    65UM5N-E component-copyModelName
    UHD Signage Display

    Key Features

    Choose your Size

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (65UM5N-E)
      $
      $
      LG Members Price
    Total
    Add to CompareAdd to CompareRemove Compare

    component-OBScountrySelectDesc

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (65UM5N-E)
      $
      $
      LG Members Price
    Total
    UHD Signage Display
    Contact Us

    UHD Signage Display with
    LG webOS Platform and Advanced Security

    A screen showing the meeting’s contents is installed on the meeting room’s wall. A screen showing the meeting’s contents is installed on the meeting room’s wall.
    * 65 inch
    * All images in this page are for illustrative purposes only.
    The difference comparing at a glance is shown in Ultra HD quality, which is four times higher than Full HD. The difference comparing at a glance is shown in Ultra HD quality, which is four times higher than Full HD.

    High Resolution Display

    It offers a resolution that is four times higher than FHD, satisfying customers visually. Additionally, the anti-glare coating on the screen reduces screen reflection in bright lighting environments, increasing visibility and legibility, providing customers with a comfortable screen.
    A number of tasks can be done at the same time with the intuitive GUI. A number of tasks can be done at the same time with the intuitive GUI.

    Convenient webOS Platform

    The UM5N-E is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, enabling easy connection with external sensors and webOS partner apps to create an SI-friendly environment.

    Durability that Provides Reliability

    Optimized for business environments, the UM5N-E is guarded against the potential impact of salt, dust, iron powder and humidity through the implementation of conformal coating on the power board. Also, its customer-centric features, such as IP5x, 30-degree tilting and Shock Monitoring, provide both reliability and satisfaction.
    The UM5N-E has Conformal Coating on the power board to protect display even in a salty or humid environment. The UM5N-E has Conformal Coating on the power board to protect display even in a salty or humid environment.

    Design for Space Utilization

    Designed with thin bezels and simple cable management, the UM5N-E saves space. With specialized hidden power inlets, it can be installed close to the wall, leaving only about 13 mm of space with the slim bracket.
    The UM5N-E with slim bezels is mounted close to the wall, showcasing a rear design that is optimized for space-saving with a simple cable management system. The UM5N-E with slim bezels is mounted close to the wall, showcasing a rear design that is optimized for space-saving with a simple cable management system.
    * All images are for illustrative purposes only.
    * The product image will differ slightly from the actual appearance of the product due to the variance caused by each inch option.
    The UM5N-E provides security features to protect important data from external access or attacks. The UM5N-E provides security features to protect important data from external access or attacks.

    Enhanced Security Features

    The UM5N-E provides security features, including LG's Enhanced Kernel Protection (EKP) technology, guarding important data from external access or attacks. LG UHD Signage also holds reliable certification in the field of information security, maintaining customers' data and businesses securely. For example, this model is ISO/IEC 15408 Common Criteria EAL2 Certified.
    LG strives for a sustainable future by obtaining various certifications such as FCC EMC Class B or EPEAT*. * the United States Only LG strives for a sustainable future by obtaining various certifications such as FCC EMC Class B or EPEAT*. * the United States Only

    Sustainability

    With a commitment to innovation and sustainability, LG is continuously striving to create a better future for manufacturers, consumers, and future generations. With a focus on minimizing waste, maximizing recycling, and efficient power management, LG actively strives for sustainability, obtaining various certifications such as FCC EMC Class B or EPEAT*.

    * The United States Only

    SuperSign Solutions

    SuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.
    Cafe managers are creating menus that will be displayed on the display installed on the cafe wall using content management software. Cafe managers are creating menus that will be displayed on the display installed on the cafe wall using content management software.

