    Indoor LED Series, LSGA026-GK
    Find a Dealer

    LSGA Indoor LED Series

    At the airport, a massive fit-to-wall LED screen is installed, and the screen displays flight times and Ads clearly. At the airport, a massive fit-to-wall LED screen is installed, and the screen displays flight times and Ads clearly.
    * All images in this page are for illustrative purposes only.

    Fast Installation

    Various factors such as safety knobs, fast locks, handles, and positioning pins facilitate the installer in smoothly setting up and dismantling LED screens without the requirement of extra tools.
    The cabinet parts, including 'Safety Knobs', 'Easy Handle', 'Fast Lock & One Hand Operation', and 'Positioning Pins', are depicted in an enlarged manner. The cabinet parts, including 'Safety Knobs', 'Easy Handle', 'Fast Lock & One Hand Operation', and 'Positioning Pins', are depicted in an enlarged manner.

    Easy Maintenance

    The LSGA series features a lock fixing method that requires no additional tools, simplifying the process of replacing LED modules or power/data units and resulting in time and cost savings for maintenance.
    It is demonstrating that a simple Lock Fixing method allows for convenient replacement of the cabinet's Power/Data Unit. It is demonstrating that a simple Lock Fixing method allows for convenient replacement of the cabinet's Power/Data Unit.
    The screen is tailored to fit the wall, utilizing two different cabinet sizes. The screen is tailored to fit the wall, utilizing two different cabinet sizes.

    Two Cabinet Options

    The LSGA series offers two cabinet sizes to accommodate customer demands for various screen sizes.
    Capable of front and rear installation depending on the customers' needs. Capable of front and rear installation depending on the customers' needs.

    Front and Rear Serviceability

    The product offers either front access or rear access, allowing customers to choose installation options according to their environment and minimizes limitations in installation and maintenance.
    Close
    PHYSICAL PARAMETERS
    • Pixel Configuration
      Single SMD
      Pixel Pitch(mm)
      2.6
    • Module Resolution (WxH)
      96x96
      Module Dimensions(WxH,mm)
      250x250
    • Weight per Module (kg)
      0.55
      No. of Modules per Cabinet (WxH)
      2x4
    • Cabinet Resolution (WxH)
      192x384
      Cabinet Dimensions (W x H x D, mm)
      500x1,000x90
    • Cabinet Surface Area (m2)
      0.5
      Weight per Cabinet (kg/unit)
      10
    • Weight per Square Meter (kg/m2)
      20
      Physical Pixel Density (pixels/m2)
      147,456
    • Flatness of Cabinet (mm)
      ±0.1
      Cabinet Material
      Magnalium
    • Service access
      Front & Rear
    OPTICAL SPECIFICATIONS
    • Max Brightness (After Calibration, nit)
      800
      Color Temperature (K)
      3,200~9,300
    • Visual Viewing Angle (Horizontal)
      160
      Visual Viewing Angle (Vertical)
      140
    • Brightness Uniformity
      0.98
      Color Uniformity
      ±0.003Cx,Cy
    • Contrast Ratio
      6,500:1
      Processing Depth (bit)
      14
    ELECTRICAL SPECIFICATIONS
    • Power Consumption (W/Cabinet, Max.)
      196
      Power Consumption (W/Cabinet, Avg.)
      66
    • Power Consumption (W/m2, Max.)
      392
      Heat Dissipation (BTU/h/Cabinet, Max.)
      535
    • Heat Dissipation (BTU/h/Cabinet, Avg.)
      180
      Heat Dissipation (BTU/h/m2, Max.)
      1,070
    • Power Supply (V)
      100 to 240
      Frame Rate (Hz)
      50 / 60
    • Refresh Rate (Hz)
      3,840
    OPERATION SPECIFICATIONS
    • LED Lifetime (Half brightness)
      100,000
      Operating Temperature(℃)
      -10℃ to +40℃
    • Operating Humidity
      10~80%RH
      IP rating Front
      IP40
    • IP rating Rear
      IP20
    Standard
    • Certification
      CE, FCC, cTUVus, CB
    Environment
    • Environment
      RoHS, REACH
    CONTROLLER
    • Controller
      CVGA

    To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
