    LDAA025-1 component-copyModelName
    LG Miraclass, 2K Screen

    Key Features

    Choose your Pitch

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (LDAA025-1)
      $
      $
      LG Members Price
    Total
    Add to CompareAdd to CompareRemove Compare

    component-OBScountrySelectDesc

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (LDAA025-1)
      $
      $
      LG Members Price
    Total
    LG Miraclass, 2K Screen
    Contact Us
    A large LED screen is showing a colorful and lively action scene at the movie theater. A large LED screen is showing a colorful and lively action scene at the movie theater.
    * All images in this page are for illustrative purposes only.

    Discover New Depths with True Black Immersion

    With its series of individual, self-emissive LEDs, the LED screen of LG Miraclass results in distinctive and eye-catching contrast, taking the viewing experience to a whole new level.
    he LED Cinema embodies a distinct black color, showing the contrast between the dark shadow and bright sky he LED Cinema embodies a distinct black color, showing the contrast between the dark shadow and bright sky

    Feast Your Eyes
    on a Festival of Color

    With 24-bit color processing, capable of displaying 68.7 billion color variants,
    the LG Miraclass reproduces DCI-P3 colors just as the content creators intended.
    The audience at the theater are watching a racing scene that shows the colors the filmmaker intended. The audience at the theater are watching a racing scene that shows the colors the filmmaker intended.

    Brightness Brings Detail to Life

    The LG Miraclass is made up of self-emissive LEDs working independently.
    The result is bright and brilliant picture quality, with no corner dimming or image distortion.
    A man is shown snowboarding down a snowy mountain. In this scene, the edges of the screen are darkened using Single Light Source Projection, while the Self-Emissive LED Screen shows the color distinctly and clearly. A man is shown snowboarding down a snowy mountain. In this scene, the edges of the screen are darkened using Single Light Source Projection, while the Self-Emissive LED Screen shows the color distinctly and clearly.

    Brightness to Illuminate
    and Inspire

    Adjust the brightness to your preferred setting, with five stages ranging from 48 to 300 nits.
    Personalize your viewing experience and make your media the highlight.
    Screens of various brightness ranging from 48 to 300 nits are being shown, which can support not only movie screenings but also corporate events. Screens of various brightness ranging from 48 to 300 nits are being shown, which can support not only movie screenings but also corporate events.

    Take Picture Quality
    to Another Dimension

    With consistent brightness and clarity from corner to corner of the screen, audiences can fully
    immerse themselves in the 3D viewing experience, wherever they sit.
    In the movie theater, people are watching the movie wearing 3D glasses, and the 3D screen’s liveliness is being conveyed to the audience. In the movie theater, people are watching the movie wearing 3D glasses, and the 3D screen’s liveliness is being conveyed to the audience.
    * 3D active glasses (Volfoni, XpanD) are required.

    Easy Operation with
    Intuitive Software

    Dedicated management software is on hand to help operators run the new LED screens smoothly
    and with confidence. Various functions can now be accessed at the touch of a button.
    Movie theater manager is simply adjusting movie theater screen settings in the office. Movie theater manager is simply adjusting movie theater screen settings in the office.
    * The above image is for illustration purposes only. Actual GUI may differ.

    Dolby-Compatible LED Screen

    The new LG Miraclass can be quickly and seamlessly integrated into theaters, thanks to its compatibility with Dolby. Dolby IMS supports stable and professional content operation, while the combination of Dolby Atmos sound and LG picture quality makes movies truly memorable.
    LG Miraclass screen is compatible with Dolby. LG Miraclass screen is compatible with Dolby.
    * Dolby, Dolby Atmos and the double-D symbol are registered trademarks of Dolby Laboratories.
    Explore more showroom at<br>LG Digital Connect1 Explore more showroom at<br>LG Digital Connect2

    Explore more showroom at
    LG Digital Connect

    Explore
    Close
    Physical Parameters
    • Pixel Pitch (mm)
      2.5mm
      Pixel Configuration
      SMD
    • LED Lifetime (Half Brightness)
      100,000 Hours
      No. of Modules per Cabinet (WxH)
      6 (2 x 3)
    • Cabinet Resolution (W × H)
      256 x 180
      Cabinet Material
      Aluminum
    • Cabinet Dimensions (W x H x D, mm)
      Main : 640 x 450 x 59 (163 w/back cover)
      Secondary : 640 x 450 x 59 (101 w/handle)
      Weight per Cabinet (kg/unit)
      Main Cabinet : 13.8
      Secondary : 7.5
    • Power Consumption (W/Cabinet, 48 nit)
      130 (Main) / 40 (Secondary)
      Power Consumption (W/Cabinet, 300nit)
      200 (Main) / 80 (Secondary)
    • Service Access
      Rear only
    4K Screen Specifications
    • Screen Resolution (WxH, Native)
      2,048 x 1,080
      Physical Pixel Density (pixels/㎡)
      160,000
    • No. of Cabinets per Screen (Resolution, WxH)
      48 (8 x 6)
      Screen Dimensions (W x H, mm)
      5,120 x 2,700 (14sqm)
    • Screen Weight (kg)
      366.3
      Power Supply (V)
      AC100-240 V ~, 50/60 Hz
    • Power Type
      Built-in Power
      Power Consumption (W/Screen, 48 nit)
      2,010
    • Power Consumption (W/Screen, 300 nit)
      3,960
      Operating Temperature(℃)
      0℃ to 40℃
    • Operating Humidity
      10% to 80%
    OPTICAL SPECIFICATIONS
    • Video Frame Rate (Hz)
      24, 25, 30, 48, 50, 60, 144@3D
      Refresh Rate (@24Hz)
      3,072@24Hz, 3,840@60Hz
    • Brightness (After Calibration, nit)
      48(DCI) / 55 / 65 / 75 / 100 / 130 / 260 / 300
      Contrast Ratio
      ≥4,000:1
    • Color Space (Gamut)
      DCI P3 Theater
      Visual Viewing Angle (H × V)
      160 × 160
    • Processing Depth (bit)
      15bit@24/48/50Hz
      Bit Rate (Color Processing / Color)
      24 (72 / total)
    General
    • Certification
      DCI, CB, CE-LVD/EMC, FCC, ETL/UL, RoHS, REACH
      Cinema server compatibility
      Dolby IMS3-L
    • Interface
      RJ45, HDMI x 2, RS232C
    Series
    • Series
      LDAA-1
    • Dimension
      • LDAA025-MD_2D.dwg
      • LDAA025-SD_2D.dwg
      • LDAA025-MD_2D.pdf
      • LDAA025-SD_2D.pdf
    • Datasheet
      • LDAA025_Datasheet(low)_LG Miraclass_240507 1.pdf
    • Software

      To download Software, Please visit the Software Download Page (Click).

    • Manual

      To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).

    To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
