    55'' 500 nits FHD Slim Bezel Video Wall

    Key Features

    Choose your Size

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (55VL5PJ)
      $
      $
      LG Members Price
    Total
    Add to CompareAdd to CompareRemove Compare

    component-OBScountrySelectDesc

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (55VL5PJ)
      $
      $
      LG Members Price
    Total
    55'' 500 nits FHD Slim Bezel Video Wall
    Contact Us

    Artistic Immersion, Overwhelming Captivation

    A man is looking at a big screen attached to the window of a sports store. A man is looking at a big screen attached to the window of a sports store.
    * All images in this web page are for illustrative purposes only.

    Daisy Chain Capability

    By using this daisy-chained network feature, you can execute commands such as controlling, monitoring and even updating firmware.
    Multiple displays are being managed simultaneously through the daisy chain. The UHD daisy chain utilizing HDMI and DisplayPort allows easy access to adjusting UHD settings. Multiple displays are being managed simultaneously through the daisy chain. The UHD daisy chain utilizing HDMI and DisplayPort allows easy access to adjusting UHD settings.

    Real-Time LG ConnectedCare

    Maintenance is easy and fast with the optional LG ConnectedCare* service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, enabling the stable operation of clients' businesses.
    The LG employee is remotely monitoring the VL5PJ installed in a different place by using cloud-based LG monitoring solution. The LG employee is remotely monitoring the VL5PJ installed in a different place by using cloud-based LG monitoring solution.
    * LG ConnectedCare is the brand name of LG Signage365Care Service. The availability differs by region.
    The ultra narrow bezel provides immersive images continuously. The ultra narrow bezel provides immersive images continuously.

    Ultra Narrow Bezel

    The 3.5mm ultra narrow bezel size creates immersive and seamless viewing experiences on assembled video wall screens.
    VL5PJ can adjust the color temperature from 3,200K to 13,000K in units of 100K. VL5PJ can adjust the color temperature from 3,200K to 13,000K in units of 100K.

    Easy Color Adjustment

    Depending on the content, the color temperature of the display can be easily adjusted in increments of 100K using a remote control.
    VL5PJ consists of less image gaps between the tiled screens compared to the LG Conventional. This improves the viewing experience of the displayed content as it minimizes the visual disturbance by the gaps. VL5PJ consists of less image gaps between the tiled screens compared to the LG Conventional. This improves the viewing experience of the displayed content as it minimizes the visual disturbance by the gaps.

    Image Gap Reduction

    The VL5PJ includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a seamless viewing experience.
    * The "LG Conventional" refers to displays which do not include an image improvement algorithm.
    ** The image shown above are for illustration purposes only.
    The included SoC and webOS smart signage platform demonstrate its ability to execute several tasks at once. The included SoC and webOS smart signage platform demonstrate its ability to execute several tasks at once.

    High Performance and Great Scalability

    Thanks to its built-in SoC and webOS smart signage platform, the VL5PJ can execute several tasks at once while providing smooth content playback without the need for a media player. As webOS supports HTML5 as a web-based platform and offers SDK (Software Development Kit), it is even easier for SIs to build and optimize their web apps.
    * SDK can be downloaded with the link below. (https://webossignage.developer.lge.com)
    Close
    Panel
    • Screen Size
      55"
      Panel Technology
      IPS
    • Back Light Type
      Direct
      Aspect Ratio
      16 : 9
    • Native Resolution
      1,920 x 1,080 (FHD)
      Refresh Rate
      60Hz
    • Brightness(Typ., nit)
      500
      Contrast Ratio
      1,200:1
    • Dynamic CR
      500,000 : 1
      Color gamut
      NTSC 72%
    • Viewing Angle(H x V)
      178x178
      Color Depth
      10bit, 1.07Billion colors
    • Response Time
      8 ms (G to G)
      Surface Treatment(Haze)
      3%
    • Life time
      60,000Hrs (Typ.) / 50,000Hrs (Min.)
      Operation Hours (Hours/Day)
      24/7
    • Portrait / Landscape
      Yes / Yes
    Connectivity
    • Input
      HDMI 2 (HDCP 2.2), DP (HDCP 2.2), DVI-D (HDCP 1.4), Audio In, RS-232C In, RJ45 (LAN), IR In, USB 2.0 Type A
      Output
      DP Out (Input : HDMI / DVI / DP), Audio Out, RS-232C Out
    Mechanical Specification
    • Bezel Color
      Black
      Bezel Width
      T/R/L/B : 2.25/1.25/2.25/1.25mm
    • Weight(Head)
      23.5 Kg
      Packed Weight
      26.9 Kg
    • Monitor Dimension(W x H x D)
      1,213.4 x 684.2 x 93.1 mm
      Carton Dimensions(W x H x D) (Box outer size)
      1,337 x 247 x 833 mm
    • Handle
      Yes
      VESA? Standard Mount Interface
      600 x 400
    Key Feature
    • HW
      Internal Memory (8 GB), Temperature Sensor, BLU Sensor, Acceleration(Gyro) Sensor
      SW
      webOS 4.1, Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail Over, Background Image (No Signal Image), Sync Mode (RS-232C Sync, Local Network Sync), Video Tag (4), Play via URL, Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting (Max. 15 × 15), Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, 3rd Party Compatibility (Crestron Connected?2)), Power (Smart Energy Saving, PM Mode, Wake on LAN, Network Ready), HDMI-CEC3), SI Server Setting, webRTC, Pro:Idiom, W/B Setting by Grey Scale, Scan Inversion
    Environment Conditions
    • Operation Temperature
      0 °C to 40 °C
      Operation Humidity
      10 % to 80 %
    Power
    • Power Supply
      AC 100-240V~, 50/60Hz
      Power Type
      Built-In Power
    Power Consumption
    • Typ.
      135 W
      Max.
      150 W
    • BTU (British Thermal Unit)
      461 BTU/Hr(Typ.), 512 BTU/Hr(Max)
      Smart Enegy Saving
      115 W
    • DPM
      0.5 W
      Power off
      0.5 W
    Certification
    • Safety
      CB / NRTL
      EMC
      FCC Class “A” / CE / KC
    • ErP / Energy Star
      Yes / Energy Star 8.0
    Software Compatibility
    • SuperSign CMS
      Yes
      SuperSign Control / Control+
      Yes / Yes
    • SuperSign WB
      Yes
      SuperSign Media Editor
      Yes
    • LG Connected Care
      Yes
    Language
    • OSD
      English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Japanese, Russian, Portugues(Europe), Dutch, Czech, Greek,Turkish, Arabic
    Accessory
    • Basic
      Remote Controller(include battery 2ea), Power Cord, RS232C cable, Lan calbe, DP cable, IR Receiver, Guide Bracket, Screws, Manual
    Special Feature
    • IP Rating
      IP5X tested
    • Dimension
      • 55vl5pj_2d.dwg
      • 55vl5pj_2d.pdf
    • Datasheet
      • VL5PJ_Datasheet(low)_LG Video Wall_211203.pdf
    • Software

      To download Software, Please visit the Software Download Page (Click).

    • Manual

      To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).

    To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
