    Discontinued
    WV30 Series

    Key Features

    component-OBScountrySelectDesc

    WV30 Series
    Panel
    • Screen Size
      47"
      Resolution
      1,366 x 768 (HD) , 1,920x 1,080 at Video Wall
    • Brightness
      800
    Connectivity - Intput
    • Digital
      DVI, HDMI/DVI with HDCP
      Analog
      RGB(1), Component(BNC, 1), AV(BNC, 1)
    • Audio
      PC Audio In (1), AV/Component Audio(RCA,1)
      External Control
      RS232C (1), RJ45 (1), IR Receiver (1)
    • USB
      USB (1)
    Connectivity - Output
    • Digital
      DVI-D(1)
      Analog
      RGB
    • Audio
      External Speaker
      External Control
      RS232C
    Physical Specification
    • Bezel Width
      3.9 (left/top) / 2.4 (right/bottom) mm
      Monitor Dimension (W x H x D)
      104.68cm X 59.16cm X 9.11cm
    • Weight (Head)
      29kg
      VESA? Standard Mount Interface
      800mm x 400mm
    Environment Conditions
    • Operation Temperature
      0°C to 40°C
      Operation Humidity
      10 % to 80 %
    Power
    • Power Supply
      100-240V~, 50/60Hz
    Power Consumption
    • Typical / Smart Energy Saving
      160W (Typ), 110W (SES)
      DPMS
      1.0W (RGB), 1.0W (HDMI)
    • Power off
      0.5 W
    Standard(Certification)
    • Safety
      UL / c-UL / CB / TUV / KC
      EMC
      FCC / CE / KCC / VCCI / JQA
    • ErP / Energy Star
      Yes / Yes (Energy Star 5.1)
    Media Player Compatibility
    • Slot PC compatible (optional)
      No
      External Media player Attatchable
      Yes
    Software Compatibility
    • Supersign Compatibility
      Elite-w / Elite-w lite (Only control)
    Accessory
    • Basic
      Remote Controller, Power cable, RGB Cable, DVI Cable, Manual, IR Receiver, RS-232C Cable, Tiling Guide, Screw, Ring Core
      Optional
      Wall Mount
    • Dimension
      • 47WV30.dwg
    • Datasheet
      • Leaflet_WV30.pdf
    • Software
      • WV30_FLASH_V03.10.20(7121)_USB.epk
      • WV30_MICOM_V2.05.2_USB.epk
    • Software

      To download Software, Please visit the Software Download Page (Click).

    • Manual

      To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
