    UHD Signage
    Contact Us

    Sleek 4K UHD Signage Featuring Enhanced Security with LG Shield

    Two UP5Q-E displays are installed side by side in the mart. The left screen displays advertisements in full screen, while the right one shows ads in a split-screen layout. Two UP5Q-E displays are installed side by side in the mart. The left screen displays advertisements in full screen, while the right one shows ads in a split-screen layout.
    * All images are for illustrative purposes only.
    The difference comparing at a glance is shown in Ultra HD quality, which is four times higher than Full HD. The difference comparing at a glance is shown in Ultra HD quality, which is four times higher than Full HD.

    High Resolution Display

    It offers a resolution that is four times higher than FHD, satisfying customers visually. Additionally, the anti-glare coating on the screen reduces screen reflection in bright lighting environments, increasing visibility and legibility, providing customers with a comfortable screen.
    The UP5Q-E with LG Shield offers security features that protect its system and network. The UP5Q-E with LG Shield offers security features that protect its system and network.

    Comprehensive Security

    webOS Signage goes beyond security measures at the operating system (OS) level. LG Shield employs a five-tiered defense system, encompassing server, application, operating system, system, and hardware. Each layer operates independently, providing comprehensive protection against various threats. Also webOS platform support ETSI EN 303 645.
    Two UP5Q-E displays are installed side by side in the meeting room. One display features a four-way multi-screen setup showing video conference participants, while the other presents meeting materials in full screen. Two UP5Q-E displays are installed side by side in the meeting room. One display features a four-way multi-screen setup showing video conference participants, while the other presents meeting materials in full screen.

    Multi-Screen Play with 4K OSD

    The new webOS platform supports detailed text-based content playback with 4K OSD, ensuring that 4K app content is displayed smoothly. Thanks to its powerful CPU and GPU performance, it can deliver seamless content playback, even when handling graphics and data-intensive tasks. Additionally, the multi-screen feature offers 4-screen streaming capabilities, enhancing the overall user experience.
    Inside the convenience store, two UP5Q-E displays are mounted on the wall, each vividly and seamlessly showcasing advertisements. Inside the convenience store, two UP5Q-E displays are mounted on the wall, each vividly and seamlessly showcasing advertisements.

    Smooth Content Play

    Experience seamless 4K playback with UP5Q-E, ensuring smooth content transitions. With 32GB storage, it offers efficient file transfer through USB 3.0, reducing potential delays in content playback and updates.
    A number of tasks can be done at the same time with the intuitive UI. A number of tasks can be done at the same time with the intuitive UI.

    Convenient webOS Platform

    The UP5Q-E is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, enabling easy connection with external sensors and webOS partner apps to create an SI-friendly environment.
    The UP5Q-E is designed to be flame-resistant. The UP5Q-E is designed to be flame-resistant.

    Sturdy Design with Fire Flame Resistance

    The outer cover of the product is designed to effectively resist fire flame spread, making the product a great fit for installation in public spaces.

    * Based on third party testing, the case top and back cover of the product are classified Class A1 (case top) and A2 (back cover) under EN13501-1, Class 1 under BS476 Part 7.
    The UP5Q-E has conformal coating to protect the display even in salty or humid environments. The UP5Q-E has conformal coating to protect the display even in salty or humid environments.

    Durability that Provides Reliability

    Optimized for business environments, the UP5Q-E is protected against salt, dust, iron powder, and humidity due to conformal coating applied specifically to selected areas of the power board. Additionally, its customercentric features such as IP5x, 30-degree tilting, and Shock Monitoring provide both reliability and satisfaction.

    * Shock Monitoring refers to the feature where sensors detect impacts on the device and alert the user.
    ** CTK has reported that its based model has achieved an IP5X rating, which, under the Ingress Protection (IP) rating system, specifically indicates the level of protection against dust.
    Cafe managers are creating menus that will be displayed on the display installed on the cafe wall using content management software. Cafe managers are creating menus that will be displayed on the display installed on the cafe wall using content management software.

    SuperSign Solutions

    SuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that fits you.

