    LAD033F component-copyModelName
    LG Miraclass, 4K Screen

    Key Features

    Choose your Pitch

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (LAD033F)
      $
      $
      LG Members Price
    Total
    Add to CompareAdd to CompareRemove Compare

    component-OBScountrySelectDesc

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (LAD033F)
      $
      $
      LG Members Price
    Total
    LG Miraclass, 4K Screen
    Contact Us
    LAD033F-01-Outshine-the-Limitation-Find-the-Opportunities-Unreleased-Indoor-LED-Signage-ID-D LAD033F-01-Outshine-the-Limitation-Find-the-Opportunities-Unreleased-Indoor-LED-Signage-ID-M
    * All images in this page are for illustrative purposes only.

    Discover New Depths with
    True Black Immersion

    With its series of individual, self-emissive LEDs, the LED screen of LG Miraclass results in distinctive
    and eye-catching contrast, taking the viewing experience to a whole new level.
    The LG Miraclass embodies a distinct black color, showing the contrast between the dark shadow and the bright Earth. The LG Miraclass embodies a distinct black color, showing the contrast between the dark shadow and the bright Earth.

    Feast Your Eyes
    on a Festival of Color

    With 24-bit color processing, capable of displaying 68.7 billion color variants,
    the LG Miraclass reproduces DCI-P3 colors just as the content creators intended.
    The audience at the theater are watching a racing scene that shows the colors the filmmaker intended. The audience at the theater are watching a racing scene that shows the colors the filmmaker intended.

    Brightness Brings Detail to Life

    The LG Miraclass is made up of self-emissive LEDs working independently.
    The result is bright and brilliant picture quality, with no corner dimming or image distortion.
    A man is shown snowboarding down a snowy mountain. In this scene, the edges of the screen are darkened using Single Light Source Projection, while the Self-Emissive LED Screen shows the color distinctly and clearly. A man is shown snowboarding down a snowy mountain. In this scene, the edges of the screen are darkened using Single Light Source Projection, while the Self-Emissive LED Screen shows the color distinctly and clearly.

    The Optimal Space Utilization

    As LG Miraclass does not need a projection room, a space behind the stuffy theater can be reinvented to more customer satisfying interiors.
    While the conventional projector-style theater requires a projection room, the LG Miraclass does not, thereby creating more space in the back of the theater. While the conventional projector-style theater requires a projection room, the LG Miraclass does not, thereby creating more space in the back of the theater.

    Dolby-Compatible LED Screen

    The new LG Miraclass can be quickly and seamlessly integrated into theaters, thanks to its compatibility with Dolby. Dolby IMS supports stable and professional content operation, while the combination of Dolby Atmos sound and LG picture quality makes movies truly memorable.
    LG Miraclass screen is compatible with Dolby. LG Miraclass screen is compatible with Dolby.
    * Dolby, Dolby Atmos and the double-D symbol are registered trademarks of Dolby Laboratories.
    Explore more showroom at<br>LG Digital Connect1 Explore more showroom at<br>LG Digital Connect2

    Explore more showroom at
    LG Digital Connect

    Explore
    Close
    Physical Parameters
    • Pixel Pitch (mm)
      3.3mm
      Pixel Configuration
      SMD
    • LED Lifetime (Half Brightness)
      100,000 Hours
      No. of Modules per Cabinet (WxH)
      6 (2 x 3)
    • Cabinet Resolution (W × H)
      192 x 270
      Cabinet Material
      Iron & Aluminum
    • Cabinet Dimensions (W x H x D, mm)
      Main : 640 x 900 x 94 (191 w/back cover)
      Secondary : 640 x 900 x 94 (124 w/handle)
      Weight per Cabinet (kg/unit)
      Main : 29
      Secondary : 15
    • Power Consumption (W/Cabinet, 48 nit)
      140 (Main) / 52 (Secondary)
      Power Consumption (W/Cabinet, 100 nit)
      160 (Main) / 70 (Secondary)
    • Service Access
      Rear only
    4K Screen Specifications
    • Screen Resolution (WxH, Native)
      4,224 x 2,160
      Physical Pixel Density (pixels/㎡)
      90,000
    • No. of Cabinets per Screen (Resolution, WxH)
      176 (22 x 8)
      Screen Dimensions (W x H, mm)
      14,080 x 7,200 (101 sqm)
    • Screen Weight (kg)
      2,654
      Power Supply (V)
      AC100-240 V ~, 50/60 Hz
    • Power Type
      Built-in Power
      Power Consumption (W/Screen, 48 nit)
      9,240
    • Power Consumption (W/Screen, 100 nit in Only LAD033F)
      12,410
      Operating Temperature(℃)
      0℃ to 40℃
    • Operating Humidity
      10% to 80%
    OPTICAL SPECIFICATIONS
    • Video Frame Rate (Hz)
      24, 25, 30, 48, 50, 60, 144@3D
      Refresh Rate (@24Hz)
      3,072
    • Brightness (After Calibration, nit)
      48(DCI) / 55 / 65 / 75 / 100
      Contrast Ratio
      ≥4,000:1
    • Color Space (Gamut)
      DCI P3 Theater
      Visual Viewing Angle (H × V)
      160 × 160
    • Processing Depth (bit)
      16bit
      Bit Rate (Color Processing / Color)
      15 (45 / total)
    General
    • Certification
      DCI, CB, CE-LVD/EMC, FCC, ETL/UL, RoHS, REACH
      Cinema server compatibility
      Dolby IMS3-L
    • Interface
      RJ45, HDMI (on IMS server)
    Series
    • Series
      LADF
    • Dimension
      • main-2d_p19_191224.dwg
      • secondary-2d_p20_191224.dwg
      • main-2d_p19_191224.pdf
      • secondary-2d_p20_191224.pdf
    • Datasheet
      • LAD033F_Datasheet(low)_LG Miraclass_240507 1.pdf
    • Software

      To download Software, Please visit the Software Download Page (Click).

    • Manual

      To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).

    To access more technical documentation and downloads, please visit the LG B2B Partner Portal.

    Find a dealer to help with service for sales, installation, and after sales.
    Business Unit is required
    Address Unit is required.
    • sales
    • install
    • service
    Please retry to enter zip code.

    There is no data. Please retry to enter zip code.

    Compare

    0
    Compare 0
    LG Electronics is focused on developing new innovations across Digital Signage. We are committed to providing commercial electronic products that help businesses perform better. To support this, we have developed unique LED Signage. We offer a wide range of products, including information displays, digital signage for advertising, commercial system air conditioners, VRF systems & tailored solutions for different vertical markets. Find out more about our LED Signage today. Contact your local LG representative for more information.
