    LG Indoor LED

    Key Features

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (GSCE039)
      $
      $
      LG Members Price
    Total
    Add to CompareAdd to CompareRemove Compare

    component-OBScountrySelectDesc

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (GSCE039)
      $
      $
      LG Members Price
    Total
    LG Indoor LED
    Contact Us

    Ceiling LED Display for
    Virtual Productrion

    Body text can be up to 1000 characters.
    A virtual production studio with curved LED walls and ceiling and floor LEDs is filming images of a forest and field landscape. A virtual production studio with curved LED walls and ceiling and floor LEDs is filming images of a forest and field landscape.
    * All images in this page are for illustrative purposes only.

    Fast Installation

    Various factors including magnets on the top and bottom, positioning pins, handles and fast locks help installers easily set up and dismantle the LED screens without additional tools.
    The 'Positioning Pins', 'Magnetic Assembly', 'Comfortable Handles', and 'Fast Lock & One-handed Control' parts in the cabinet are enlarged. The 'Positioning Pins', 'Magnetic Assembly', 'Comfortable Handles', and 'Fast Lock & One-handed Control' parts in the cabinet are enlarged.

    Easy Maintenance

    The GSCE series applied a simple Lock Fixing method which requires no additional tools, making it easier to replace LED modules or power/data units. It saves cost and time for maintenance.
    It is demonstrating that a simple Lock Fixing method allows for convenient replacement of the cabinet's Power/Data Unit. It is demonstrating that a simple Lock Fixing method allows for convenient replacement of the cabinet's Power/Data Unit.

    Front or Rear Serviceability

    The product offers either front access or rear access, allowing customers to choose installation options according to their environment and minimizes limitations in installation and maintenance.
    Capable of front or rear installation depending on the customers' needs. Capable of front or rear installation depending on the customers' needs.

    High Brightness

    The ceiling LED with 5,000 nits enables GSCE series to be used for alternative lightings in XR and virtual production.
    In a studio, ceiling LEDs are installed in sizes of approximately 400m2, 50-100m2, and 20-50m2, respectively. The scenery on the LED screens appears very bright. In a studio, ceiling LEDs are installed in sizes of approximately 400m2, 50-100m2, and 20-50m2, respectively. The scenery on the LED screens appears very bright.

    Powerful UI/UX with
    Megapixel VR HELIOS LED Processing Platform

    Thanks to the compatibility between GSCE and the Megapixel VR HELIOS LED processing platform, you can now utilize the powerful UX and UI functionalities offered by HELIOS. HELIOS processing platform includes Real-Time Mapping and Multi-User Control, Superior Color Control, Hyper-Speed Seam Correction using a game controller, and Monitoring and Diagnostics through connected diagnostics.
    The Megapixel VR HELIOS LED processing platform provides access to the features such as Real-Time Mapping and Multi-Use Control, Superior Color Control, Hyper-Speed Seam Correction using a Game Controller, and Monitoring and Diagnostics using Connected Diagnostics. The Megapixel VR HELIOS LED processing platform provides access to the features such as Real-Time Mapping and Multi-Use Control, Superior Color Control, Hyper-Speed Seam Correction using a Game Controller, and Monitoring and Diagnostics using Connected Diagnostics.
    * Please note that Megapixel VR HELIOS LED processing platform needs to be purchased separately, and depending on the actual usage environment, there may be limitations in the implementation of certain features offered by HELIOS. A game controller needs to be purchased separately.
    Close
    Physical Parameters
    • Pitch Name
      P3.91
      Pixel Configuration
      Single SMD
    • Pixel Pitch(mm)
      3.91
      Module Resolution (WxH)
      64x128
    • Module Dimensions(WxH,mm)
      250x500
      Weight per Module (kg)
      1.40
    • No. of Modules per Cabinet (WxH)
      2x2
      Cabinet Resolution (WxH)
      128x256
    • Cabinet Dimensions (W x H x D, mm)
      500x1000x66.05
      Cabinet Surface Area (㎡)
      0.500
    • Weight per Cabinet (kg/unit)
      12.4
      Weight per Square Meter (kg/m2)
      24.9
    • Physical Pixel Density (pixels/m2)
      65,536
      Flatness of Cabinet (mm)
      ±0.3
    • Cabinet Material
      Die-casting Magnesium
      Service Access
      Front or Rear (select one only)
    OPTICAL SPECIFICATIONS
    • Max Brightness (After Calibration, nit)
      5,000
      Color Temperature (K)
      2,000-11,000
    • Visual Viewing Angle (Horizontal)
      160
      Visual Viewing Angle (Vertical)
      155
    • Brightness Uniformity
      0.97
      Color Uniformity
      ±0.003Cx,Cy
    • Contrast Ratio
      6,000:1
      Processing Depth (bit)
      16 (PQ, HLG)
    ELECTRICAL SPECIFICATIONS
    • Power Consumption (W/Cabinet, Max.)
      300
      Power Consumption (W/Cabinet, Avg.)
      100
    • Power Consumption (W/m2, Max.)
      600
      Heat Dissipation (BTU/h/Cabinet, Max.)
      1,024
    • Heat Dissipation (BTU/h/Cabinet, Avg.)
      341
      Heat Dissipation (BTU/h/m2, Max.)
      2,047
    • Power Supply (V)
      100 to 240
      Frame Rate (Hz)
      50 / 60
    • Refresh Rate (Hz)
      3,840
    OPERATION SPECIFICATIONS
    • LED Lifetime (Half brightness)
      100,000
      Operating Temperature(℃)
      -30℃ to +45℃
    • Operating Humidity
      10~99%RH
      IP Rating Front
      IP30
    • IP Rating Rear
      IP30
    Standard
    • Certification
      CE, FCC, ETL
    Environment
    • Environment
      RoHS
    Controller
    • Controller
      (MVR HEIOS)
    Series
    • Series
      GSCE

    To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
