    LG UltraFine Display OLED Pro
    Contact Us

    The Ultimate Professional OLED Monitor Designed for Broadcast

    Filming is in progress in a studio with a large LED screen as the background. One 65EP5Q is used for color grading, while another is displaying the output for monitoring. Filming is in progress in a studio with a large LED screen as the background. One 65EP5Q is used for color grading, while another is displaying the output for monitoring.
    * All images in this page are for illustrative purposes only.
    The left image shows content being monitored in a studio using the 65EP5Q, while the right image displays a close-up of the 65EP5Q’s rear interface, showcasing its diverse input and output options. The left image shows content being monitored in a studio using the 65EP5Q, while the right image displays a close-up of the 65EP5Q’s rear interface, showcasing its diverse input and output options.

    Diverse I/O Interfaces

    A variety of input interfaces are provided including HDMI and SDI In/Out with BNC, and it also supports SDI over IP via SFP+ case with a SFP module. OLED Pro can transmit 12Gbps data transfer for 4K 60p images.*

    * To use 4K 60p, only the YCbCr 4:2:2 10-bit format is available.
    A basketball game broadcast is being monitored on the 65EP5Q, which displays consistent and accurate colors across the entire screen without distortion, regardless of viewing angle. A basketball game broadcast is being monitored on the 65EP5Q, which displays consistent and accurate colors across the entire screen without distortion, regardless of viewing angle.

    Consistent Luminance & Color Accuracy

    OLED Pro's advanced localized brightness compensation helps deliver consistent, accurate colors across the entire display surface. Experience enhanced color fidelity and vibrancy, regardless of seating position or viewing angle. Whether it's a small review session or a packed presentation, you can enjoy a superior viewing experience—clear, precise, and uniform from edge to edge.
    The left screen shows an underwater scene that appears muted due to murky colors, while the OLED Pro display on the right, which supports 3D LUT, delivers a more vivid and accurate representation of the underwater environment. The left screen shows an underwater scene that appears muted due to murky colors, while the OLED Pro display on the right, which supports 3D LUT, delivers a more vivid and accurate representation of the underwater environment.

    Professional Color Grading with 3D LUT

    Experience precise color control and creative freedom with OLED Pro’s full support for professional 3D Look-Up Tables. Whether you’re crafting cinematic visuals or monitoring live broadcast content, easily apply and adjust LUTs to reflect your exact artistic vision. This advanced color processing empowers creators and post-production teams to meet demanding visual standards, exceed client expectations, and bring unique stories to life.

    * Images shown are for illustrative purposes only.
    The image shows the 65EP5Q's Load Profile menu interface, illustrating how multiple user-specific screen setting profiles are stored separately and can be easily switched between. The image shows the 65EP5Q's Load Profile menu interface, illustrating how multiple user-specific screen setting profiles are stored separately and can be easily switched between.

