    Discontinued
    65LV570H (NA) component-copyModelName
    LV570H Series

    Key Features

    component-OBScountrySelectDesc

    LV570H Series
    Display
    • Diagonal Size
      64.8"
      Type
      Edge LED
    • Resolution
      1,920 x 1,080 (FHD)
    Design
    • Color
      Black
      Stand
      (20/45/90°) Swivel
    Broadcasting System
    • Analog
      NTSC
      Digital
      ATSC / VSB / Clear QAM
    Video
    • Triple XD Engine
      ?
      Real Cinema 24p (3:3 Pull down)
      ?
    • Aspect Ratio
      ? 5 modes (16:9, Just Scan, Set By Program, 4:3, Zoom)
    Audio
    • Audio Output / Speaker System
      10W + 10W / 2.0 ch
      Sound Mode
      ? 6 modes (Standard, News, Music, Cinema, Sport, Game)
    Feature
    • Installation
      EZ-Manager Wizard (for Initial Configuration), USB Cloning
      Management
      Wake on RF, Self Diagnostics via USB, TVLink Interative, IR Out (MPI Jack), Multi IR Code
    • Hospitality
      Installer Menu, Welcome Screen (Splash Image), Logical Channel Map (LCM), External Speaker Out, Instant On, RJP Compatibility, b-LAN? embedded
    Interface
    • Side
      HDMI (2), USB 2.0
      Rear
      RF In, AV In, Digital Optical Audio Out, HDMI Input, RGB In, PC Audio Input, RJ45(2), TV link Configuration (Phone Jack Type), External Speaker Out, MPI Port, Debug
    Dimension
    • Vesa (mm)
      300 x 300
      W x H x D / Weight (without stand)
      57.5" x 33.4" x 1.5" / 63.5lb
    • W x H x D / weight (with stand)
      57.5" x 35.4" x 11.6" / 75.0lb
      W x H x D / weight (Carton)
      63.1" x 39.5" x 6.9" / 90.4lb
    General
    • Region
      North America
    • Datasheet
      • LV570H_NA_page_170525.pdf
    • Software

      To download Software, Please visit the Software Download Page (Click).

    • Manual

      To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
