Fast Installation
Easy Maintenance
Two Cabinet Options
90° Corner Design Available
Front or Rear Serviceability
Compatibility with
LG Software Solutions
* The items that can be monitored by LG ConnectedCare : Main Board (Temp., Signal Status, FPGA Ver, Ethernet Connection Status), Receiving Card (Temp., LED Power)
Explore more showroom at
LG Digital Connect
-
- Pixel Configuration
- 3 in 1 SMD
- Pixel Pitch (mm)
- 2.97
-
- Module Resolution (W x H)
- 84 × 168
- Module Dimensions (W x H, mm)
- 250 × 500
-
- Weight per Module (kg)
- 1.30
- No. of Modules per Cabinet (W × H)
- 2 × 2 / 2 × 1 (Half-sized)
-
- Cabinet Resolution (W × H)
- 168 × 336 / 168 × 168 (Half-sized)
- Cabinet Dimensions (W × H × D)
- 500 × 1,000 × 74.88 / 500 × 500 × 74.88 (Half-sized)
-
- Cabinet Surface Area (m2)
- 0.500 / 0.250 (Half-sized)
- Weight per Cabinet (kg/cabinet)
- 12.5 / 8.5 (Half-sized)
-
- Weight per Square Meter (kg/m2)
- 25.0 / 34.0 (Half-sized)
- Physical Pixel Density (pixels/m2)
- 112,896
-
- Flatness of Cabinet
- ± 0.3 mm
- Cabinet Material
- Die Casting Aluminum Alloy
-
- Service Access
- Front or Rear (One Option Only)
-
- Max Brightness (After Calibration)
- 1,000
- Color Temperature
- 3,200-9,300 (K)
-
- Visual Viewing Angle (Horizontal)
- 160
- Visual Viewing Angle (Vertical)
- 160
-
- Brightness Uniformity
- 97%
- Color Uniformity
- ± 0.003 Cx,Cy
-
- Contrast Ratio
- 5,000
- Processing Depth (bit)
- 14
-
- Power Consumption (W/Cabinet, Max.)
- 270 / 135 (Half-sized)
- Power Consumption (W/Cabinet, Avg.)
- 90 / 45 (Half-sized)
-
- Power Consumption (W/m2, Max.)
- 540
- Power Supply (V)
- 100 to 240
-
- Frame Rate (Hz)
- 50 / 60
- Refresh Rate (Hz)
- 2,880
-
- Lifetime (Hours to Half Brightness)
- 100,000
- Operating Temperature (°C)
- -10 °C to +45 °C
-
- Operating Humidity
- 0 - 80 % RH
- IP rating Front / Rear
- IP30 / IP30
-
- Input Interface
- HDMI / DP / OPS / USB
- Input Resolution
- 3,840 x 2,160 @60Hz
-
- Output Signal
- Gigabit Ethernet (16 ea)
- Output Fiber Optical
- No
-
- Control RJ45
- Yes
- Control USB
- No
-
- Electrical Power Consumption (W)
- 50
- Electrical Power Supply (V)
- AC 100-240 V
-
- Mechanical Size (mm)
- 443 (W) × 307.5 (D) × 63 (H) → EIA Standard Rack (2U)
- Mechanical Weight (kg)
- 4.9
-
- Feature Signal Redundancy
- Yes
- Feature HDR10
- Yes
-
- Input Interface
- HDMI / DVI
- Input Resolution
- 1,920 x 1,200 @60Hz
-
- Output Signal
- Gigabit Ethernet (4 ea)
- Output Fiber Optical
- No
-
- Control RJ45
- No
- Control USB
- Yes
-
- Electrical Power Consumption (W)
- 16
- Electrical Power Supply (V)
- AC 100-240 V
-
- Mechanical Size (mm)
- 482.6 (W) × 250 (D) × 44.45 (H) → EIA Standard Rack (1U)
- Mechanical Weight (kg)
- 2.9
-
- Feature Signal Redundancy
- Yes
- Feature HDR10
- No
-
- Input Interface
- HDMI / DVI / DP
- Input Resolution
- 3,840 x 2,160 @60Hz
-
- Output Signal
- Gigabit Ethernet (16 ea)
- Output Fiber Optical
- 4 ea
-
- Control RJ45
- Yes
- Control USB
- Yes
-
- Electrical Power Consumption (W)
- 30
- Electrical Power Supply (V)
- AC 100-240 V
-
- Mechanical Size (mm)
- 482.6 (W) × 250 (D) × 96 (H) → EIA Standard Rack (3U)
- Mechanical Weight (kg)
- 4.6
-
- Feature Signal Redundancy
- Yes
- Feature HDR10
- Yes
-
- Series
- LSCA
To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
