    65UV5N-E (NA) component-copyModelName
    UHD Signage

    Key Features

    Choose your Size

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (65UV5N-E (NA))
      $
      $
      LG Members Price
    Total
    Add to CompareAdd to CompareRemove Compare

    component-OBScountrySelectDesc

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (65UV5N-E (NA))
      $
      $
      LG Members Price
    Total
    UHD Signage
    Contact Us

    UHD Digital Signage with BrightSignOS?

    Inside the convenience store, two signage displays are mounted on the wall, each vividly and brightly showcasing advertisements. Inside the convenience store, two signage displays are mounted on the wall, each vividly and brightly showcasing advertisements.
    * All images in this page are for illustrative purposes only.
    Two UV5N-E units powered by BrightSignOS are installed on the wall of a restaurant. Two UV5N-E units powered by BrightSignOS are installed on the wall of a restaurant.

    BrightSignOS

    Leading the way in digital signage, the UV5N-E is powered by BrightSignOS, known for its security, reliability, sustainability, and support. Running BrightSignOS also includes a free bsn.Control subscription for remote multidevice monitoring and seamless integration with over 100 CMS solutions.
    Sturdy Design with Fire Flame Resistance Sturdy Design with Fire Flame Resistance

    Sturdy Design with Fire Flame Resistance

    The outer cover of the product is designed to effectively resist fire flame spread, making the product a great fit for installation in public spaces.

    * Based on third party testing, the case top and back cover of the product are classified Class A1 (case top) and A2 (back cover) under EN13501-1, Class 1 under BS476 Part 7.
    The difference comparing at a glance is shown in Ultra HD quality, which is four times higher than Full HD. The difference comparing at a glance is shown in Ultra HD quality, which is four times higher than Full HD.

    High Resolution Display

    Offering a resolution that is four times higher than FHD, the UV5N-E delivers crisp visuals to customers. Additionally, the anti-glare coating on the screen reduces screen reflection in brightly lit environments, increasing visibility and legibility, allowing for customers to comfortably view the screen.

    Design for Space Utilization

    Designed with thin bezels and simple cable management, the UV5N-E saves space. With specialized hidden power inlets, it can be installed close to the wall, leaving only about 13 mm of space with the slim bracket.
    The UV5N-E, with slim bezels, is mounted close to the wall, showcasing a rear design optimized for space-saving with a simple cable management system. The UV5N-E, with slim bezels, is mounted close to the wall, showcasing a rear design optimized for space-saving with a simple cable management system.
    * All images are for illustrative purposes only.
    * The product image will differ slightly from the actual appearance of the product due to the variance caused by each inch option.

    Durability that Provides Reliability

    Optimized for business environments, the UV5N-E is protected against salt, dust, iron powder and humidity thanks to conformal coating on the power board, allowing for stable operation. Also, its customer-centric features, such as IP5x, 30-degree tilting and Shock Monitoring, provide both reliability and flexibility.
    The UV5N-E has conformal coating to protect the display even in salty or humid environments. The UV5N-E has conformal coating to protect the display even in salty or humid environments.
    The UV5N-E with BrightSignOS offers security features that protect its content and network. The UV5N-E with BrightSignOS offers security features that protect its content and network.

    Enhanced Security Features

    Built exclusively for digital signage, BrightSignOS offers a fortified security system that keeps your content and network protected at every level. It minimizes risks with a secure, signature-verified operating system that can be configured to any security profile and runs only approved signage applications. This security extends to integrated CMS solutions and the free bsn.Control remote management service, ensuring a resilient defense with unmatched uptime.
    LG strives for a sustainable future by obtaining various certifications such as FCC EMC Class B. LG strives for a sustainable future by obtaining various certifications such as FCC EMC Class B.