    * Sold separately

    Eye-Catching Large Screen

    A large screen effectively captures people's attention as UP5Q-E offers 75/86-inch sizes.
    The company lounge features a sizable UP5Q-E installed on the wall. The large screen vividly displays images, easily capturing people’s attention. The company lounge features a sizable UP5Q-E installed on the wall. The large screen vividly displays images, easily capturing people’s attention.
    Close
    Connectivity
    (Jack Interface)
    • HDMI IN
      Yes(3), 3840x2160@60Hz, HDCP 2.2/1.4
      DP IN
      Yes(1), 3840x2160@60Hz, HDCP2.2/1.3
    • RS232C IN
      Yes (1), 4pin Phone-jack
      RJ45(LAN) IN
      Yes (1)
    • IR IN
      Yes (1)
      USB IN
      USB3.0 Type A(1), USB2.0 TypeA(1)
    • Audio Out
      Yes (1)
      RS232C Out
      Yes (1), 4pin Phone-jack
    Mechanical
    • Bezel Color
      Black
      Bezel Width
      13.4 mm (Even)
    • Weight (Head)
      53.0 kg
      Packed Weight
      66.7 kg
    • Monitor Dimensions (W x H x D)
      1928.8 x 1099.8 x 29.7 mm (without IR, Handle)
      Carton Dimensions (W x H x D)
      2100 x 1250 x 253 mm
    • Handle
      Yes
      VESATM Standard Mount Interface
      600 x 400
    HW Feature
    • Internal Memory (eMMC)
      32GB
      Wi-Fi/BT (Built-in)
      Yes
    • Temperature Sensor
      Yes
      Auto Brightness sensor
      Yes
    • Acceleration(Gyro) Sensor
      Yes
      Local Key Operation
      Yes
    SW Feature
    • OS Ver. (webOS)
      webOS8.0
      Local Contents Scheduling
      Yes
    • Group Manager
      Yes
      USB Plug & Play
      Yes
    • Fail over
      Yes
      Booting Logo Image
      Yes
    • No Signal Image
      Yes
      RS232C Sync
      Yes
    • Local Network Sync
      Yes
      PIP
      Yes
    • PBP
      Yes(4)
      Screen Share
      Yes
    • Video Tag
      Yes(6)
      Play via URL
      Yes
    • Screen Rotation
      Yes
      External Input Rotation
      Yes
    • Gapless Playback
      Yes
      Tile Mode Setting
      Yes (Max. 15x15)
    • Setting Data Cloning
      Yes
      SNMP
      Yes
    • ISM Method
      Yes
      Auto Set ID
      Yes
    • Status Mailing
      Yes
      Control Manager
      Yes
    • Cisco Certification
      TBD
      Crestron Connected
      Yes
    • Smart Energy Saving
      Yes
      PM mode
      Yes
    • Wake on LAN
      Yes
      Network Ready
      Yes
    • Beacon
      Yes
      HDMI-CEC
      Yes
    • SI Server Setting
      Yes
      webRTC
      Yes
    • Pro:Idiom
      Yes
    Environment Conditions
    • Operation Temperature
      0°C to 40°C
      Operation Humidity
      10 % to 80 %
    Power
    • Power Supply
      AC 100-240V~, 50/60Hz
      Power Type
      Built-In Power
    Power Consumption
    • Typ.
      205W (TBD)
      Max.
      297W (TBD)
    • BTU (British Thermal Unit)
      699 BTU/Hr(Typ.), 1013 BTU/Hr(Max) (TBD)
      Smart Enegy Saving (70%)
      144W (TBD)
    • DPM
      0.5W
      Power off
      0.5W
    Sound
    • Speaker (Built-in)
      Yes (10W X 2)
    Certification
    • Safety
      CB / NRTL
      EMC
      FCC Class "B" / CE / KC
    • ErP / Energy Star
      N/A / Yes
      ePEAT(US only)
      Yes
    Software Compatibility
    • SuperSign CMS
      Yes
      SuperSign Control+
      Yes
    • SuperSign WB
      Yes
      SuperSign Cloud
      Yes
    • Mobile CMS
      Yes
      Connected Care
      Yes
    Language
    • OSD
      English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türk?e, Arabic
    Accessory
    • Basic
      Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, Cable Holder(6EA), Cable Holder(7Pin/1EA)
      Optional
      Wall Mount (LSW640A/B)
    Special Feature
    • IP Rating
      IP5X
      Conformal Coating (Power Board)
      Yes (Partial space coating)
    • Datasheet
      • UP5Q-E_Datasheet(low)_LG UHD Signage_250526.pdf
    • Software

      To download Software, Please visit the Software Download Page (Click).

    • Manual

      To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).

    To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
