    Digital Floor Series
    Contact Us

    Digital Floor Series

    LEDs on the wall and floor vividly show the landscape and a camera is capturing the scene. LEDs on the wall and floor vividly show the landscape and a camera is capturing the scene.
    * All images in this web page are for illustrative purposes only.
    This demonstrates that the LEDs can withstand the weight of a vehicle on them and still work well. This demonstrates that the LEDs can withstand the weight of a vehicle on them and still work well.

    High Durability

    LFCG is a unique display installed on the floor with high durability designed to load up to 2,500 kg/sqm.

    Excellent Usability

    Surface safety when installing the screen on the floor IP65 protective slip-resistant mat and reflection-reducing surfaces and high visual performance with high contrast LED for uniform visual performance in black are considered. New mask with diffusing powder has been applied for reducing the color shifting and refracting the light to various directions as considering its usage for XR Stage.
    LFCG was developed with a matte anti-slip and anti-reflective surface with IP65 protection. LFCG was developed with a matte anti-slip and anti-reflective surface with IP65 protection.
    * As the surface is made of polycarbonate, it may be susceptible to scratches (especially against metal).

    Easy Installation and Maintenance

    Its simple product structure allows for easy installation and quick maintenance. You can quickly deploy and connect the cabinets with the foot support system without any tools. A simple flush control mechanism design is applied to keep the height level regardless of floor type. In addition, magnets attached to the LED module allow for easy maintenance, and hot-swapping* is able during the display operation.
    It is easy to install LFCG by simply fixing the cabinet with the footer, and the magnets attached to the LED module allow for easy maintenance with the screen on. It is easy to install LFCG by simply fixing the cabinet with the footer, and the magnets attached to the LED module allow for easy maintenance with the screen on.
    * Hot Swapping : Swap module on-site during screen’s on the operation.
    Close
    Physical Parameters
    • Pixel Configuration
      Single SMD
      Pixel Pitch (mm)
      3.91
    • Module Resolution (W × H)
      64 × 64
      Module Dimensions (W × H, mm)
      250 × 250
    • Weight per Module (kg)
      0.90
      No. of Modules per Cabinet (W × H)
      2 × 2
    • Cabinet Resolution (W × H)
      128 × 128
      Cabinet Dimensions (W × H × D, mm)
      500 × 500 × 83.3
    • Cabinet Surface Area (m2)
      0.250
      Weight per Cabinet (kg/unit)
      11.5
    • Weight per Square Meter (kg/m2)
      46
      Physical Pixel Density (pixels/m2)
      65,536
    • Flatness of Cabinet (mm)
      ±0.3
      Cabinet Material
      Die Casting Aluminum
    • Service Access
      Front
    OPTICAL SPECIFICATIONS
    • Max. Brightness (After Calibration, nit)
      1,500
      Color Temperature (K)
      3,500-9,000
    • Visual Viewing Angle (Horizontal)
      160
      Visual Viewing Angle (Vertical)
      160
    • Brightness Uniformity
      0.97
      Color Uniformity
      ±0.003Cx,Cy
    • Contrast Ratio
      5,000:1
      Processing Depth (bit)
      15
    ELECTRICAL SPECIFICATIONS
    • Power Consumption (W/Cabinet, Max.)
      165
      Power Consumption (W/Cabinet, Avg.)
      55
    • Power Consumption (W/m2, Max.)
      660
      Heat Dissipation (BTU/h/Cabinet, Max.)
      563
    • Heat Dissipation (BTU/h/Cabinet, Avg.)
      187
      Power Supply (V)
      100 to 240
    • Frame Rate (Hz)
      50 / 60
      Refresh Rate (Hz)
      3,840
    OPERATION SPECIFICATIONS
    • Lifetime (Half brightness)
      100,000
      Operating Temperature (°C)
      -10° to +45°
    • Operating Humidity
      10 ~ 80%RH
      IP Rating Front
      IP65
    • IP Rating Rear
      IP65
    Standard
    • Certification
      CE, FCC, ETL, EMC Class A
    Environment
    • Environment
      RoHS, REACH
    Controller
    • LFCG039-EN
      LCIN010
      LFCG039-RN
      CVCA
    Series
    • Series
      LFCG
    • Dimension
      • LFCG039-GN-v1.0.dwg
      • LFCG039-GN-v1.0.pdf
    • Datasheet
      • LFCG Series_Datasheet(low)_LG LED Signage_241004.pdf
    • Software

      To download Software, Please visit the Software Download Page (Click).

    • Manual

      To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
