- Pitch Name
- P1.0
- Pixel Pitch (mm)
- 1.0
-
- LED Type
- SMD 3-in-1
- Resolution(W x H, per Unit Case)
- 384 x 360
-
- Dimensions(W x H x D, per Module)
- 192 x 180 x 16 mm
- Dimensions(W x H x D, per Unit Case)
- 384 x 360 x 77 mm
-
- Weight(per Unit Case)
- 5 kg
- Weight(per SQM)
-
36 kg1)
1) LED Unit Case (Except LED Controller)
-
- IP Rating
- N/A
- Unit Frame Material
- Die Casting Allumium
-
- Unit Frame Color
- Black
- Curvature
- N/A
-
- Access
- Rear
-
- Brightness (After Calibration)
- 1,000nit
- Contrast Ratio
- 6,000:1
-
- Viewing Angle(H x V)
- 160 x 140
- Bit Depth
- 16bit
-
- Brightness Uniformity
- ≥ 97%
- Color Uniformity
- ±0.015Cx, Cy
-
- Color Gamut
- NTSC 100%, BT2020 94%
- Color temperature - Default
- 6,500K
-
- Color temperature - Adjustable
- 3,200 ~ 9,300K
- Video Frame Rate
- 50/60Hz
-
- Input Power Range
- 100-240V~, 50/60Hz
- Power consumption - Max/Typ(per Unit Case)
- 170/85W
-
- Power consumption - Max/Typ(per SQM)
- 1,230/615W
- Refresh rate
- 1,920Hz
-
- Redundancy
- N/A
-
- Video Inputs
- HDMI In, DP In/Out, DVI, USB
- Control
- RJ45 In/Out, RS232C In/Out
-
- Special Features
- Temperature Sensor, Ambient Light Sensor, Current Sensor
-
- Working Temperature/Humidity
- 0 °C to 40 °C at 10 % to 80 %
- Storage Temperature/Humidity
- -20°C to 60 at 5 to 90%
-
- LED Lifetime
- 100,000hrs
-
- Safety
- IEC 60950-1 / EN 60950-1 / UL 60950-1
- EMC
- FCC Class "A" / CE / KC
-
- Environment
- RoHS
To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
