    LG Indoor LED
    Contact Us

    LED Display for
    Virtual Production

    A virtual production studio with curved LED walls and ceiling and floor LEDs is filming images of a forest and field landscape. A virtual production studio with curved LED walls and ceiling and floor LEDs is filming images of a forest and field landscape.
    * All images in this page are for illustrative purposes only.

    Easy Installation & Maintenance

    The module can be easily removed using the dedicated tool (with front or rear selective service access). The positioning pins and magnets help perform panel adjustments accurately and quickly, ensuring seamless screen assembly.
    The 'Positioning Pins', 'Magnetic Assembly', 'Comfortable Handles', and 'Fast Lock & One-handed Control' parts in the cabinet are enlarged. The 'Positioning Pins', 'Magnetic Assembly', 'Comfortable Handles', and 'Fast Lock & One-handed Control' parts in the cabinet are enlarged.

    Curve Effect Available

    The mechanical connection between the two panels is secured by an angle adapter system and a fast lock, adjustable by 10 degrees in concave areas and 5 degrees in convex areas.
    Curved LED walls are installed in a studio. Curved LED walls are installed in a studio.

    Stacking & Hanging System Available

    Installation can be performed by stacking or hanging, using the optional accessories (single, double, triple beams) for customization to the studio environment.
    The part where the cabinet can be installed either as stacking or hanging is enlarged and shown. The part where the cabinet can be installed either as stacking or hanging is enlarged and shown.

    Broadcast Quality Available

    Accurate color reproduction, low latency of video processing, and HDR capability.
    A vivid HDR-enabled screen and a screen with a high refresh rate displaying the exact color are being shown. A vivid HDR-enabled screen and a screen with a high refresh rate displaying the exact color are being shown.

    Powerful UI/UX with
    Megapixel VR HELIOS LED Processing Platform

    Thanks to the compatibility between LBCG and the Megapixel VR HELIOS LED processing platform, you can now utilize the powerful UX and UI functionalities offered by HELIOS. HELIOS processing platform includes Real-Time Mapping and Multi-User Control, Superior Color Control, Hyper-Speed Seam Correction using a game controller, and Monitoring and Diagnostics through connected diagnostics.
    The Megapixel VR HELIOS LED processing platform provides access to the features such as Real-Time Mapping and Multi-Use Control, Superior Color Control, Hyper-Speed Seam Correction using a Game Controller, and Monitoring and Diagnostics using Connected Diagnostics. The Megapixel VR HELIOS LED processing platform provides access to the features such as Real-Time Mapping and Multi-Use Control, Superior Color Control, Hyper-Speed Seam Correction using a Game Controller, and Monitoring and Diagnostics using Connected Diagnostics.
    * Please note that Megapixel VR HELIOS LED processing platform needs to be purchased separately, and depending on the actual usage environment, there may be limitations in the implementation of certain features offered by HELIOS. A game controller needs to be purchased separately.
    Close
    Physical Parameters
    • Pixel Configuration
      Single SMD
      Pixel Pitch(mm)
      2.6
    • Module Resolution (WxH)
      96x96
      Module Dimensions(WxH,mm)
      250x250
    • Weight per Module (kg)
      0.6
      No. of Modules per Cabinet (WxH)
      2 x 2
    • Cabinet Resolution (WxH)
      192x192
      Cabinet Dimensions (W x H x D, mm)
      500x500x75.5
    • Cabinet Surface Area (㎡)
      0.25
      Weight per Cabinet (kg/unit)
      6.2
    • Weight per Square Meter (kg/m2)
      24.8
      Physical Pixel Density (pixels/m2)
      147,456
    • Flatness of Cabinet (mm)
      ±0.15
      Cabinet Material
      Die-casting Magnesium
    • Service Access
      Front or Rear
      (select one only)
    OPTICAL SPECIFICATIONS
    • Max Brightness (After Calibration, nit)
      1,500
      Color Temperature (K)
      3,500~9,000
    • Visual Viewing Angle (Horizontal)
      160
      Visual Viewing Angle (Vertical)
      160
    • Brightness Uniformity
      0.97
      Color Uniformity
      ±0.003Cx,Cy
    • Contrast Ratio
      5,000:1
      Processing Depth (bit)
      16 (PQ, HLG)
    ELECTRICAL SPECIFICATIONS
    • Power Consumption (W/Cabinet, Max.)
      180
      Power Consumption (W/Cabinet, Avg.)
      60
    • Power Consumption (W/m2, Max.)
      720
      Heat Dissipation (BTU/h/Cabinet, Max.)
      614
    • Heat Dissipation (BTU/h/Cabinet, Avg.)
      205
      Heat Dissipation (BTU/h/m2, Max.)
      2,457
    • Power Supply (V)
      100 to 240
      Frame Rate (Hz)
      50 / 60
    • Refresh Rate (Hz)
      7,680
    OPERATION SPECIFICATIONS
    • LED Lifetime (Half brightness)
      100,000
      Operating Temperature(℃)
      -10℃ to +45℃
    • Operating Humidity
      0~80%RH
      IP Rating Front
      IP30
    • IP Rating Rear
      IP30
    Standard
    • Certification
      CE, FCC, ETL
    Environment
    • Environment
      RoHS, REACH
    Controller
    • Controller
      (MVR HEIOS)
    Series
    • Series
      LBCG

    To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
