    GSEG100 component-copyModelName
    Ultra High Brightness Series

    Key Features

    Choose your Pitch

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (GSEG100)
      $
      $
      LG Members Price
    Total
    Add to CompareAdd to CompareRemove Compare

    component-OBScountrySelectDesc

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (GSEG100)
      $
      $
      LG Members Price
    Total
    Ultra High Brightness Series
    Contact Us

    Ultra High Brightness Series

    A large LED is installed on the building. The sun is shining brightly, but the LED screen’s advertisement is clearly visible. A large LED is installed on the building. The sun is shining brightly, but the LED screen’s advertisement is clearly visible.
    * All images in this page are for illustrative purposes only.

    High Brightness for Outdoor

    Optionally, users can choose among the three models : GSEG-GN(6,000 nits), GSEG-GR(7,000 nits) and GSEG-GS(10,000 nits). It also can be optimized for screen time, region, regulations, and power consumption etc. depending on different environmental conditions.
    GSEG can be installed by selecting either 6,000 or 7,000 or 10,000 nits brightness for the surrounding environment. GSEG can be installed by selecting either 6,000 or 7,000 or 10,000 nits brightness for the surrounding environment.
    * Brightness options are set before shipment from the factory, and cannot be changed after installation.

    Easy Installation and Maintenance

    It comes with a guide pin to make easy adjustment for the upper and lower side of cabinet. With optimum cable-less design, it connects the LED module and the system part of the cabinet with no cables, allowing simple power/signal connection to be automatically completed when LED module is installed. Fully enclosed connection improves its hardware reliability as well.
    GSEG is a cable-less design allowing for simple power/signal connection and is easy to install and maintain. GSEG is a cable-less design allowing for simple power/signal connection and is easy to install and maintain.

    Compatibility with LG Software Solutions

    When connected with LG's CVEA system controller, the GSEG series is compatible with LG software solutions including SuperSign CMS, LED Assistant, and ConnectedCare, which help customers operate their own business properly.
    The LG employee is remotely monitoring the GSEG series installed in a different place by using a cloud-based LG monitoring solution. System controller with webOS enables GSEG series to be compatible with LG software solutions. The LG employee is remotely monitoring the GSEG series installed in a different place by using a cloud-based LG monitoring solution. System controller with webOS enables GSEG series to be compatible with LG software solutions.
    * The availability of the 'LG ConnectedCare' service differs by region, and it needs to be purchased separately. So please contact the LG sales representative in your region for more details.
    * The items that can be monitored by LG ConnectedCare : Main Board (Temp., Signal Status, FPGA Ver, Ethernet Connection Status), Receiving Card (Temp., LED Power)
    * Actual GUI may vary in different webOS versions.
    * LG Software solutions needs to be purchased separately.
    Close
    Physical Parameters
    • Pixel Configuration
      Single SMD
      Pixel Pitch (mm)
      10.42
    • Module Resolution (W x H)
      48x32
      Module Dimensions(WxH,mm)
      500x333.33
    • Weight per Module (kg)
      2.05
      No. of Modules per Cabinet (WxH)
      2X3
    • Cabinet Resolution (WxH)
      96x96
      Cabinet Dimensions (W x H x D, mm)
      1,000x1,000x105
    • Cabinet Surface Area (㎡)
      1.000
      Weight per Cabinet (kg/unit)
      25.0
    • Weight per Square Meter (kg/m2)
      25.0
      Physical Pixel Density (pixels/m2)
      9,216
    • Flatness of Cabinet (mm)
      ±1.0
      Cabinet Material
      Aluminum
    • Service Access
      Front and Rear
    OPTICAL SPECIFICATIONS
    • Max Brightness (After Calibration, nit)
      6,000
      Color Temperature (K)
      3,200 - 9,300
    • Visual Viewing Angle (Horizontal)
      160
      Visual Viewing Angle (Vertical)
      130
    • Brightness Uniformity
      97%
      Color Uniformity
      ±0.05Cx,Cy
    • Contrast Ratio
      8,000:1
      Processing Depth (bit)
      16 (HDR10, HDR10 Pro)
    ELECTRICAL SPECIFICATIONS
    • Power Consumption (W/Cabinet, Max.)
      680
      Power Consumption (W/Cabinet, Avg.)
      272
    • Power Consumption (W/m2, Max.)
      680
      Heat Dissipation (BTU/h/Cabinet, Max.)
      2,321
    • Heat Dissipation (BTU/h/Cabinet, Avg.)
      928
      Heat Dissipation (BTU/h/m2, Max.)
      2,321
    • Power Supply (V)
      100 to 240
      Frame Rate (Hz)
      50 / 60
    • Refresh Rate (Hz)
      7,680
    OPERATION SPECIFICATIONS
    • LED Lifetime (Half brightness)
      100,000
      Operating Temperature(℃)
      -30°C to +50°C
    • Operating Humidity
      0~90%RH
      IP Rating Front
      IP66
    • IP Rating Rear
      IP66
    Certification
    • Certification
      CE, FCC, ETL
    Environment
    • Environment
      RoHS, REACH
    Controller
    • Controller
      CVEA
    90 Degree Corner Cut
    • 90 Degree Corner Cut
      Yes
    Series
    • Series
      GSEG

    To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
