    55EW5Q-C component-copyModelName
    Transparent OLED

    Key Features

    Choose your Size

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (55EW5Q-C)
      $
      $
      LG Members Price
    Total
    Add to CompareAdd to CompareRemove Compare

    component-OBScountrySelectDesc

    See Retailer for Pricing

    Limited Quantity Sale

    Available QTY 0
    • vip-price-message
      (55EW5Q-C)
      $
      $
      LG Members Price
    Total
    Transparent OLED
    Contact Us

    See the unseen,
    LG Transparent OLED

    A cafe has Transparent OLED Signage installed, and a woman is checking the menu by looking at the Transparent OLED Signage screen A cafe has Transparent OLED Signage installed, and a woman is checking the menu by looking at the Transparent OLED Signage screen
    * All images in this page are for illustrative purposes only.
    Transparent OLED Signage is installed in front of a table upon which cell phones are displayed in a cell phone store. The Transparent OLED Signage screen is showing an advertisement, and the cell phones displayed behind the screen are also clearly visible. Transparent OLED Signage is installed in front of a table upon which cell phones are displayed in a cell phone store. The Transparent OLED Signage screen is showing an advertisement, and the cell phones displayed behind the screen are also clearly visible.

    High Transparency

    LG’s OLED technology enables the Transparent OLED Signage to have a sleek design without the need for a backlight unit or liquid crystal layer, achieving an impressive 43%* transparency. It clearly displays objects behind the screen while overlaying relevant information right in front of them.

    * The Year of Measurement : 2022
    Measurement Method : Checking Transparency Using a Hazemeter
    Conducted by : LG Display - internal testing
    Attach thin and transparent tempered glass to the screen to maximize product protection and user safety. Attach thin and transparent tempered glass to the screen to maximize product protection and user safety.

    Protective Tempered Glass

    Touching a display directly can cause damage or scratches. The tempered glass in front protects the product from such external impacts and its anti-shatter glass is designed to help minimize customers' injuries.

