    Outdoor Display
    Contact Us

    Outstanding Visibility with Advanced Reliability

    There is an XE3C installed on the roadside, displaying various advertisements. There is an XE3C installed on the roadside, displaying various advertisements.
    * All images in this page are for illustrative purposes only.

    High Visibility
    Under Strong Sunlight

    With outstanding high brightness of 3,000 nits (Typ.), 75XE3C outdoor display delivers contents clearly while captivating passersby, making it the suitable display for outdoor visibility. In addition, its clear visibility can deliver a variety of information even to those wearing polarized sunglasses.
    A large-sized display is installed on the street, and a woman is looking at a vivid-quality advertisement on the screen. A large-sized display is installed on the street, and a woman is looking at a vivid-quality advertisement on the screen.
    * Stand is optional accessory.
    XE3C enhances the contrast of images, making them appear more vivid. XE3C enhances the contrast of images, making them appear more vivid.

    Advanced Local Dimming

    The backlighting in specific areas of the screen can be controlled to increase contrast and provide a clearer image.
    A blurry picture of FHD is being compared with UHD with vivid quality images. A blurry picture of FHD is being compared with UHD with vivid quality images.

    Superb Picture Quality with Ultra HD Resolution

    With the resolution of UHD, it makes the color and details of the contents vivid and realistic. In addition, the wide viewing angle applied with an IPS panel, provides clear contents.

    * Within 178 degree
    XE3C is coated for an anti-reflection. XE3C is coated for an anti-reflection.

    Anti-reflection

    Thanks to anti-reflection coating, 75XE3C has low interference between reflection of external light & back light.
    The XE3C screen can adjust its brightness automatically according to the ambient light. The XE3C screen can adjust its brightness automatically according to the ambient light.

    Smart Brightness Control

    The screen brightness is automatically adjusted depending on the ambient light. The brightness is increased in light for better visibility, while it is decreased in darkness for efficient power management.
    M+ panels reduce power consumption by 35% compared to RGB. M+ panels reduce power consumption by 35% compared to RGB.

    Low Power Consumption Using the M+ Panel

    The M+ panel can offer high energy efficiency and cost savings as decreasing power consumption by approx.

    * M+ IPS reduced approx. by 35% BLU Power consumption (IEC62087, 10 min) compared to RGB IPS, tested under same brightness (@fullwhite, 400 nit)
    ** Specific features can differ from circumstances.
    The XE3C has a conformal coating making it resistant to dust and salinity in moisture. The XE3C has a conformal coating making it resistant to dust and salinity in moisture.

    Dust & Humidity Protection Designed with IP56 Rating

    Conformal Coating* protect the circuit board, power board against dust, iron powder, humidity, etc.

    * Thin protective films/breathing membranes that filter water vapor and solid debris
    A display is working well in an environment of -30~50°C. A display is working well in an environment of -30~50°C.

    Wide Range of Operating Temperature

    75XE3C can be used under a wide range of operating temperatures from -30°C to +50°C.
    XE3C, with its thermal management solution, performs well even in hot outdoor environments. XE3C, with its thermal management solution, performs well even in hot outdoor environments.

    Enhanced Thermal Management

    Environmentally sealed structure for water-resistant and protection against brake dust. 75XE3C has thermal management solution regarding heat from the LCD, Circuit / Powerboard and Solarloading. Totally self-contained and suitable for outdoor use without air filter.
    XE3C with a 9.5 mm protective glass, protects its panel. XE3C with a 9.5 mm protective glass, protects its panel.

    9.5 mm Protective Glass

    Designed to protect panel from impacts and vandalism for outdoor use.

    * P2A tested
    It has improved user convenience by utilizing the SoC and webOS. It has improved user convenience by utilizing the SoC and webOS.

    webOS Smart Platform

    Quad Core SoC (System-on-Chip) can execute several tasks at the same time without a separate media player. In addition, webOS 3.0 platform enhances user convenience with intuitive UI and simple app development tools.
    User can monitor and control their displays through mobile phone and laptop. User can monitor and control their displays through mobile phone and laptop.

    Web Monitoring

    The LG Control Manager*, the embedded web monitoring program, allows a variety of parameters to be diagnosed in real time such as temperature, ambient light, and gyro sensors. It can be easily controlled at all times.

    * Enabled by wired LAN connection
    The optional stand allows for the panel to be installed freely. The optional stand allows for the panel to be installed freely.

    Optional Stand

    Optional stand to allow panel to stand freely and facilitate easy cable management.
    Close
    Panel
    • Screen Size
      75" Class
      Native Resolution
      3,840 x 2,160 (UHD), M+
    • Brightness(Typ., with Protective Glass, cd/m2)
      3000
    Connectivity
    • Input
      HDMI, DP, DVI-D, Audio In, USB 3.0, SD Card
      Output
      DP, External Speaker (*waterproof speakers are mandatory for outdoor installation)
    • External Control
      RS232C In/out, RJ45 In
    Physical Specification
    • Bezel Width
      110mm(T), 230mm(B), 73.3mm(L/R)
      Monitor Dimension (W x H x D)
      1,075.6 x 1,991.6 x 218.9 mm
    • Weight (Head)
      180 kg
    Environment Conditions
    • Operation Temperature
      -30 °C to 50 °C
      Operation Humidity
      5 % to 100 %
    Power
    • Power Supply
      100-240V~, 50/60Hz
      Power Type
      Built-In Power
    Power Consumption
    • Typ.
      750W (Full White)
      403W (IEC 62087)
      Max
      1000W
    Standard(Certification)
    • Safety
      UL / cUL / CB
      EMC
      FCC Class "A" / CE / KC
    • ErP / Energy Star
      No / No
    Media Player Compatibility
    • OPS type compatible
      No
      External Media player Attatchable
      Yes (Available space for media player installation inside the product)
    Software Compatibility
    • Content Management Software
      SuperSign CMS
      Control and Monitoring Software
      SuperSign C
    Accessory
    • Basic
      Remote Controller, Manual, QSG, Regulation Book, Phone to RS232C Gender, USB cable, HDMI cable
      Optional
      Enclosure Stand (ST-750X)
    • Datasheet
      • XE3C_Datasheet(low)_LG Outdoor Display_231012.pdf
    • Software

      To download Software, Please visit the Software Download Page (Click).

    • Manual

      To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
