    LG Indoor LED
    Contact Us

    Floor LED Display for
    Virtual Productrion

    A virtual production studio with curved LED walls and ceiling and floor LEDs is filming images of a forest and field landscape. A virtual production studio with curved LED walls and ceiling and floor LEDs is filming images of a forest and field landscape.
    * All images in this page are for illustrative purposes only.
    This demonstrates that the LEDs can withstand the weight of a vehicle on them and still work well. This demonstrates that the LEDs can withstand the weight of a vehicle on them and still work well.

    High Durability

    LFCM is a unique display installed on the floor with high durability designed to load up to 1,500 kg/sqm.

    * The LFCM LED display passed a TüV Rheinland-approved compression test, where a vertical downward force was gradually applied until the display was broken (Test report No.: CN21Y9D3 001).
    LFCM is developed with an anti-slip and anti-reflective surface with IP65 protection, and features color uniformity in terms of its visual performance. LFCM is developed with an anti-slip and anti-reflective surface with IP65 protection, and features color uniformity in terms of its visual performance.

    Excellent Usability

    Surface safety when installing the screen on the floor IP65 protective slip-resistant mat and reflection-reducing surfaces and high visual performance with high contrast LED for uniform visual performance in black are considered. New mask with diffusing powder has been applied for reducing the color shifting and refracting the light to various directions as considering its usage for XR Stage.

    * As the surface is made of polycarbonate, it may be susceptible to scratches (especially against metal).

    Easy Installation and Maintenance

    The product features a simple structure that enables fast installation and easy maintenance. The cabinets can be easily deployed and connected using the foot support system. A straightforward flush control mechanism design helps to maintain consistent height levels on different types of floors. Additionally, the LED module is equipped with magnets for convenient maintenance, and hot swapping is possible even while the display is in operation.
    It is easy to install LFCM by simply fixing the cabinet with the footer, and the magnets attached to the LED module allow for easy maintenance with the screen on. It is easy to install LFCM by simply fixing the cabinet with the footer, and the magnets attached to the LED module allow for easy maintenance with the screen on.
    * Hot Swapping : Swap module on-site during screen’s on the operation.

    Powerful UI/UX with
    Megapixel VR HELIOS LED Processing Platform

    Thanks to the compatibility between LFCM and the Megapixel VR HELIOS LED processing platform, you can now utilize the powerful UX and UI functionalities offered by HELIOS. HELIOS processing platform includes Real-Time Mapping and Multi-User Control, Superior Color Control, Hyper-Speed Seam Correction using a game controller, and Monitoring and Diagnostics through connected diagnostics.
    The Megapixel VR HELIOS LED processing platform provides access to the features such as Real-Time Mapping and Multi-Use Control, Superior Color Control, Hyper-Speed Seam Correction using a Game Controller, and Monitoring and Diagnostics using Connected Diagnostics. The Megapixel VR HELIOS LED processing platform provides access to the features such as Real-Time Mapping and Multi-Use Control, Superior Color Control, Hyper-Speed Seam Correction using a Game Controller, and Monitoring and Diagnostics using Connected Diagnostics.
    * Please note that Megapixel VR HELIOS LED processing platform needs to be purchased separately, and depending on the actual usage environment, there may be limitations in the implementation of certain features offered by HELIOS. A game controller needs to be purchased separately.
    Close
    Physical Parameters
    • Pitch Name
      P3.91
      Pixel Configuration
      Single SMD
    • Pixel Pitch(mm)
      3.91
      Module Resolution (WxH)
      64x64
    • Module Dimensions(WxH,mm)
      250x250
      Weight per Module (kg)
      0.90
    • No. of Modules per Cabinet (WxH)
      2x2
      Cabinet Resolution (WxH)
      128x128
    • Cabinet Dimensions (W x H x D, mm)
      500x500x83.3
      Cabinet Surface Area (㎡)
      0.25
    • Weight per Cabinet (kg/unit)
      12
      Weight per Square Meter (kg/m2)
      48
    • Physical Pixel Density (pixels/m2)
      65,536
      Flatness of Cabinet (mm)
      ±0.5
    • Cabinet Material
      Die-casting Aluminum
      Service Access
      Front
    OPTICAL SPECIFICATIONS
    • Max Brightness (After Calibration, nit)
      1,500
      Color Temperature (K)
      3,500~9,000
    • Visual Viewing Angle (Horizontal)
      160
      Visual Viewing Angle (Vertical)
      160
    • Brightness Uniformity
      0.97
      Color Uniformity
      ±0.003Cx,Cy
    • Contrast Ratio
      5,000:1
      Processing Depth (bit)
      16
    ELECTRICAL SPECIFICATIONS
    • Power Consumption (W/Cabinet, Max.)
      180
      Power Consumption (W/Cabinet, Avg.)
      60
    • Power Consumption (W/m2, Max.)
      720
      Heat Dissipation (BTU/h/Cabinet, Max.)
      819
    • Heat Dissipation (BTU/h/Cabinet, Avg.)
      273
      Heat Dissipation (BTU/h/m2, Max.)
      3,276
    • Power Supply (V)
      100 to 240
      Frame Rate (Hz)
      50 / 60
    • Refresh Rate (Hz)
      7,680
    OPERATION SPECIFICATIONS
    • LED Lifetime (Half brightness)
      100,000
      Operating Temperature(℃)
      -10℃ to +45℃
    • Operating Humidity
      0~80%RH
      IP Rating Front
      IP65
    • IP Rating Rear
      IP65
    Standard
    • Certification
      CE, FCC, ETL
    Environment
    • Environment
      RoHS, REACH
    Controller
    • Controller
      (MVR HEIOS)
    Series
    • Series
      LFCM

    To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
