Discontinued

65EJ5E-B component-copyModelName

Flat OLED Signage

Key Features

Brightness(Typ.): 400 cd/m2 (APL 25%)
Bezel: 0.9 mm (Even, Off bezel)
Depth: 6.0 mm (Head)
Interface: HDMI/ USB 2.0(2)/ DP/ Audio Out/ RS232C/ RJ45/ IR

Choose your Size

Add to Compare

component-OBScountrySelectDesc

Key Features

Brightness(Typ.): 400 cd/m2 (APL 25%)
Bezel: 0.9 mm (Even, Off bezel)
Depth: 6.0 mm (Head)
Interface: HDMI/ USB 2.0(2)/ DP/ Audio Out/ RS232C/ RJ45/ IR

Choose your Size

Add to Compare

component-OBScountrySelectDesc

component-copyModel-toastMsg

Flat OLED Signage

Artistic Space Beyond Display

This sophisticated wallpaper OLED signage achieves the best possible picture quality, concealing its presence by blending in with the wall. Minimal space is required for installation, which simplifies the construction process.

Unrivaled Picture Quality

Perfect Black

Limitless contrast and the deepest blacks
Self-lighting pixels switch off completely to reproduce absolutes blacks with no light bleed, offering infinite contrast

Unrivaled Picture Quality

Perfect Color

Accurate & stable color reproduction
Self-lighting pixels bring colors to life with superb accuracy.

Unrivaled Picture Quality

Perfect Viewing Screen

Wide viewing angle
LG OLED Signage delivers awe-inspiring picture quality across the entire screen, even from wide viewing angles.

Ultimate Elegance of Design

Perfect Design

LG's OLED technology unlocks the new worlds of design flexibility with unbelievably lightweight and slim display. The advantages the OLED display brings are countless from the easier installation to a sleek look.

Ultimate Elegance of Design

Hide in Plain Sight

The subtle edge of the wallpaper OLED totally blends in with the wall, giving audiences the sensation that content is being played directly within the wall itself. Integrating with and adding to a luxurious interior design, the wallpaper OLED is an effective method for delivering advertisements and information.

06_NxN-Expandable-Screen-Size_1537340259889

Realizing an Immersive View

N×N Expandable Screen Size

By tiling up displays horizontally and vertically, the screen size can be as large as users want. Expansive, large screens are more effective at moving viewers by providing an incredibly immersive viewing experience.

07_LAN-Daisy-Chain-Management_1537252982979

Realizing an Immersive View

LAN Daisy Chain Management

A LAN daisy chain allows you to execute commands to control and monitor the screens and even update their firmware.

08_Wall-Fixers-Optimized-for-Simple-Tiling_1537253037828

Easy Installation

Wall Fixers Optimized for Simple Tiling

The overall installation process of the wallpaper OLED has gotten much easier. Once the dedicated wall fixers are driven into a wall, a display can be easily hung on them. Video wall tiling has become more convenient, thanks to its front installation feature, which departs from the conventional side-sliding method.

09_Enhanced-Flexibility-of-Cables_1537253090446

Easy Installation

Enhanced Flexibility of Cables

As a result of in-depth consideration of usage scenarios, improvements have been made to the flexibility of common cables connecting the display to the signage box. These new cables are pliable enough to be easily embedded in a wall or other structures.

Panel

Screen Size

65"

Native Resolution

3,840 x 2,160 (UHD)
Brightness (APL25%, Typ., cd/m2)

400

Brightness (APL100%, Typ., cd/m2)

150

Connectivity

Input

HDMI, DP, USB 2.0 (2)

Output

DP, Audio
External Control

RS232C In/out, RJ45 In/out, External IR Receiver

Physical Specification

Bezel Width

(Off bezel) 0.9 mm (Even)
(On bezel) 8.1 mm (T), 10.7 mm (B), 8.3 mm (L/R)

Dimension (W x H x D)

(Head) 1,445.1 x 822.6 x 6.0 mm
(Signage Box) 782.8 x 35.5 x 239.0 mm
Weight

13.5 kg (Set)

Carton Dimensions (W x H x D)

1,590 x 965 x 205 mm
Packed Weight

23.4 kg

Environment Conditions

Operation Temperature Range

0°C ~ 40°C

Operation Humidity Range

10% ~ 80%

Power

Power Supply

100-240V~, 50/60Hz

Power Type

Built-In Power
Power Consumption (Typ. / Max.)

440 W (8 color bar) / 478 W (8 color bar)

Standard(Certification)

Safety

IEC 60950-1 / EN 60950-1 / UL 60950-1

EMC

FCC Class "A" / CE / KC
ErP / Energy Star

Yes (EU Only) / No

Media Player Compatibility

OPS type compatible

No

External Media Player Attachable

Yes

Software Compatibility

Content Management Software

SuperSign CMS

Control and Monitoring Software

SuperSign Control+ / Control

Accessory

Basic

Remote Controller, Power Cord, QSG, IR Receiver, Regulation Book, Phone to RS232C Gender, RS232 Cable (4p-4p), FFC Cables (for Connection Between Panel and Signage Box), DP Cable, LAN Cable, LC (VLC Cable), Wall Fixers, Wall Fixer Install Guide, Install Guide Sheets, Tapes (for Cabling and Dust Proof), Screws

Dimension
- 65ej5e_Dimension.dwg
- 65ej5e_Dimension.pdf
Datasheet
- EJ5E leaflet_web_11810.pdf
Software

To download Software, Please visit the Software Download Page (Click).
Manual

To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