    Carbon Footprint Certification

    The cradle-to-grave carbon footprint of UM5N-E has been reduced.
    Carbon Footprint Certification1 Carbon Footprint Certification2
    * UM5N-E achieved Reducing CO2 certification.
    * The Carbon Trust Assurance for UM5N-E is valid until 07 Sep 2025.
    * The Carbon Trust Assurance for UM5N-E is certified against PAS2050:2011.
    Close
    Info
    • Product
      Standard (UHD)
      Year
      Y23
    • Month
      M12
    Panel
    • Screen Size (Inch)
      65"
      Panel Technology
      IPS
    • Back Light Type
      Direct
      Aspect Ratio
      16:9
    • Native Resolution
      3840 x 2160 (UHD)
      Refresh Rate
      60Hz
    • Brightness (Typ.)
      500nit (Typ.)
      Contrast Ratio
      1,000:1
    • Dynamic CR
      1,000,000:1
      Color gamut
      BT709 95%
    • Viewing Angle(H x V)
      178 X 178
      Color Depth
      10bit(D), 1.07Billion colors
    • Response Time
      Tr : 8ms / Tf :10ms
      Surface Treatment (Haze)
      0.28
    • Life time
      50,000Hrs (Min.)
      Operation Hours (Hours/Day)
      24/7
    • Portait / Landscape
      Yes / Yes
    Connectivity
    (Jack Interface)
    • HDMI IN
      Yes(3), 3840x2160@60Hz, HDCP 2.2/1.4
      DP IN
      Yes(1), 3840x2160@60Hz, HDCP2.2/1.3
    • RS232C IN
      Yes(1), 4pin PhYesne-jack
      RJ45(LAN) IN
      Yes (1)
    • IR IN
      Yes (1)
      USB IN
      USB2.0 Type A(1)
    • HDMI Out
      Yes(1), 3840x2160@30Hz, Input : HDMI1/2/3/DP
      Audio Out
      Yes (1)
    • RS232C Out
      Yes (1), 4pin Phone-jack
      Daisy Chain
      Yes(Input HDMI, DP / Output HDMI)
    Mechanical
    • Bezel Color
      Black
      Bezel Width
      T/R/L/B: 12.4mm(Even)
    • Weight (Head)
      21.6Kg
      Packed Weight
      28.4Kg
    • Monitor Dimensions (W x H x D)
      1458 x 833 x 57.7mm (Without IR)
      Carton Dimensions (W x H x D)
      1600 x 970 x 179mm
    • VESATM Standard Mount Interface
      300 x 300
    HW Feature
    • Internal Memory
      16GB
      Wi-Fi (Built-in)
      Yes
    • Temperature Sensor
      Yes
      Auto Brightness sensor
      Yes(IR)
    • Acceleration(Gyro) Sensor
      Yes
      Local Key Operation
      Yes
    • Speaker (Built-in)
      Yes
    SW Feature
    • OS Ver. (webOS)
      webOS6.0
      Local Contents Scheduling
      Yes
    • Group Manager
      Yes
      USB Plug & Play
      Yes
    • Fail over
      Yes
      Booting Logo Image
      Yes
    • No Signal Image
      Yes
      RS232C Sync
      Yes
    • Local Network Sync
      Yes
      PIP
      Yes
    • PBP
      Yes (4)
      Screen Share
      Yes
    • Video Tag
      Yes (4)
      Play via URL
      Yes
    • Screen Rotation
      Yes
      External Input Rotation
      Yes
    • Gapless Playback
      Yes
      Tile Mode Setting
      Yes (Max. 15x15)
    • Setting Data Cloning
      Yes
      SNMP
      Yes
    • ISM Method
      Yes
      Auto Set ID
      Yes
    • Status Mailing
      Yes
      Control Manager
      Yes
    • Cisco Certification
      TBD
      Cisco Certi.
      Yes
    • Crestron Inside
      Yes
      Smart Energy Saving
      Yes
    • PM mode
      Yes
      Wake on LAN
      Yes
    • Beacon
      Yes
      Network Ready
      Yes
    • HDMI-CEC
      Yes
      SI Server Setting
      Yes
    • webRTC
      Yes
      Pro:Idiom
      Yes
    Environment Conditions
    • Operation Temperature
      0°C to 40°C
      Operation Humidity
      10 % to 80 %
    Power
    • Power Supply
      AC 100-240V~, 50/60Hz
      Power Type
      Built-In Power
    Power Consumption
    • Typ.
      145W
      Max.
      200W
    • BTU (British Thermal Unit)
      495 BTU/Hr(Typ.), 682 BTU/Hr(Max)
      Smart Enegy Saving (70%)
      101.5W
    • DPM
      0.5W
      Power off
      0.5W
    Sound
    • Speaker (Built-in)
      Yes (10W X 2)
    Certification
    • Safety
      CB / NRTL
      EMC
      FCC Class "B" / CE / KC
    • ErP / Energy Star
      Yes(NewErP)/Yes
      ePEAT(US only)
      Yes
    Software Compatibility
    • SuperSign CMS
      Yes
      SuperSign Control+
      Yes / Yes
    • SuperSign WB
      Yes
      SuperSign Cloud
      Yes
    • Promota
      Yes (Not available for EU/CIS)
      Mobile CMS
      Yes
    • Connected Care
      Yes
    Language
    • OSD
      English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkiye, Arabic
    Accessory
    • Basic
      Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender
      Optional
      Slim Wall Mount (WB21LMA/B),
      Wall Mount (OLW480A/B)
      Wall Mount Adapter (AM-B330S)
    Special Feature
    • Tilt (Face Down)
      Yes(Max 30o degree, 40oC temperature)
      IP Rating
      IP5X
    • Conformal Coating (Power Board)
      Yes

    To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
