet that enhances durability, and its high-strength frame, surpassing that of plastic, allows for stable operation.

    54" & 27" Combination Installation Available

    The LSBF (54") and LSBE (27") models, sharing the same product platform, provide flexible matrix combinations for various spatial configurations. The compatibility between the 54" and 27" models enables versatile sizing options according to space requirements, allowing for installation.
    The 27" LSBE and the 54" LSBF are compatible and installed on the shopping mall wall in appropriate sizes. The 27" LSBE and the 54" LSBF are compatible and installed on the shopping mall wall in appropriate sizes.

    Compatibility with LG Software Solutions

    When connected with LG's CVBA system controller, the LSBF series is compatible with LG software solutions including SuperSign CMS, LED Assistant, and ConnectedCare, which help customers operate their own business properly.
    The LG employee is remotely monitoring the LSBF series installed in a different place by using a cloud-based LG monitoring solution. System controller with webOS enables LSBF series to be compatible with LG software solutions. The LG employee is remotely monitoring the LSBF series installed in a different place by using a cloud-based LG monitoring solution. System controller with webOS enables LSBF series to be compatible with LG software solutions.
    * The availability of the 'LG ConnectedCare' service differs by region, and it needs to be purchased separately. So please contact the LG sales representative in your region for more details.
    * The items that can be monitored by LG ConnectedCare : Main Board (Temp., Signal Status, FPGA Ver, Ethernet Connection Status), Receiving Card (Temp., LED Power)
    * Actual GUI may vary in different webOS versions.
    * LG Software solutions needs to be purchased separately.
    Close
    PHYSICAL PARAMETERS
    • Pixel Configuration
      Single SMD
      Pixel Pitch(mm)
      2.50
    • Module Resolution (WxH)
      120x135
      Module Dimensions(WxH,mm)
      300x337.5x13
    • Weight per Module (kg)
      0.95
      No. of Modules per Cabinet (WxH)
      4 x 2
    • Cabinet Resolution (WxH)
      480x270
      Cabinet Dimensions (W x H x D, mm)
      1200x675x72
    • Cabinet Surface Area (㎡)
      0.810
      Weight per Cabinet (kg/unit)
      23.0
    • Weight per Square Meter (kg/m2)
      28.0
      Physical Pixel Density (pixels/m2)
      160,000
    • Flatness of Cabinet (mm)
      ±0.3
      Cabinet Material
      Die-casting Aluminum
    • Service access
      Front
    OPTICAL SPECIFICATIONS
    • Max Brightness (After Calibration, nit)
      600
      Color Temperature (K)
      3,000 - 10,000
    • Visual Viewing Angle (Horizontal)
      160
      Visual Viewing Angle (Vertical)
      150
    • Brightness Uniformity
      97%
      Color Uniformity
      ±0.003Cx,Cy
    • Contrast Ratio
      5,000:1
      Processing Depth (bit)
      14
    ELECTRICAL SPECIFICATIONS
    • Power Consumption (W/Cabinet, Max.)
      372
      Power Consumption (W/Cabinet, Avg.)
      145
    • Power Consumption (W/m2, Max.)
      460
      Heat Dissipation (BTU/h/Cabinet, Max.)
      1,270
    • Heat Dissipation (BTU/h/Cabinet, Avg.)
      495
      Heat Dissipation (BTU/h/m2, Max.)
      1,570
    • Power Supply (V)
      100 to 240
      Frame Rate (Hz)
      50 / 60
    • Refresh Rate (Hz)
      3,840
    OPERATION SPECIFICATIONS
    • LED Lifetime (Half brightness)
      100,000
      Operating Temperature(℃)
      -20℃ to +40℃
    • Operating Humidity
      10~80%RH
      IP rating Front
      IP50
    • IP rating Rear
      IP50
    Standard
    • Certification
      CE, FCC, cTUVus, CB, KC, CCC
    Environment
    • Environment
      RoHS, REACH
    CONTROLLER
    • Controller
      CVBA
    SERIES
    • Series
      LSBF

    To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
