    Discontinued
    22LW760M (NA) component-copyModelName
    LW760M Series

    Key Features

    component-OBScountrySelectDesc

    LW760M Series
    Panel
    • Size
      22" class (21.6" diagonal)
      Backlight Type
      Edge LED
    • Resolution
      1,366 x 768 (HD)
    Broadcasting System
    • Analog
      Yes (NTSC)
      Digital
      Yes (ATSC)
    Video
    • Triple XD Engine
      Yes
      Real Cinema 24p (3:3 Pull down)
      Yes
    • Aspect Ratio
      Yes (16:9, Just Scan, Set By Program, 4:3, Zoom, Cinema Zoom1)
    Audio
    • Audio Output / Speaker System
      5W + 5W / 2.0 ch
      Sound Mode
      Yes (Standard, News, Music, Cinema, Sport, Game)
    Side Interface
    • HDMI In
      2
      USB (2.0)
      2
    • AV In
      Yes
    Rear Interface
    • RF In
      1
      Audio Out
      1 (Optical)
    • Service Only Port
      1 (Common use PTC & CPU Service, 3.5mm phone jack)
      LAN Port
      1
    • Speaker Out/Line Out
      1 (3.5mm jack)
      Pillow Speaker interface
      1 (6pin)
    • MPI Port
      1 (RJ-12)
    Cabinet
    • Bezel Width (Left/Right, Upper, Bottom) : on bezel (mm)
      14.7/14.7, 16.2, 20.8
      Bezel Width (Left/Right, Upper, Bottom) : off bezel (mm)
      13/13, 14.6, 19.2
    • VESA Compatible
      75mm x 75mm
      Weight
      6.4 lbs
    • Weight (Box)
      8.6 lbs
      WxHxD (w/o stand)
      20” x 12.4” x 2.1”
    • WxHxD (Box)
      22.8” x 15.1” x 5.5”
    General
    • Region
      North America
    • Datasheet
      • LG_SPEC-SHEET_LW760M_081603_PR.pdf
