    49VL5F-A component-copyModelName
    49'' 450 nits FHD Slim Bezel Video Wall

    Key Features

    Choose your Size

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (49VL5F-A)
      $
      $
      LG Members Price
    Total
    Add to CompareAdd to CompareRemove Compare

    component-OBScountrySelectDesc

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (49VL5F-A)
      $
      $
      LG Members Price
    Total
    49" 450 nits FHD Slim Bezel Video Wall
    Contact Us
    00_cover_1553047508052 00_cover_1553047508052

    Incredible Immersion with Ultra-Narrow Bezel

    The VL5F series provides all-encompassing screen immersion thanks to its ultra-narrow 3.5 mm bezel-to-bezel, while its outstanding IPS panel delivers a clear image from any angle. With its extremely attractive and highly functional design, it can be used to deliver advertising and information in a variety of business environments.
    01_Seamless-Large-Screens_1553047563854 01_Seamless-Large-Screens_1553047563854
    Achieving Incredible Immersion

    Seamless Large Screens with Ultra-Narrow Bezel

    The ultra-narrow bezel creates a visually stunning digital wall to effectively deliver dynamic content and immerse the viewers. The large screen it generates is enough to captivate the attention of passersby.
    VL5F-A-03-Image Gap Reduction-Narrow Bezel-Video Wall-Digital Signage-ID_1568849829092 VL5F-A-03-Image Gap Reduction-Narrow Bezel-Video Wall-Digital Signage-ID_1568849829092
    Achieving Incredible Immersion

    Image Gap Reduction

    The VL5F series includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a seamless viewing experience.
    03_Higher-Viewing-Angle_1553047746531 03_Higher-Viewing-Angle_1553047746531
    Vivid and Dynamic Picture Quality

    Higher Viewing Angle

    Large screens are usually positioned higher than human-eye level, making uniform picture quality essential for video walls. The viewing angle of the VL5F series is high enough to display vivid colors throughout the screen with no distortion.
    04_Wider-Viewing-Angle_1553048095967 04_Wider-Viewing-Angle_1553048095967
    Vivid and Dynamic Picture Quality

    Wider Viewing Angle

    It is well known that LG IPS panel technology enables better control of liquid crystals, which in turn allows the screen to be viewed from virtually any angle. Because of this, the VL5F series captures the attention of and captivates more viewers with lifelike colors, regardless of their viewing position.
    05_Easy-Color-Adjustment_1553048295554 05_Easy-Color-Adjustment_1553048295554
    User Convenience

    Easy Color Adjustment

    Depending on the content, the color temperature of the display can be easily adjusted in increments of 100K using a remote control.
    06_Simple-White-Balance-Adjustment_1553048364696 06_Simple-White-Balance-Adjustment_1553048364696
    User Convenience

    Simple White Balance Adjustment

    In conventional video walls, white balance was adjustable only in full-white mode, but the VL5F series allows you to modify each value of grey scale to achieve more detailed and precise white balance adjustment.
    07_User-Friendly-Menu-Structure_1553048511803 07_User-Friendly-Menu-Structure_1553048511803
    User Convenience

    User-Friendly Menu Structure

    The menu structure has been optimized for commercial use. It simplifies approach flows and groups similar functions together, adopting a more intuitive GUI for ease of use. This way, users can avoid having to do trial-anderror when exploring desired functions and managing displays.
    08_Intuitive-GUI_1553048642820 08_Intuitive-GUI_1553048642820
    User Convenience

    Intuitive GUI

    The GUI(Graphic User Interface) is carefully designed with a four-way navigation remote control that lets users easily switch to other settings. Also, it adopts a larger font for better visibility, which is necessary when users want to control displays from relatively far distances.
    ENERGY STAR? Certified

    ENERGY STAR? Certified

    Close
    Panel
    • Screen Size
      49"
      Panel Technology
      IPS
    • Aspect Ratio
      16:9
      Native Resolution
      1,920 x 1,080 (FHD)
    • Brightness(Typ.,cd/m2)
      450
      Contrast Ratio
      1,300:1
    • Dynamic CR
      500,000 : 1 (The luminosity ratio of Full Black/Full White color on video input condition.)
      Viewing Angle (H x V)
      178 x 178
    • Response Time
      8 ms (G to G)
      Surface Treatment (Haze)
      3%
    • Life Time (Typ.)
      60,000 Hrs
      Operation Hours
      24 Hrs
    • Orientation
      Landscape & Portrait
    Connectivity
    • Input
      HDMI, DP, DVI-D, RGB, Audio, USB 2.0
      Output
      DP, Audio
    • External Control
      RS232C In/out, RJ45 (LAN) In, IR In
    Mechanical Specification
    • Bezel Width
      2.25 mm (T/L), 1.25 mm (B/R)
      Monitor Dimensions (W × H × D)
      1,077.6 x 607.8 x 89.7 mm
    • Weight (Head)
      17.8 kg
      Carton Dimensions (W × H × D)
      1,214 x 778 x 263 mm
    • Packed Weight
      22.8 kg
      VESA? Standard Mount Interface
      600 x 400 mm
    Environment Conditions
    • Operation Temperature
      0°C to 40°C
      Operation Humidity
      10 % to 80 %
    Power
    • Power Supply
      100-240V~, 50/60Hz
      Power Type
      Built-In Power
    Power Consumption
    • Typ.
      90 W
      Max.
      110 W
    • Smart Energy Saving
      55 W
    Certification
    • Safety
      CB / NRTL
      EMC
      FCC Class "A" / CE / KC
    • ErP / Energy Star
      Yes (EU Only) / Yes (Energy Star 8.0, US Only)
    Media Player Compatibility
    • OPS type compatible
      No
    Software Compatibility
    • Content Management Software
      SuperSign CMS
      Control and Monitoring Software
      SuperSign Control/Control+
    Accessory
    • Basic
      Remote Controller, Power Cord, RS232C Cable, LAN Cable, DP Cable, IR Receiver, Guide Bracket, Screws, Manual
      Optional
      Wall Mount (Landscape: WM-L640V, Portrait: WM-P640V)
    • Dimension
      • [Dimension]49VL5F.dwg
      • [Dimension]49VL5F.pdf
    • Datasheet
      • VL5F Series_Datasheet(low)_LG Video Wall_200220.pdf
    • Software

      To download Software, Please visit the Software Download Page (Click).

    • Manual

      To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).

    To access more technical documentation and downloads, please visit the LG B2B Partner Portal.

    Find a dealer to help with service for sales, installation, and after sales.
    Business Unit is required
    Address Unit is required.
    • sales
    • install
    • service
    Please retry to enter zip code.

    There is no data. Please retry to enter zip code.

    Compare

    0
    Compare 0
    Product design, features and specifications are subject to change without notice and may also differ based on your region of purchase. Screen images simulated and/or dramatized. Some features in videos may not be available on all models. Please refer to the TECHNICAL SPECIFICATIONS tab for a complete list of features by model.
