    Outdoor LED Display for Seaside Environments

    Key Features

    Choose your Pitch

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (GNEA062)
      $
      $
      LG Members Price
    Total
    Add to CompareAdd to CompareRemove Compare

    component-OBScountrySelectDesc

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (GNEA062)
      $
      $
      LG Members Price
    Total
    Outdoor LED Display for Seaside Environments
    Contact Us

    Outdoor LED Display for Seaside Environments

    A large LED is installed on the building’s outer wall next to a resort’s outdoor swimming pool by the beach, and it clearly shows the resort’s event advertisement. A large LED is installed on the building’s outer wall next to a resort’s outdoor swimming pool by the beach, and it clearly shows the resort’s event advertisement.
    * All images in this page are for illustrative purposes only.

    Durability for Rough Environment

    GNEA series provides durability with marine-grade powder coating and conformal coating to protect against salinity and corrosion in marine environments and weather conditions. Both the front and rear of the cabinet are IP67-certified and offer reliable designs for seaside, allowing stable power and data connections protected by outdoor environmental factors such as wet weather and the salinity.
    GNEA series has Conformal Coating on the power board to protect LED even in a humid or salty environment. GNEA series has Conformal Coating on the power board to protect LED even in a humid or salty environment.
    * Metal parts meet Qualicoat standards.
    More Durable LEDs that used a screw mounting bracket and SUS 316 screws are installed on the swimming pool building’s outer wall. More Durable LEDs that used a screw mounting bracket and SUS 316 screws are installed on the swimming pool building’s outer wall.

    Safe Installation and Maintenance

    GNEA series offers safe and hassle free installation and maintenance with a powerful screw mounting bracket. Applying SUS 316 screws further protects against salt corrosion, leading to increased durability.
    There is a LED screen and the screen is being watched with mobile phone camera. Despite showing the same advertisement, the conventional screen shows black bars, but the GNEA series clearly shows the original screen. There is a LED screen and the screen is being watched with mobile phone camera. Despite showing the same advertisement, the conventional screen shows black bars, but the GNEA series clearly shows the original screen.

    High Refresh Rate

    A high refresh rate of 7,680 Hz assures the smooth playback of content. The flicker-free image prevents the black bars that typically occur during video playback, and reduces eye strain and blurred images for viewers.

    Compatibility with LG Software Solutions

    When connected with LG's CVEA system controller, the GNEA series is compatible with LG software solutions including SuperSign CMS, LED Assistant, and ConnectedCare, which help customers operate their own business properly.
    "The LG employee is remotely monitoring the GNEA series installed in a different place by using a cloud-based LG monitoring solution. System controller with webOS enables GNEA series to be compatible with LG software solutions. " "The LG employee is remotely monitoring the GNEA series installed in a different place by using a cloud-based LG monitoring solution. System controller with webOS enables GNEA series to be compatible with LG software solutions. "
    * The availability of the 'LG ConnectedCare' service differs by region, and it needs to be purchased separately. So please contact the LG sales representative in your region for more details.
    * The items that can be monitored by LG ConnectedCare : Main Board (Temp., Signal Status, FPGA Ver, Ethernet Connection Status), Receiving Card (Temp., LED Power)
    * Actual GUI may vary in different webOS versions.
    * SuperSign CMS service needs to be purchased separately.
    Close
    Physical Parameters
    • Pitch Name
      P6.25
      Pixel Configuration
      Single SMD
    • Pixel Pitch(mm)
      6.25
      Module Resolution (WxH)
      64x64
    • Module Dimensions(WxH,mm)
      400x400
      Weight per Module (kg)
      2.45
    • No. of Modules per Cabinet (WxH)
      2x4
      Cabinet Resolution (WxH)
      128x256
    • Cabinet Dimensions (W x H x D, mm)
      800x1,600x143.5
      Cabinet Surface Area (㎡)
      1.280
    • Weight per Cabinet (kg/unit)
      40.0
      Weight per Square Meter (kg/m2)
      31.3
    • Physical Pixel Density (pixels/m2)
      25,600
      Flatness of Cabinet (mm)
      ±1.0
    • Cabinet Material
      Al
      Service Access
      Rear
    OPTICAL SPECIFICATIONS
    • Max Brightness (After Calibration, nit)
      6,000
      Color Temperature (K)
      3,500~8,500
    • Visual Viewing Angle (Horizontal)
      160
      Visual Viewing Angle (Vertical)
      130
    • Brightness Uniformity
      97%
      Color Uniformity
      ±0.05Cx,Cy
    • Contrast Ratio
      5,000:1
      Processing Depth (bit)
      16 (HDR10, HDR10 Pro)
    ELECTRICAL SPECIFICATIONS
    • Power Consumption (W/Cabinet, Max.)
      940
      Power Consumption (W/Cabinet, Avg.)
      376
    • Power Consumption (W/m2, Max.)
      734
      Heat Dissipation (BTU/h/Cabinet, Max.)
      3,208
    • Heat Dissipation (BTU/h/Cabinet, Avg.)
      1,283
      Heat Dissipation (BTU/h/m2, Max.)
      2,506
    • Power Supply (V)
      100 to 240
      Frame Rate (Hz)
      50 / 60
    • Refresh Rate (Hz)
      7,680
    OPERATION SPECIFICATIONS
    • LED Lifetime (Half brightness)
      100,000
      Operating Temperature(℃)
      -30°C to +50°C
    • Operating Humidity
      0~90%RH
      IP Rating Front
      IP67
    • IP Rating Rear
      IP67
    Certification
    • Certification
      CE, FCC, ETL
    Environment
    • Environment
      RoHS, REACH
    Controller
    • Controller
      CVEA
    90 Degree Corner Cut
    • 90 Degree Corner Cut
      Yes
    Series
    • Series
      GNEA
    • Dimension
      • GNEA_Series-v1.1 (1).dwg
      • GNEA_Series-v1.1.pdf
    • Datasheet
      • GNEA-Series_Datasheet(low)_LG-Outdoor-LED_220801.pdf
    • Software

      To download Software, Please visit the Software Download Page (Click).

    • Manual

      To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).

    To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