    * Optically Clear Adhesive

    Sleek Elegance in Transparency

    By connecting spaces and creating a sense of openness, this transparent display features a stunning design that enhances high-end furniture and luxurious interiors. It is designed as a semi-assembled display, allowing for versatile installation options to seamlessly integrate into existing structures and spaces.
    There’s an open display unit in the large lounge with a transparent OLED screen installed in its center. The screen shows an image of a tree along with the current time and weather information, and the scenery visible through the transparent screen makes the space feel more expansive. There’s an open display unit in the large lounge with a transparent OLED screen installed in its center. The screen shows an image of a tree along with the current time and weather information, and the scenery visible through the transparent screen makes the space feel more expansive.
    Close
    Info
    • Product
      OLED (Transparent)
      Year
      Y24
    • Month
      M12
    Panel
    • Screen Size (Inch)
      55"
      Panel Technology
      OLED
    • Back Light Type
      OLED
      Aspect Ratio
      16:9
    • Native Resolution
      1920x1080 (FHD)
      Refresh Rate
      120 Hz
    • Brightness
      200/600nit (APL 100%/25%, Without Glass)
      Contrast Ratio
      200,000 : 1
    • Color gamut
      DCI 90%, BT709 110%
      Viewing Angle (H x V)
      178x178
    • Color Depth (Number of Colors)
      10bit(R), 1.07Bilion colors
      Response Time
      0.1ms (G to G), 8ms (MPRT)
    • Surface Treatment (Haze)
      Haze 3% (SET), Hard coating (5H)
      Life time
      30,000 Hrs (Typ.)
    • Operation Hours (Hours/Day)
      18/7 (Moving Content Only)
      Portait / Landscape
      Yes / Yes
    • Transparency
      43% (SET)
    Connectivity
    (Jack Interface)
    • HDMI IN
      Yes(1), HDCP 2.2/1.4
      DP IN
      Yes(1), HDCP1.3
    • RS232C IN
      Yes(1)
      RJ45(LAN) IN
      Yes(1)
    • IR IN
      Yes(1), External IR Receiver
      USB IN
      USB2.0 Type A(2)
    • DP Out
      Yes(1)
      Audio Out
      Yes(1)
    • RS232C Out
      Yes(1)
      RJ45(LAN) Out
      Yes(1)
    • IR Out
      Sharing RS232C Out
      Daisy Chain
      Input HDMI, DP / Output DP
    Mechanical
    • Bezel Color
      Transparent
      Bezel Width
      T/R/L/B : 7.9/7.9/7.9/121.8mm
    • Weight (Head)
      11.6Kg (Head), 2.6Kg (Signage Box)
      Packed Weight
      21.9Kg
    • Monitor Dimensions (W x H x D)
      1225.5 x 810.1 x 14.6mm (Head)
      381.6 x 217.6 x 73.6 (Signage Box)
      Carton Dimensions (W x H x D)
      1345 x 920 x 246mm
    Protection Glass
    • Thickness
      3.0mm
      Tempered / Chemical strengthening
      Chemical strengthening
    • Anti-Reflective
      Yes (Film)
      Shatter-Proof
      Yes
    HW Feature
    • Internal Memory (eMMC)
      16GB
      Temperature Sensor
      Yes
    SW Feature
    • OS Ver. (webOS)
      webOS7.5
      Local Contents Scheduling
      Yes
    • Group Manager
      Yes
      USB Plug & Play
      Yes
    • Fail over
      Yes
      RS232C Sync
      Yes
    • Local Network Sync
      Yes
      Video Tag
      Yes(4)
    • Screen Rotation
      Yes
      External Input Rotation
      Yes
    • Gapless Playback
      Yes
      Tile Mode Setting
      Yes
    • Setting Data Cloning
      Yes
      SNMP
      Yes
    • ISM Method
      Yes
      Auto Set ID
      Yes
    • Status Mailing
      Yes
      Control Manager
      Yes
    • PM mode
      Yes
      Wake on LAN
      Yes
    • HDMI-CEC
      Yes
      SI Server Setting
      Yes
    • Scan Inversion
      Yes
    Environment Conditions
    • Operation Temperature
      0 °C to 40 °C
      Operation Humidity
      10 % to 80 %
    Power
    • Power Supply
      AC 100-240V~, 50/60Hz
      Power Type
      Built-In Power
    POWER
    Consumption
    • Typ.
      70W (IEC 62087)
      Max.
      230W
    • BTU (British Thermal Unit)
      239 BTU/Hr(Typ), 785 BTU/Hr(Max.)
      DPM
      0.5W
    • Power off
      0.5W
    Certification
    • Safety
      CB / NRTL
      EMC
      FCC Class "A" / CE / KC
    • ErP / Energy Star
      Yes / No
    Software Compatibility
    • SuperSign CMS
      Yes
      SuperSign Control+
      Yes
    • SuperSign Cloud
      Yes
      Mobile CMS
      Yes
    • Connected Care
      Yes
    Language
    • OSD
      English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Polski, Türk?e, Arabic
    Accessory
    • Basic
      Remote Controller(include battery 2ea), Power Cord, QSG,
      IR receiver, Regulation Book, Phone to RS232C Gender, MCX/Harness Cables(1000mmx4ea/1000mmx2ea) for connection between panel and Signage Box), DP Cable(2M), LAN Cable(1.5M), RS232 Cable(4P-4P,1.5M), LC Cable(VLC,3M), Screw(M3xL5.5 Black,16EA / M3xL3.5 Silver, 20EA / M4xL22 Black, 22EA), Cover Shield Assy 1EA, Cable Rubber 1EA, Rubber Damper 4EA, Cable Holder 4EA, Signage Box Wing Bracket 2EA
    Special Feature
    • Conformal Coating (Power Board)
      Yes

    To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