    Instant, Secure Profile Switching with Password Protection

    Switch instantly between up to 10 customized setting profiles— whether for different users, color spaces, or project types. Stay precise and productive across every workflow with effortless transitions between configurations. Each profile can be passwordprotected to help prevent unauthorized changes, ensuring your calibrated settings remain consistent—so you can focus on creating, not recalibrating.
    Close
    Info
    • Product
      OLED Pro
      Year
      Y25
    • Month
      M06
    Panel
    • Screen Size (Inch)
      65"
      Panel Technology
      OLED
    • Back Light Type
      OLED
      Aspect Ratio
      16:9
    • Native Resolution
      3840x2160 (UHD)
      Refresh Rate
      120Hz
    • Brightness
      2900/2200/1000/330nit (APL 3%/10%/25%/100%)
      Contrast Ratio
      3,300,000 : 1
    • Color gamut
      DCI-P3 99.5%
      Viewing Angle (H x V)
      178 x 178
    • Color Depth (Number of Colors)
      10bit, 1.07Billion colors
      Response Time
      0.1ms (G to G)
    • Surface Treatment (Haze)
      Haze 1%
      Life time
      30,000 Hrs (Typ.)
    • Operation Hours (Hours/Day)
      12/7 (Moving Content Only)
      Portait / Landscape
      No / Yes
    Connectivity
    (Jack Interface)
    • HDMI IN
      Yes(1), (HDCP1.4/2.2)
      RS232C IN
      Yes(1), Service only
    • RJ45(LAN) IN
      Yes(1), 100base-T
      USB IN
      USB2.0 Type A(1)
    • Audio Out
      Yes (1)
    Mechanical
    • Bezel Color
      Sliver
      Bezel Width
      T/R/L/B : 1.5/1.5/1.5/1.5mm (Off Bezel)
      T/R/L/B : 6.2/6.2/6.2/11.1mm (On Bezel)
    • Weight (Head)
      22kg
      Weight (Head+Stand)
      27.3kg
    • Packed Weight
      34.1kg
      Monitor Dimensions (W x H x D)
      1441 x 826 x 24.3mm
    • Monitor Dimension with Stand (W x H x D)
      1441 x 865/910 x 263mm
      Carton Dimensions (W x H x D)
      1600 x 970 x 172mm
    • VESATM Standard Mount Interface
      300 x 300
    HW Feature
    • Internal Memory (eMMC)
      16GB
      Wi-Fi/BT (Built-in)
      Yes
    • Temperature Sensor
      Yes
      Power Indicator
      Yes
    • Local Key Operation
      Yes
      FAN (Built-in)
      Yes
    SW Feature
    • OS Ver. (webOS)
      webOS8.5
      No Signal Image
      Yes
    • PIP
      Yes
      PBP
      Yes(2)
    • ISM Method
      Yes
    Environment Conditions
    • Operation Temperature
      0°C to 40°C
      Operation Humidity
      10 % to 80 %
    Power
    • Power Supply
      AC 100-240V~, 50/60Hz
      Power Type
      Built-In Power
    Power Consumption
    • Typ.
      120W (IEC 62087)
      Max.
      450W
    • BTU (British Thermal Unit)
      TBD
      Power off
      0.5W
    Sound
    • Speaker (Built-in)
      Yes (15W x 2)
    Certification
    • Safety
      CB / NRTL
      EMC
      FCC Class "A" / CE / KC
    • ErP / Energy Star
      Yes (EU Only) / No
    Software Compatibility
    • SuperSign WB
      Yes
    Language
    • OSD
      English
    Accessory
    • Basic
      Remote Controller(include battery 2ea), IG(Installation Guide), Regulation Book, Stand(Base,body,neck,cable holder,Screw), AV Cover,Wall mount cover
    Special Feature
    • Conformal Coating (Power Board)
      Yes
    Product Dedicated
    Feature
    • SDI In
      Yes(4), 12Gx4
      - Single Link : SD/HD/3G/6G/12G
      - Dual Link : HD/3G_4K
      - Quad Link : HD_4K/3G_4K
      - Quad View : HD/3G/6G/12G
      SFP+ In
      Yes(1), SFP+, Support only for the Embrionix's SDI module
    • SDI Out
      Yes(4), Loop-through
      OS ver.
      webOS8.5
    • Color Adjustment
      OLED Light, Brightness, Contrast, Chroma, Sharpness, Tint, White Balance Control
      Color Temp.
      VAR Temp/9300K/6500K/5400K/3200K/D65(6504K)/C(6774K)/D-Cinema(6302K)
    • Over scan (Over scan)
      Zero Scan, Over Scan, Under Scan
      Aspect Ratio
      Auto, Original, Full Wide, 4:3, 14:9, 13:9, 1.85:1, 2.35:1, 1:1
    • Zoom
      x2~x5
      HDR/SDR monitoring
      Yes
    • Calibration SW
      Yes (SuperSign WB - including Uniformity Compensation, 9p/13p/25p, EBU Grade1)
      3rd Party Cal. SW Compatibility
      Yes (CalMAN - including Uniformity Compensation, 9p/13p/25p, EBU Grade1)
      ※ LG Connect must be on.
    • Eyesafe Certification (Less than 50% of blue light emission)
      Yes
      DeltaE < 2
      Yes
    • Gamut
      Auto/Native/BT.709/BT.2020/sRGB/AdobeRGB/P3/Cali 1 BT.709/Cali 1 BT.2020/Cali 1 sRGB/Cali 1 AdobeRGB/Cali 1 P3
      SDI Color Format
      Auto, RGB444, YCbCr444, YCbCr422
    • Custom 3D LUT file Import (through USB)
      Yes
      R/G/B Gain
      Adjustable (0~1023)
    • Mono/Blue Only
      Yes
      Transfer Matrix
      Yes
    • Mastering Peak
      Yes
      EOTF(Electro-Optical Transfer Function)
      Auto/User/1.9/2.2/2.4/2.6/Cali 1~Cali 10
    • Audio - Source Selection
      Yes (SDI1, SDI2, SDI3, SDI4)
      Audio - Level Meter
      Yes (Ch1~16, Selectable)
    • Audio - Sound Mode
      Yes
      Audio - Dolby Atmos
      Yes
    • Profile Load / Save
      Profile1~10
      Function Key
      Function1~5
    • VPID
      Yes
      Internal Signal Pattern
      Yes
    • PBP
      Yes
      PIP
      Yes
    • OLED Panel Setting (for image sticking prevention)
      TPC Auto-dimming (Temporal Peak Luminance Control), Pixel Cleaning, Screen Shift, Logo Luminance Adjustment, GSR Auto dimming(Global Sticky Reduction),Convex Power Control
      LG Connect
      Yes
    • 3rd Party Control Pad Compatibility
      Yes (Open API)
      Remote IP Control App (HTML)
      Yes
    • Datasheet
      • 65EP5Q Datasheet(low)_LG OLED Pro Monitor_250825.pdf
    • Software

      To download Software, Please visit the Software Download Page (Click).

    • Manual

      To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).

    To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
