    Discontinued
    65UT770H (NA) component-copyModelName
    UT770H Series

    Key Features

    Choose your Size

    component-OBScountrySelectDesc

    UT770H Series
    Display
    • Inch
      65
      Type
      Nanocell (Nano Bezel)
    • Resolution
      3,840 x 2,160 (UHD)
      Backlight Unit Type
      Edge
    • Brightness (nit)
      400
    Broadcasting System
    • TV Reception
      ATSC / Clear QAM/VSB, Analog NTSC
    Video
    • HDR (Dolby Vision / 10 Pro / HLG)
      No / Yes / Yes
    Audio
    • Audio Output
      10W + 10W
      Speaker System
      2.0 ch
    • DOLBY ATMOS
      Yes
      One Touch Sound Tuning
      Ready
    • LG Sound Sync
      Bluetooth required
    Hospitality Solution
    • Solution Type
      Pro:Centric (Smart, V, Direct), Quick Menu 3.0
      Data Streaming (IP & RF)
      Yes
    • HCAP (GEM/FLASH/HTML)
      ※ Service Carousel (TLL/XML)
      GEM / HTML5
      IP Return path
      Yes
    • Multicast / Unicast ready
      Yes / Yes
      webRTC (Real Time Communication)
      Yes
    • Pro:Centric Application (version)
      PCA3.8
      Pro:Centric Server
      PCS400R
    • DRM
      Pro:Idiom (S/W Type), Pro:Idiom Media
    FEATURES
    • Hospitality
      Hotel Mode(Installer Menu), Welcome Screen(Splash Image), Insert Image, One Channel Map(LCM), External Speaker Out (Int / Ext Variable / Fixed), Instant ON, V-Lan Tag, RJP (Remote Jack Pack) Compatibility, Auto Off / Sleep Timer, Motion Eye Care
    Jack Interface
    • Set Side
      HDMI In 2.0, USB 2.0 (2)
      Set Rear
      HDMI In (HDCP, 2.0), AV In (Phone Jack Type), RS-232C (Control & Service), RJ45 (Usage Purpose : 2 (Ethernet, Aux)), RF In(Dual b-Lan), Digital Audio Out (Optical), External Speaker Out (3.5mm Phone Jack) : 1 (Spk-out fixed 0.01W~1.00W and line out), TV link Configuration(phone jack type) : 1 (b-LAN Service), MPI Port(RJ12 jack), Debug (Phone Jack Type) : 1(CPU/PTC)
    Dimension(Unit: mm/kg)
    • Vesa
      300 x 300
      W x H x D / Weight (with stand)
      1,451 x 910 x 323.7 / 25.8
    • W x H x D / Weight (without stand)
      1,451 x 840 x 64 / 24.1
      W x H x D / Weight (Shipping)
      1,600 x 1,035 x 207 / 33.3
    Power(Unit : Watts)
    • Power Supply (Voltage, Hz)
      AC 120 V ~ 50 / 60 Hz
      Typical
      169W
    • Stand-by
      Under 0.5W
    General
    • Region
      North America
    • Dimension
      • [Dimension] 65UT770H (NA).dwg
      • [Dimension] 65UT770H (NA).pdf
    • Datasheet
      • UT770H(NA)_Datasheet_Hotel TV_Commercial TV_ID_190920_low.pdf
    • Software

      To download Software, Please visit the Software Download Page (Click).

    • Manual

      To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
