    LSCC012-CZF component-copyModelName
    LG Indoor LED, LSCC012-CZF, 2025

    Key Features

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (LSCC012-CZF)
      AED
      AED
      LG Members Price
    Total
    Add to CompareAdd to CompareRemove Compare

    component-OBScountrySelectDesc

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (LSCC012-CZF)
      AED
      AED
      LG Members Price
    Total
    LG Indoor LED, LSCC012-CZF, 2025

    LSCC Ultra Slim Series

    A large LED is installed on the corner wall of the mall near the display window. Although it’s positioned on a wall with an angle, it displays vivid images that look smooth and continuous, without any awkward breaks. A large LED is installed on the corner wall of the mall near the display window. Although it’s positioned on a wall with an angle, it displays vivid images that look smooth and continuous, without any awkward breaks.
    *All images in this page are for illustrative purposes only.
    The LSCC series cabinet is designed with an ultra-slim depth of 33.6mm and a lightweight build of 5kg.

    Ultra Slim Depth and Lightweight

    The ultra slim design, with a cabinet thickness of just 33.6 mm and a weight of only 5.0 kg, is the standout feature of this product. This sleek and lightweight design allows the LSCC series to be seamlessly installed in a variety of venues, harmonizing effortlessly with its surroundings.
    The LSCC series with 4K HDR quality displays content more vividly and brightly compared to the one on the left.

    Stunning Picture Quality with 4K HDR

    All models of the LSCC series deliver 4K HDR while maintaining 800 nits of brightness. Not only do they offer a great contrast ratio and wide viewing angle, but the 4K HDR feature also ensures stunning picture quality.

    * This feature is only supported when using LG’s controller, CVCA.
    The LSCC series, with its enhanced power consumption, offers higher energy efficiency.

    Superior Energy Efficiency

    The LSCC series improves power consumption by 16% to 25%, depending on pitch models, delivering both energy efficiency and lower operating costs. Consequently, the LSCC series stands as the second most energy-efficient model in LG’s indoor PKG lineup as of Aug 2024.

    * Power consumption improvement is compared to the LG LSCB model.
    The LSCC series is securely installed using safety wires attached to the wire holders on the back of the module.

    Attachable Wire Hooks for Modules

    All modules come with wire holders attached to the back, allowing wires to be secured for installation on ceilings, walls, or other surfaces as needed. Simply attach a safety wire to prevent the module from falling, providing safety

    * Wires can be ordered separately as accessories.
    The content with the 90° corner option is shown without any interruptions even when installed on a corner.

    90° Corner Design Available

    By adding the 90° corner option, the LSCC series seamlessly integrates into any space, delivering smooth content to customers. Additionally, elegantly curved LED screens can be implemented as an option.

    Compatibility with LG Software Solutions

    When connected with LG's CVCA system controller, the LSCC series is compatible with LG software solutions including SuperSign CMS, LED Assistant, and ConnectedCare, which help customers operate their own business deftly.
    The LG employee is remotely monitoring the LSCC series installed in a different place by using a cloud-based LG monitoring solution. System controller with webOS enables the LSCC series to be compatible with LG software solutions. The LG employee is remotely monitoring the LSCC series installed in a different place by using a cloud-based LG monitoring solution. System controller with webOS enables the LSCC series to be compatible with LG software solutions.
    * The availability of the 'LG ConnectedCare' service differs by region, and it needs to be purchased separately. So please contact the LG sales representative in your region for more details.
    * The items that can be monitored by LG ConnectedCare : LG webOS System Controller (Temp., Signal Status, FPGA Ver, Ethernet Connection Status), Receiving Card (Temp., LED Power) CLOSE
    Close
    PHYSICAL PARAMETERS
    • Pixel Configuration
      Single SMD
      Pixel Pitch(mm)
      1.25
    • Module Resolution (WxH)
      240x135
      Module Dimensions(WxH,mm)
      300x168.75
    • Weight per Module (kg)
      0.6
      No. of Modules per Cabinet (WxH)
      1x2
    • Cabinet Resolution (WxH)
      240x270
      Cabinet Dimensions (W x H x D, mm)
      300x337.5x61.8（MAX）
      (Cabinet Mounting depth changs for different curve)
    • Cabinet Surface Area (㎡)
      0.1
      Weight per Cabinet (kg/unit)
      3.5（weight changs for different curve）
    • Weight per Square Meter (kg/㎡)
      33.98
      Physical Pixel Density (pixels/㎡)
      640,000
    • Flatness of Cabinet (mm)
      ±0.1
      Cabinet Material
      Die-casting Aluminum
    • Service access
      Front
    OPTICAL SPECIFICATIONS
    • Brightness (After Calibration, nit)
      Max. 800
      Color Temperature (K)
      3500-9000K(default:6500K)
    • Visual Viewing Angle (Horizontal)
      160
      Visual Viewing Angle (Vertical)
      160
    • Brightness Uniformity
      97%
      Color Uniformity
      ±0.003CxCy
    • Contrast Ratio
      5,000 : 1
      Processing Depth (bit)
      14 (HDR10, HDR10 Pro)
    ELECTRICAL SPECIFICATIONS
    • Power Consumption (W/Cabinet, Max.)
      54
      Power Consumption (W/Cabinet, Avg.)
      18
    • Power Consumption (W/㎡, Max.)
      533
      Heat Dissipation (BTU/h/Cabinet, Max.)
      184
    • Heat Dissipation (BTU/h/Cabinet, Avg.)
      61
      Heat Dissipation (BTU/h/m2, Max.)
      1,820
    • Power Supply (V)
      100 to 240
      Frame Rate (Hz)
      50 / 60
    • Refresh Rate (Hz)
      3,840
    OPERATION SPECIFICATIONS
    • LED Lifetime (Half brightness)
      100,000
      Operating Temperature(℃)
      -10℃ to +45℃
    • Operating Humidity
      0-80%RH
      IP rating Front
      IP30
    • IP rating Rear
      IP30
    Standard
    • Certification
      CE, FCC, ETL, EMC Class-A
      Certification (Fire Protection)
      BS476 Part7 Class1, EN13501-1
    Environment
    • Environment
      RoHS,REACH
    CONTROLLER
    • Controller
      CVCA
    90 degree corner cut
    • 90 degree corner cut
      X
