- Pixel Configuration
- 3 in 1 SMD
- Pixel Pitch (mm)
- 2.976
-
- Module Resolution (W × H)
- 84 × 84
- Module Dimensions (W × H, mm)
- 250 × 250
-
- Weight per Module (kg, ±0.003 kg)
- 0.70
- No. of Modules per Cabinet (W × H)
- 2 × 4
-
- Cabinet Resolution (W × H)
- 168 × 336
- Cabinet Dimensions (W × H × D, mm)
- 500 × 1,000 × 68
-
- Cabinet Surface Area (m2)
- 0.500
- Weight per Cabinet (kg/Cabinet)
- 12.0
-
- Weight per Square Meter (kg/m2)
- 24.0
- Physical Pixel Density (pixels/m2)
- 112,896
-
- Flatness of Cabinet (mm)
- 0.5
- Cabinet Material
- Die Casting Aluminum
-
- Service Access
- Front or Rear
-
- Max. Brightness (After Calibration)
- 1,000
- Color Temperature (K)
- 3,200-9,300
-
- Visual Viewing Angle (H × V)
- 160 × 140
- Brightness Uniformity
- 97%
-
- Color Uniformity
- ±0.003 Cx,Cy
- Contrast Ratio (Typ.)
- 5,000 : 1
-
- Processing Depth (bit)
- 16 (HDR10, HDR10 Pro)
-
- Power Consumption (W/Cabinet, Max.)
- 300
- Power Consumption (W/Cabinet, Avg.)
- 100
-
- Power Consumption (W/m2, Max.)
- 600
- Power Consumption (BTU/Cabinet, Max.)
- 1,024
-
- Power Consumption (BTU/Cabinet, Avg.)
- 341
- Power Consumption (BTU/m2, Max.)
- 2,047
-
- Power Supply (V)
- 100 to 240
- Frame Rate (Hz)
- 50 / 60
-
- Refresh Rate (Hz)
- ≥3,840
-
- Lifetime (Half brightness)
- 100,000
- Operating Temperature (°C)
- -20 to +40
-
- Operating Humidity
- 10-90% RH
- IP Rating Front / Rear
- IP5X / IP5X
-
- Series
- LSBC
To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
