    Ultra Light Series
    Contact Us

    GSCD Ultra Light Series

    With a lightweight design, the Ultra Light Series can be easily composed of a large screen without providing heavy load to the installing structure. A 90° corner option is provided for seamless right-angled installation.
    There is a screen installed on the corner of the building. There is a screen installed on the corner of the building.
    An LED signage is installed on the exterior wall of the building, transmitting the information with outstanding clarity under the sunlight. An LED signage is installed on the exterior wall of the building, transmitting the information with outstanding clarity under the sunlight.

    High Brightness

    With a great brightness of 7,000 nits*, it clearly delivers content and attracts public attention, which is the ultimate display for outdoor visibility.
    * GSCD100-GR series only
    GSCD series is very light that can be installed on the roof of the building. GSCD series is very light that can be installed on the roof of the building.

    Lightweight Design

    The weights of the cabinet is very light, so even if a large LED screen is installed on the roof, it puts less pressure on the building's load.
    The control unit of the cabinet is easy to attach and detach. The control unit of the cabinet is easy to attach and detach.

    Easy Maintenance

    The control unit (PDU) of the cabinet is a modular type which can be easily attached or detached, supporting easy maintenance.
    Capable of front or rear installation depending on the customers' needs. Capable of front or rear installation depending on the customers' needs.

    Front or Rear Serviceability

    The product offers either front access or rear access, allowing customers to choose installation options according to their environment.
    Content is clearly displayed even when the screen is installed on a 90° corner. Content is clearly displayed even when the screen is installed on a 90° corner.

    90° Corner Design Available

    If you add a 90° corner option*, the GSCD series can deliver content effectively even when installed on the corners.
    * Require purchase of 90° corner installable model.
    The IP65 certified cabinet allows GSCD series to work well even in rainy or cloudy weather. The IP65 certified cabinet allows GSCD series to work well even in rainy or cloudy weather.

    IP Rated Weatherproof Design

    The front and back of the cabinet are IP65 certified, allowing stable operation less affected by weather.

    Compatibility with
    LG Software Solutions

    Powered by LG’s high performance system controller, the GSCD series is compatible with LG software solutions including SuperSign CMS, LED Assistant, and ConnectedCare, which help customers operate their own business flawlessly.
    The LG employee is remotely monitoring the GSCD series installed in a different place by using a cloud-based LG monitoring solution. System controller with web OS enables GSCD series to be compatible with LG software solutions. The LG employee is remotely monitoring the GSCD series installed in a different place by using a cloud-based LG monitoring solution. System controller with web OS enables GSCD series to be compatible with LG software solutions.
    * The availability of the 'LG ConnectedCare' service differs by region, and it needs to be purchased separately. So please contact the LG sales representative in your region for more details.
    * The items that can be monitored by LG ConnectedCare : Main Board (Temp., Signal Status, FPGA Ver, Ethernet Connection Status), Receiving Card (Temp., LED Power)
    Explore more showroom at<br>LG Digital Connect1 Explore more showroom at<br>LG Digital Connect2

    Explore more showroom at
    LG Digital Connect

    Explore
    Close
    Physical Parameters
    • Pixel Configuration
      3 in 1 SMD 1921
      Pixel Pitch (mm)
      6.94
    • Module Resolution (WxH)
      72x36
      Module Dimensions (WxH, mm)
      500x250mm
    • Weight per Module (kg)
      1.3kg
      No. of Modules per Cabinet (WxH)
      2 × 4 / 2 × 2 (Half-sized)
    • Cabinet Resolution (WxH)
      144 × 144 / 144 × 72 (Half-sized)
      Cabinet Dimensions (W x H x D, mm)
      1,000 × 1,000 × 84.4 mm / 1,000 × 500 × 84.4 mm (Half-sized)
    • Cabinet Surface Area (㎡)
      1.000 / 0.500 (Half-sized)
      Weight per Cabinet (kg/unit)
      18.5 / 10.4 (Half-sized)
    • Weight per Square Meter (kg/m2)
      18.5 / 20.8 (Half-sized)
      Physical Pixel Density (pixels/m2)
      20,736
    • Flatness of Cabinet (mm)
      ±0.5
      Cabinet Material
      Aluminum Profile
    • Service Access
      Front or Rear (One Option Only)
    OPTICAL SPECIFICATIONS
    • Max. Brightness (After Calibration)
      5,000
      Color Temperature (K)
      3,200-9,300
    • Visual Viewing Angle (Horizontal)
      160
      Visual Viewing Angle (Vertical)
      134
    • Brightness Uniformity
      97%
      Color Uniformity
      ±0.003CxCy
    • Contrast Ratio
      6,000
      Processing Depth (bit)
      16
    ELECTRICAL SPECIFICATIONS
    • Power Consumption (W/Cabinet, Max.)
      680 / 340 (Half-sized)
      Power Consumption (W/Cabinet, Avg.)
      226 / 114 (Half-sized)
    • Power Consumption (W/m2, Max.)
      680
      Power Supply (V)
      100 to 240
    • Frame Rate (Hz)
      50 / 60
      Refresh Rate (Hz)
      3,840
    OPERATION SPECIFICATIONS
    • Lifetime (Hours to Half Brightness)
      100,000
      Operating Temperature(℃)
      -30°C to +50°C
    • Operating Humidity
      10-99%RH
      IP Rating (Front / Rear)
      IP65 / IP65
    Controller(CVCA)
    • Connectivity - Input
      HDMI (HDCP 2.2), DP (HDCP 2.2, HDCP 1.4), OPS, USB 2.0
      Connectivity - Output
      Gigabit Ethernet × 16, RS-232C In/Out (4 Pin Phone-jack)
    • Connectivity - Control
      RJ45 In (LAN)
      Video - Resolution
      3,840 × 2,160 @ 60Hz
    • Video - Format
      RGB / YCbCr4:4:4 / YCbCr4:2:2
      Feature
      8 GB (System 4 GB + Available 3.6 GB), Temperature Sensor, Local Key Operation, Signal Redundancy, HDR10
    • Software - Platform
      webOS 4.0 w / Open API Support
      Software - Setup and Maintenance
      LG LED Assistant
    • Software - Content Management
      LG SuperSign CMS
      Software - Cloud Monitoring
      LG ConnectedCare
    • Physical Specs - Dimensions (W × H × D, mm)
      443 × 63 × 307.5 → EIA Standard Rack (2U)
      Physical Specs - Weight (kg)
      4.9
    • Power Specs - Power Supply (V)
      AC 100-240 V, 50/60 Hz
      Power Specs - Power Type
      Built-in Power
    • Power Specs - Power Consumption (W)
      50 (Max.)
      Environmental Conditions - Operation Temperature
      0°C to 40°C
    • Environmental Conditions - Operation Humidity
      10% to 80%
      Certifications - Safety
      IEC 60950-1 / EN 60950-1 / UL 60950-1
    • Certifications - EMC
      FCC Class "A" / CE / KC
    Series
    • Series
      GSCD
    • Dimension
      • 2D-Drawing-GSCD069.dwg
      • 2D-Drawing-GSCD069.pdf
    • Datasheet
      • GSCD Series_Datasheet(low)_LG Ultra Light LED Signage_210730.pdf
    • Software

      To download Software, Please visit the Software Download Page (Click).

    • Manual

      To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
