    Ceiling Concealed AC 2.8 KW ARNU09GL1G4 Series
    Find a Dealer
    Ceiling Concealed Duct1 Ceiling Concealed Duct2

    Ceiling Concealed Duct

    Invisible cooling solution suitable for applications that require interior aesthetics
    Operation for Multiple Rooms1 Operation for Multiple Rooms2

    Operation for Multiple Rooms

    Using a spiral duct (embedded or flexible type) and stream chamber, it is possible to operate cooling and heating for several rooms simultaneously.
    E.S.P. Control1 E.S.P. Control2

    E.S.P. Control

    E.S.P. (External Static Pressure) control function can make air volume controlled easily with remote controller. The BLDC motor can control fan speed and air volume regardless of the external static pressure. No additional accessories are necessary to control air flow.
    Two Thermistors Control1 Two Thermistors Control2

    Two Thermistors Control

    The indoor temperature can be checked using the thermistors in the remote controller, as well as from the indoor unit to sensor temperature difference in one place. Two thermistors can optimize indoor air temperature for a more comfortable environment.
    Minimized Height1 Minimized Height2

    Minimized Height

    New mid-static ducts provide ideal solution for installation in limited space.
    Flexible Installation <br>(Low Static Duct Only)1 Flexible Installation <br>(Low Static Duct Only)2

    Flexible Installation
    (Low Static Duct Only)

    The new low static duct allows the air intake at the rear or bottom under installation condition.
    Ceiling Concealed Duct Line Up1 Ceiling Concealed Duct Line Up2

    Ceiling Concealed Duct Line Up

    Contact Us1 Contact Us2

    Contact Us

    Please contact us for more information on the product and we will get in touch with you soon.
    Learn More
    Close
    CAPACITY
    • Cooling - kW
      2.8
      Cooling - kcal/h
      2,400
    • Cooling - Btu/h
      9,600
      Heating - kW
      3.2
    • Heating - kcal/h
      2,800
      Heating - Btu/h
      10,900
    POWER INPUT
    • Power Input(H / M / L) - W
      39 / 29 / 24
    CASING
    • Casing
      Galvanized Steel Plate
    DIMENSIONS (W × H × D)
    • Body - ㎜
      700 × 190 × 700
      Body - inch
      27-9/16 × 7-15/32 × 27-9/16
    COIL
    • Rows × Columns × FPI
      2 × 11 × 14
      Face Area - m2
      0.12
    FAN
    • Type
      Sirocco Fan
      Motor Output × Number - W × No.
      19 × 1
    • Running Current - A
      0.4
      Air Flow Rate(H / M / L) (High Mode-Factory Set) - m3/min
      9.0 / 7.0 / 5.5
    • Air Flow Rate(H / M / L) (High Mode-Factory Set) - ft3/min
      320 / 250 / 200
      External Static Pressure (High Mode) - ㎜Aq(Pa)
      2.54 (25)
    • Air Flow Rate (H / M / L) (Standard Mode) - m3/min
      9.0 / 7.0 / 5.5
      Air Flow Rate (H / M / L) (Standard Mode) - ft3/min
      320 / 250 / 200
    • External Static Pressure (Standard Mode) - ㎜Aq(Pa)
      0 (0)
      Drive
      Direct
    • Motor type
      BLDC
    TEMPERATURE CONTROL
    • Temperature Control
      Microprocessor, Thermostat for cooling and heating
    SOUND ABSORBING THERMAL INSULATION MATERIAL
    • Sound Absorbing Thermal Insulation Material
      Foamed polystyrene
    SAFETY DEVICE
    • Safety Device
      Fuse
    PIPE CONNECTIONS
    • Liquid Side - ㎜(inch)
      ? 6.35 (1/4)
      Gas Side - ㎜(inch)
      ? 12.7 (1/2)
    • Drain Pipe(Internal Dia.) - ㎜(inch)
      ? 25.4 (1)
    NET WEIGHT
    • Body - kg(lbs)
      17.5 (38.6)
    SOUND PRESSURE LEVELS
    • H / M / L - dB(A)
      28 / 25 / 22
    SOUND POWER LEVELS
    • H / M / L - dB(A)
      53 / 49 / 45
    POWER SUPPLY
    • Power Supply - ?, V, Hz
      1, 220-240, 50
      1, 220, 60
    REFRIGERANT CONTROL
    • Refrigerant Control
      EEV
    TRANSMISSION CABLE
    • Transmission Cable - ? × Cores
      1.0-1.5 × 2C