    Sustainability

    With a commitment to innovation and sustainability, LG is continuously striving to create a better future for manufacturers, consumers, and generations to come. With a focus on minimizing waste, maximizing recycling, and efficient power management, LG actively strives for sustainability, obtaining various certifications such as FCC EMC Class B.
    Close
    Info
    • Product
      Standard (UHD)
      Year
      Y24
    • Month
      M09
    Panel
    • Screen Size (Inch)
      65"
      Panel Technology
      IPS
    • Back Light Type
      Edge
      Aspect Ratio
      16:9
    • Native Resolution
      3840 x 2160 (UHD)
      Refresh Rate
      60Hz
    • Brightness (Typ.)
      500nit (Typ.)
      Contrast Ratio
      1,100:1
    • Dynamic CR
      1,000,000:1
      Color gamut
      BT709 95%
    • Viewing Angle(H x V)
      178 X 178
      Color Depth (Number of Colors)
      10bit(D), 1.07Billion colors
    • Response Time
      Tr : 8ms / Tf :10ms
      Surface Treatment(Haze)
      28%
    • Life time
      50,000Hrs (Min.)
      Operation Hours (Hours/Day)
      24/7
    • Portait / Landscape
      Yes / Yes
    Connectivity
    (Jack Interface)
    • HDMI IN
      Yes(3), 3840x2160@60Hz, HDCP 2.2/1.4
      DP IN
      Yes(1), 3840x2160@60Hz, HDCP2.2/1.3
    • RS232C IN
      Yes (1), 4pin Phone-jack
      RJ45(LAN) IN
      Yes (1)
    • IR IN
      Yes (1)
      USB IN
      USB2.0 Type A(1)
    • HDMI Out
      Yes(1), 3840x2160@30Hz, Input : HDMI1/2/3/DP
      Audio Out
      Yes (1)
    • RS232C Out
      Yes (1), 4pin Phone-jack
      IR Out
      No (Support IR daisy chain via RS232C IN/OUT)
    • Daisy Chain
      Yes(Input HDMI, DP / Output HDMI)
    Mechanical
    • Bezel Color
      Black
      Bezel Width
      T/R/L: 8.9mm, B: 12.9mm
    • Weight (Head)
      24.2 kg
      Packed Weight
      30.4 kg
    • Monitor Dimensions (W x H x D)
      1450.3 x 830.3 x 29.7mm (Without IR)
      Carton Dimensions (W x H x D)
      1600.0 x 970.0 x 172.0mm
    • VESATM Standard Mount Interface
      300 x 300
    HW Feature
    • Internal Memory (eMMC)
      16GB
      Wi-Fi/BT (Built-in)
      Yes
    • Temperature Sensor
      Yes
      Auto Brightness sensor
      Yes(IR)
    • Acceleration(Gyro) Sensor
      Yes
      Local Key Operation
      Yes
    SW Feature
    • OS Ver. (webOS)
      webOS6.0
      Local Contents Scheduling
      Yes
    • Group Manager
      Yes
      USB Plug & Play
      Yes
    • Fail over
      Yes
      Booting Logo Image
      Yes
    • No Signal Image
      Yes
      RS232C Sync
      Yes
    • Local Network Sync
      Yes
      PIP
      Yes
    • PBP
      Yes (4)
      Screen Share
      Yes
    • Video Tag
      Yes (4)
      Play via URL
      Yes
    • Screen Rotation
      Yes
      External Input Rotation
      Yes
    • Gapless Playback
      Yes
      Tile Mode Setting
      Yes (Max. 15x15)
    • Setting Data Cloning
      Yes
      SNMP
      Yes
    • ISM Method
      Yes
      Auto Set ID
      Yes
    • Status Mailing
      Yes
      Control Manager
      Yes
    • Crestron Connected
      Yes
      Smart Energy Saving
      Yes
    • PM mode
      Yes
      Wake on LAN
      Yes
    • Network Ready
      Yes
      Beacon
      Yes
    • HDMI-CEC
      Yes
      SI Server Setting
      Yes
    • webRTC
      Yes
      Pro:Idiom
      Yes
    Environment Conditions
    • Operation Temperature
      0°C to 40°C
      Operation Humidity
      10 % to 80 %
    Power
    • Power Supply
      AC 100-240V~, 50/60Hz
      Power Type
      Built-In Power
    Power Consumption
    • Typ.
      145W
      Max.
      200W
    • BTU (British Thermal Unit)
      495 BTU/Hr(Typ.), 682 BTU/Hr(Max)
      Smart Enegy Saving (70%)
      101.5W
    • DPM
      0.5W
      Power off
      0.5W
    Sound
    • Speaker (Built-in)
      Yes (10W X 2)
    Certification
    • Safety
      NTRL
      EMC
      FCC Class "B"
    • ErP / Energy Star
      N/A / Yes
      ePEAT(US only)
      Yes
    • BS476 Part7
      Class 1 (case top / back cover)
      EN13501-1
      Class A1 (case top) / Class A2 (back cover)
    Software Compatibility
    • SuperSign CMS
      Yes
      SuperSign Control+
      Yes / Yes
    • SuperSign WB
      Yes
      SuperSign Cloud
      Yes
    • Mobile CMS
      Yes
      Connected Care
      Yes
    Language
    • OSD
      English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türk?e, Arabic
    Accessory
    • Basic
      Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, Cable Holder(2EA), AC Cord Holder (1EA)
      Optional
      Slim Wall Mount (WB21LMA/B),
      Wall Mount (OLW480A/B)
      Wall Mount Adapter (AM-B330S)
    Special Feature
    • Tilt (Face Down)
      Yes(Max 30o degree, 40oC temperature)
      IP Rating
      IP5X
    • Conformal Coating (Power Board)
      Yes
    • Datasheet
      • UV5N-E_Datasheet(low)_LG UHD Signage_250210.pdf
    • Software

      To download Software, Please visit the Software Download Page (Click).

    • Manual

      To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
