    55EW5G-V component-copyModelName
    Transparent OLED Signage

    Key Features

    Choose your Size

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (55EW5G-V)
      $
      $
      LG Members Price
    Total
    Add to CompareAdd to CompareRemove Compare

    component-OBScountrySelectDesc

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (55EW5G-V)
      $
      $
      LG Members Price
    Total
    Transparent OLED Signage
    Contact Us

    See the unseen,
    LG Transparent OLED

    LG Transparent OLED Signage offers new ways to communicate visually and opens up a whole new level of creativity that even conventional digital signage cannot offer.
    People analyze their work using the transparent OLED screens installed on the wall of the lobby. People analyze their work using the transparent OLED screens installed on the wall of the lobby.
    * All images are for illustrative purposes only.
    Information about structures is displayed on the transparent OLED screens which are set up in front of the miniature structures. Information about structures is displayed on the transparent OLED screens which are set up in front of the miniature structures.

    High Transparency

    LG’s OLED technology makes the Transparent OLED Signage have slimmer structure without backlight unit nor a liquid crystal layer, achieving high transparency of 38%* much higher than conventional LCD transparent displays (10%**). While clearly showing objects behind the screen, it overlays the relevant information right before them.
    * The Year of Measurement : 2018
    Measurement Method : Checking Transparency Using a Hazemeter
    Conducted by : LGD - internal testing

    ** Based on LG’s WFB series.
    A man is being shown information and photos of the dessert menu on the transparent OLED screens. A man is being shown information and photos of the dessert menu on the transparent OLED screens.

    Accurate
    and Vivid Colors

    Featuring self-lighting pixels, the display maintains vivid colors and high contrast ratio even when the display becomes transparent. It brings content to life from wide viewing angles, and the content blends into its surroundings seamlessly and naturally.
    A thin and transparent tempered glass is attached to the Transparent OLED screen. A thin and transparent tempered glass is attached to the Transparent OLED screen.

    Protective Tempered Glass

    Touching a display directly can cause damage or scratches. The tempered front glass protects product from such external impacts and its anti-shatter glass is designed to minimize customers’ injuries.
    * Optically Clear Adhesive
    A woman reviews her work by looking at it on the transparent OLED screens installed on the office windows. A woman reviews her work by looking at it on the transparent OLED screens installed on the office windows.

    Expandable Design
    (2×N Tiling)

    LG Transparent OLED Signage is designed as a semi-assembled display, meaning you can install it in various ways to fit into existing structures and spaces. With a variety of forms of installation*, it can complement any venue in which it is installed.
    * Installation accessories are not supplied by LG.
    Close
    Panel
    • Screen Size
      55"
      Panel Technology
      OLED
    • Native Resolution
      1,920 x 1,080 (FHD)
      Brightness
      150/400nit (APL 100%/25%, Without Glass)
    • Contrast Ratio
      150,000 : 1
      Dynamic CR
      No
    • Color gamut
      BT709 120 %
      Viewing Angle (H x V)
      178 x 178
    • Color Depth
      10bit(R), 1.07Bilion colors
      Response Time
      1ms (G to G), 8ms (MPRT)
    • Surface Treatment (Haze)
      Hard coating (2H)
      Operation Hours (Hours / Day)
      18 / 7 (Moving Content Only)
    Connectivity
    • Input
      HDMI (1, HDCP 1.4), DP (1, HDCP 1.3), RS232C IN , RJ45(LAN), IR IN (1,External IR Receiver,) USB2.0 Type A(2)
      Output
      DP Out, Audio Out, RS232C OUT (1, w/ IR out), RJ45(LAN)
    Mechanical Specification
    • Bezel Width
      T/R/L/B : 7.9/7.9/7.9/121.7mm
      Weight (Head)
      11.6Kg (Head), 3.4Kg (Signage Box)
    • Monitor Dimension (W x H x D)
      1225.5 x 810.1 x 4.9mm (Head)
      782.8 x 238.4 x 34.7mm (Signage Box)
      VESA? Standard Mount Interface
      No
    • Protection Glass
      Depth 3.0 mm , Tempered / Chemical Strengthening, Anti-Reflective (Film), Shatter-Proof
    Feature
    • HW
      Temperature Sensor
      SW
      Fail over, Screen Rotation, External Input Rotation, Tile Mode Setting,
    Environment Conditions
    • Operation Temperature
      0 °C to 40 °C
      Operation Humidity
      10 % to 80 %
    Power
    • Power Supply
      AC 100-240V~, 50/60Hz
      Power Type
      Built-In Power
    Power Consumption
    • Typ.
      171W (IEC 62087)
      Max.
      280W
    • Typ. / Max.
      250 W / 280 W
      BTU (British Thermal Unit)
      853.03 BTU/Hr(Typ.), 955.39 BTU/Hr(Max)
    Sound
    • Speaker
      No
    Certification
    • Safety
      IEC 60950-1 / EN 60950-1 / UL 60950-1
      EMC
      FCC Class "A" / CE / KC
    Accessory
    • Basic
      Remote Controller(include battery 2ea), Power Cord, QSG, IR receiver, Regulation Book, Phone to RS232C Gender, MCX/Harness Cables(3000mmx4ea/3000mmx2ea) for connection between panel and Signage Box), DP Cable(2M), LAN Cable(1.5M), RS232 Cable(4P-4P,1.5M), LC Cable(VLC,3M), Screw(M4xL22,12EA / M4 Nut 12EA / M3xL5.5,8EA / M3xL3.5, 20EA), Shield Cover Assy', Rubber Damper 4EA, MCX cable Holder 4ea
      Optional
      Stand (ACC-S-EW5F, 2 Pole)
    • Datasheet
      • 55EW5G-V_Datasheet(low)_LG T-OLED_210325.pdf
    • Software

      To download Software, Please visit the Software Download Page (Click).

    • Manual

      To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).

    To access more technical documentation and downloads, please visit the LG B2B Partner Portal.

    Find a dealer to help with service for sales, installation, and after sales.
    Business Unit is required
    Address Unit is required.
    • sales
    • install
    • service
    Please retry to enter zip code.

    There is no data. Please retry to enter zip code.

    Compare

    0
    Compare 0
    Product design, features and specifications are subject to change without notice and may also differ based on your region of purchase. Screen images simulated and/or dramatized. Some features in videos may not be available on all models. Please refer to the TECHNICAL SPECIFICATIONS tab for a complete list of features by model.
